METSO IOP320 181545 – 8-Channel Analog Output Module | Metso DNA DCS Platform
Engineering Background
The METSO IOP320 (Part No. 181545) is a high-precision 8-channel analog output I/O module designed for the Metso DNA distributed control system platform. Originally engineered for demanding process industries including pulp & paper, power generation, oil & gas, and chemical processing, this module delivers reliable 4–20 mA current loop outputs with optional HART communication capability. It integrates seamlessly into Metso DNA controller cabinets, providing deterministic signal conditioning and galvanic isolation for field instrumentation.
Product Positioning
The IOP320 181545 is the preferred analog output card for engineers maintaining or expanding legacy Metso DNA systems. Its plug-and-play compatibility with existing I/O bus architectures eliminates costly re-engineering, while its robust industrial-grade construction ensures long-term reliability in harsh plant environments. Konmask.com supplies this module as a tested, genuine replacement unit with full traceability documentation.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | IOP320 / 181545 |
| Manufacturer | METSO (Neles Controls / Metso Automation) |
| Platform | Metso DNA DCS |
| Module Type | Analog Output I/O Module |
| Number of Channels | 8 Channels |
| Output Signal Range | 4–20 mA (current loop) |
| Resolution | 12-bit D/A conversion |
| HART Communication | Supported (per channel) |
| Isolation | Galvanic isolation, channel-to-channel and channel-to-bus |
| Supply Voltage | 24 VDC (via I/O bus backplane) |
| Power Consumption | ≤ 5 W typical |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +70°C |
| Humidity | 5–95% RH, non-condensing |
| Protection Class | IP20 |
| Mounting | DIN rail / Metso DNA I/O bus carrier |
| Weight | 1,470 g |
| Country of Origin | Finland |
| Certifications | CE, UL (refer to original datasheet) |
Proven Application Environments
- Pulp & Paper Mills – Precise control of bleaching, digester, and recovery boiler actuators
- Power Generation – Turbine governor and boiler feed control loops
- Oil & Gas Processing – Flow control valves and pressure regulation in upstream/downstream facilities
- Chemical & Petrochemical Plants – Reactor temperature and feed rate control
- Water & Wastewater Treatment – Pump speed and dosing control via 4–20 mA field devices
Engineering Advantages
- 8-Channel Density – Maximizes cabinet space utilization; reduces wiring complexity per output point
- HART Pass-Through – Enables remote device diagnostics and parameterization without additional hardware
- Full Galvanic Isolation – Eliminates ground loops and protects controller bus from field-side transients
- Hot-Swap Compatible – Supports live replacement in Metso DNA systems without process shutdown (configuration dependent)
- Deterministic Scan Cycle – Synchronized with Metso DNA controller for predictable loop performance
- Wide Temperature Range – Qualified for ambient conditions typical of industrial control rooms and marshalling cabinets
System Architecture & Signal Flow
The IOP320 181545 mounts on a Metso DNA I/O bus carrier and communicates with the system controller via the proprietary I/O bus backplane. Each of the 8 output channels independently converts a digital setpoint from the controller into a precision 4–20 mA current signal. The HART modem layer superimposes a digital FSK signal on the 4–20 mA loop, enabling bidirectional communication with HART-capable field instruments. Galvanic isolation barriers on each channel prevent common-mode interference from propagating to the controller bus, ensuring signal integrity across long cable runs in electrically noisy plant environments.
Sourcing & Quality Verification
- Genuine OEM Parts – All IOP320 181545 units sourced from authorized channels or decommissioned Metso DNA systems with full chain-of-custody documentation
- Pre-Shipment Testing – Each module undergoes functional verification: channel output accuracy, HART communication check, and isolation resistance test
- Traceability – Serial number and firmware revision recorded; documentation available upon request
- Packaging – ESD-safe anti-static packaging with foam cushioning; suitable for international air and sea freight
- Warranty – 90-day functional warranty against manufacturing defects; extended warranty available
Procurement Process
- Confirm Compatibility – Verify your Metso DNA controller revision and I/O bus carrier type against IOP320 compatibility matrix
- Request Quote – Contact support@konmask.com with quantity, delivery timeline, and destination port
- Order Confirmation – Purchase order accepted; lead time typically 3–7 business days for in-stock units
- Inspection & Dispatch – Pre-shipment test report issued; unit dispatched via DHL / FedEx / sea freight per buyer preference
- After-Sales Support – Technical integration support available via email or WhatsApp: +0086 19859288691
Technical FAQ
Q: Is the IOP320 181545 compatible with all Metso DNA controller generations?
A: The IOP320 is designed for Metso DNA systems. Compatibility depends on the specific controller revision and I/O bus carrier. Please provide your system configuration details for confirmation before ordering.
Q: Can the IOP320 operate in SIL-rated safety loops?
A: The standard IOP320 is not SIL-certified. For safety instrumented systems, consult Metso’s safety I/O product line or contact us for guidance.
Q: What firmware version is supported?
A: Firmware version is module-specific. We document the firmware revision of each unit prior to shipment and can provide this information upon request.
Q: Do you offer exchange/repair services?
A: Yes. We offer board-level repair and exchange programs for IOP320 modules. Contact us for pricing and turnaround time.
Q: What is the minimum order quantity?
A: Minimum order quantity is 1 unit. Volume pricing is available for orders of 5 units or more.
