HMI Visualization & Machine Control Solution – Mitsubishi Electric GT2508-VTBD | GOT2000 Series
Where This Product Is Used
The GT2508-VTBD is deployed wherever engineers need a robust, high-resolution operator interface tightly coupled to a Mitsubishi MELSEC PLC or third-party controller. Typical installation environments include:
- Automotive body & paint lines – real-time monitoring of robot cell status, weld counts, and conveyor interlocks
- Food & beverage packaging – recipe management, batch logging, and CIP cycle visualization on wash-down-rated panels
- Semiconductor & electronics manufacturing – cleanroom-compatible operator stations for SMT lines and AOI equipment
- Water treatment & utilities – SCADA-edge HMI for pump stations, dosing skids, and filtration systems
- Machine tool & CNC cells – spindle load trending, alarm history, and tool-life management displays
- Pharmaceutical production – 21 CFR Part 11-ready audit-trail screens for filling and packaging lines
- Building automation & HVAC – energy dashboard and setpoint adjustment for chiller and AHU control panels
Technical Specifications
| Parameter | Value |
|---|---|
| Model | GT2508-VTBD |
| Series | GOT2000 (GT25) |
| Display Size | 8.4 inch TFT Color LCD |
| Resolution | 800 × 600 (SVGA) |
| Brightness | 400 cd/m² |
| Touch Panel Type | Analog resistive |
| CPU | 32-bit RISC processor |
| Built-in Memory | 57 MB user memory |
| SD Card Slot | Yes (SDHC up to 32 GB) |
| USB Host | USB-A × 1 |
| USB Device | USB-B × 1 (programming) |
| Ethernet | 100BASE-TX × 1 |
| RS-232 / RS-422/485 | Via expansion unit |
| Power Supply | DC 24 V ±10% |
| Power Consumption | ≤ 14 W |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -20 °C to +60 °C |
| Humidity | 10 % to 90 % RH (non-condensing) |
| Front Panel Protection | IP67 (dust-tight & waterproof) |
| Rear Protection | IP2X |
| Vibration Resistance | 5–8.4 Hz: 3.5 mm amplitude; 8.4–150 Hz: 9.8 m/s² |
| Panel Cutout (W × H) | 227 mm × 175 mm |
| Dimensions (W × H × D) | 246 mm × 194 mm × 60 mm |
| Weight | Approx. 1.2 kg |
| Certifications | CE, UL, cUL, KC |
| Programming Software | GT Works3 (GT Designer3) |
Why Engineers Specify This Model
- Native MELSEC integration – zero-configuration tag import from GX Works2/3 eliminates manual address mapping and reduces commissioning time by hours
- Multi-protocol gateway built-in – connects simultaneously to MELSEC-Q/L/FX, CC-Link IE Field, MODBUS TCP/RTU, and 100+ third-party PLCs without an external gateway
- IP67 front face – survives high-pressure washdowns in food, pharma, and chemical environments where lesser panels fail within months
- GOT Mobile function – operators monitor and operate the HMI from a tablet or smartphone over Wi-Fi without additional server software
- iQ Works integration – single engineering environment for PLC, motion, robot, and HMI reduces project file management overhead
- Long product lifecycle – Mitsubishi Electric’s 10-year production guarantee supports capital equipment with multi-decade service lives
- Thin-client VNC server – remote desktop access for maintenance engineers without opening the panel door
Complete System Bill of Materials
A fully operational GT2508-VTBD operator station typically requires the following components:
- GT2508-VTBD – HMI main unit (this item)
- GT25-PS – 24 VDC power supply unit (if not sourced separately)
- GT09-C30USB-5P – USB programming cable (USB-A to USB-B, 3 m)
- GT Works3 License – GT Designer3 engineering software (1 seat minimum)
- SD card (SDHC, Class 10) – for recipe, alarm log, and screen data backup
- GT25-RS4-9P – RS-422/485 serial communication unit (if serial PLC connection required)
- Panel gasket & M4 mounting clamps – supplied in box; verify quantity before installation
- Ethernet patch cable (Cat5e or Cat6) – for network-connected deployments
Compliance & Industry Standards
- CE Marking – EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- UL 508 – Industrial Control Equipment (UL & cUL listed)
- KC Mark – Korean Radio Waves Act compliance
- IP67 – IEC 60529 ingress protection (front panel)
- RoHS 2 – Directive 2011/65/EU, restriction of hazardous substances
- SEMI E10 / E79 – compatible with semiconductor equipment availability and efficiency reporting frameworks
- 21 CFR Part 11 readiness – audit trail and user authentication functions support FDA electronic records requirements
Quality Assurance & Sourcing
Every GT2508-VTBD unit supplied by Konmask.com is:
- Sourced directly from Mitsubishi Electric authorized distribution channels or verified tier-1 industrial distributors
- Inspected for intact factory seals, correct label printing, and matching serial number against manufacturer records
- Stored in ESD-safe, climate-controlled warehousing to prevent humidity and electrostatic damage
- Shipped with original Mitsubishi Electric packaging, documentation, and accessories
- Backed by Konmask’s 12-month quality warranty covering manufacturing defects
We do not supply grey-market, refurbished, or counterfeit units. Authenticity documentation available on request.
How to Source This Part
- Add to cart and complete checkout — most in-stock orders ship within 1–3 business days from our Hong Kong / Mainland China warehouse
- Request a quote for volume orders (5+ units) via [email protected] — volume pricing and lead-time confirmation provided within 24 hours
- Provide your project BOM if you need the full system (HMI + PLC + cables + software) — Konmask can consolidate sourcing and reduce procurement overhead
- Expedited shipping available via DHL Express, FedEx International Priority, or UPS Worldwide — contact us before checkout to arrange
- Export documentation (commercial invoice, packing list, CO, Form E) prepared for all international shipments
Application-Specific FAQ
Q: Can the GT2508-VTBD connect directly to a Siemens S7-1200 or Allen-Bradley CompactLogix?
A: Yes. GT Works3 includes pre-built communication drivers for Siemens S7 (via Ethernet) and Rockwell DF1/EtherNet/IP. No external gateway hardware is required for most topologies.
Q: Is the GT2508-VTBD suitable for outdoor or direct-sunlight installations?
A: The standard unit is rated for 0–55 °C ambient and 400 cd/m² brightness, which is marginal for direct sunlight. For outdoor kiosks, specify an anti-glare overlay and supplemental shading. Contact us for sunlight-readable enhancement options.
Q: What is the difference between GT2508-VTBD and GT2508-VTBA?
A: The suffix indicates the color of the bezel and minor regional certification variants. Core hardware, display, and communication specifications are identical. Confirm your regional certification requirement before ordering.
Q: Can I transfer existing GT16 or GT15 screens to the GT2508-VTBD?
A: GT Works3 includes a project conversion wizard that migrates GT16/GT15 projects. Some advanced objects may require manual adjustment. Mitsubishi Electric’s migration guide (SH-081220) provides step-by-step instructions.
Q: What is the recommended spare-parts strategy for a production line using this HMI?
A: For lines with ≥ 8 hours/day operation, Konmask recommends holding one cold-spare GT2508-VTBD per 10 installed units, plus a pre-loaded SD card with the current screen project. This reduces unplanned downtime to under 30 minutes in most failure scenarios.
Q: Does Konmask provide programming or commissioning support?
A: We offer remote commissioning assistance and GT Works3 project review services. Contact [email protected] with your project requirements.
