Machine Control Solution – Mitsubishi Electric FX0N-8EYT | FX0N Series Expansion Module
Where This Product Is Used
The Mitsubishi FX0N-8EYT is an 8-point transistor (NPN sink) digital output expansion module designed for the MELSEC FX0N series programmable logic controllers. It is widely deployed across demanding industrial environments where compact footprint and reliable high-speed switching are critical:
- Packaging machinery – precise solenoid and actuator control on form-fill-seal lines
- Conveyor & material handling systems – coordinating motor starters, diverters, and gate valves
- Injection molding & press control – fast-response output switching for hydraulic valves
- Assembly line automation – driving indicator lamps, buzzers, and relay coils
- HVAC & building automation panels – fan, pump, and damper actuator control
- Food & beverage processing – hygienic-environment compatible panel integration
- Textile and printing equipment – synchronized multi-axis output sequencing
Technical Specifications
| Part Number (SKU) | FX0N-8EYT |
| Series | MELSEC FX0N |
| Manufacturer | Mitsubishi Electric |
| Module Type | Digital Output Expansion Module |
| Output Points | 8 points (transistor, NPN sink type) |
| Output Type | Transistor (sink) – T suffix |
| Rated Load Voltage | 5–24 VDC |
| Max Load Current | 0.5 A per point / 0.8 A per common |
| Response Time (OFF→ON) | ≤ 0.2 ms |
| Response Time (ON→OFF) | ≤ 0.2 ms |
| Power Consumption | Supplied from FX0N base unit |
| Compatible Base Units | FX0N-14MR, FX0N-24MR, FX0N-40MR, FX0N-60MR |
| Connection Method | Direct expansion connector (right-side bus) |
| Operating Temperature | 0 – 55 °C |
| Storage Temperature | -25 – 75 °C |
| Humidity | 5 – 95% RH (non-condensing) |
| Dimensions (W × H × D) | Approx. 60 × 90 × 87 mm |
| Weight | Approx. 200 g |
| Certification | CE, UL, cUL |
Why Engineers Specify This Model
- High-speed transistor switching – sub-millisecond response enables precise pulse-train and high-frequency output applications
- Compact snap-on expansion – no additional wiring harness; plugs directly onto the FX0N bus connector
- NPN sink compatibility – matches the dominant sensor/actuator wiring standard across Asian and European machine builders
- Proven MELSEC reliability – Mitsubishi Electric’s FX0N platform has a multi-decade field track record in harsh industrial environments
- Low heat dissipation – transistor outputs generate minimal heat, reducing panel thermal load
- Scalable I/O architecture – stack multiple FX0N expansion modules to grow point count without replacing the base unit
Complete System Bill of Materials
For a fully operational FX0N control system incorporating the FX0N-8EYT, engineers typically specify:
- FX0N series base unit (e.g., FX0N-24MR or FX0N-40MR)
- FX0N-8EYT – this module (8-pt transistor output expansion)
- FX0N-8EX or FX0N-16EX – digital input expansion (if additional inputs required)
- FX0N-3A – analog I/O expansion (for process variable control)
- FX-232AW or FX-USB-AW – programming cable / USB adapter
- GX Works2 or GX Developer – Mitsubishi PLC programming software
- 24 VDC DIN-rail power supply (e.g., Meanwell DR-60-24)
- Terminal blocks, DIN rail, and panel enclosure
Compliance & Industry Standards
- CE Marking – EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- UL / cUL Listed – UL 508 Industrial Control Equipment
- RoHS Compliant – Directive 2011/65/EU
- IEC 61131-2 – Programmable Controllers: Equipment Requirements and Tests
- IP20 – Protection class for panel-mounted installation
Quality Assurance & Sourcing
All units supplied by Konmask.com are:
- Sourced from authorized Mitsubishi Electric distribution channels or verified industrial surplus with full traceability
- Inspected for physical integrity, label authenticity, and connector condition prior to dispatch
- Shipped in anti-static packaging with protective foam inserts
- Backed by Konmask’s quality guarantee – defective units are replaced or refunded
How to Source This Part
- Add the FX0N-8EYT to your cart and proceed to checkout
- For bulk orders (> 5 units) or project BOM quotes, email support@konmask.com
- Lead time: in-stock units ship within 1–3 business days; special orders within 7–14 days
- International shipping available – DHL, FedEx, and EMS options at checkout
- Payment: T/T bank transfer, PayPal, and major credit cards accepted
Application-Specific FAQ
Q: Can the FX0N-8EYT be used with FX1N or FX2N base units?
A: No. The FX0N-8EYT is designed exclusively for the FX0N series bus. For FX1N/FX2N systems, use FX2N-8EYT or FX1N-compatible expansion modules.
Q: How many FX0N-8EYT modules can be connected to one base unit?
A: Up to 2 expansion modules (input or output) can be connected to an FX0N base unit, subject to the base unit’s total I/O point limit.
Q: Is the FX0N-8EYT suitable for driving 24 VDC solenoid valves directly?
A: Yes, provided the solenoid coil current does not exceed 0.5 A per output point. For higher-current loads, use an interposing relay.
Q: What is the difference between FX0N-8EYT and FX0N-8EYR?
A: The FX0N-8EYT uses transistor (solid-state) outputs for high-speed switching; the FX0N-8EYR uses relay outputs for higher voltage/current loads and AC load compatibility.
Q: Do you provide a datasheet or wiring diagram?
A: Yes – contact support@konmask.com and reference part number FX0N-8EYT to receive the official Mitsubishi Electric hardware manual.
