Mitsubishi SJ-PF7.5-01 AC Servo Motor 7.5kW | Replacement, Equivalent & Selection Guide
The Mitsubishi SJ-PF7.5-01 is a high-performance AC servo motor from Mitsubishi Electric’s SJ-PF series, rated at 7.5 kW. Designed for demanding industrial automation applications, it delivers precise torque control, high dynamic response, and long-term reliability. This page provides full technical specifications, compatible replacement models, selection guidance, and sourcing information to help engineers and procurement teams make confident decisions.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | SJ-PF7.5-01 |
| Brand | Mitsubishi Electric |
| Series | SJ-PF |
| Rated Output Power | 7.5 kW |
| Rated Voltage | 200–230 V AC (3-phase) |
| Rated Speed | 2000 rpm |
| Encoder Type | Incremental / Absolute (series-dependent) |
| Protection Class | IP65 (shaft seal) |
| Insulation Class | Class F |
| Weight (approx.) | 6.0 kg |
| Mounting | Flange mount |
| Compatible Drive | MR-J4 / MR-J3 Series Servo Amplifier |
| Country of Origin | Japan |
Compatible Replacement & Equivalent Models
When the SJ-PF7.5-01 is unavailable or requires a direct substitute, the following models offer compatible performance characteristics. Always verify mechanical dimensions, encoder interface, and drive compatibility before substitution.
| Model | Brand | Power | Compatibility Notes |
|---|---|---|---|
| SJ-PF7.5 | Mitsubishi Electric | 7.5 kW | Base model; confirm suffix for encoder variant |
| HG-SR7024 | Mitsubishi Electric | 7.0 kW | Newer HG-SR series; MR-J4 compatible |
| SGMGH-09ACA61 | Yaskawa | 850 W | Different power class; verify application requirements |
| 1FK7083-5AF71 | Siemens SIMOTICS | 7.5 kW | Cross-brand; requires drive and coupling adaptation |
| AKM74P | Kollmorgen | ~7.5 kW | Cross-brand; verify flange and encoder interface |
Note: Cross-brand replacements require engineering validation. Contact Konmask technical support for assistance.
Why Choose the Original Model
- Guaranteed compatibility with Mitsubishi MR-J3/J4 servo amplifiers — no parameter re-tuning required.
- Proven reliability in continuous-duty industrial environments with Class F insulation and IP65 protection.
- Factory-matched encoder ensures accurate position feedback without calibration overhead.
- Full Mitsubishi ecosystem support — seamless integration with MELSERVO, MELSEC PLC, and GOT HMI platforms.
- Traceable supply chain — Konmask sources from authorized distributors with full documentation.
Typical Applications
- CNC machine tool spindle and axis drives
- Industrial robots and articulated arm systems
- Injection molding machine servo axes
- Automated assembly and pick-and-place systems
- Packaging machinery and conveyor positioning
- Semiconductor and electronics manufacturing equipment
System Compatibility
The SJ-PF7.5-01 is designed to operate with the following Mitsubishi servo amplifier and controller platforms:
- Servo Amplifiers: MR-J3-70B, MR-J3-70A, MR-J4-70B, MR-J4-70A
- PLC Controllers: MELSEC Q Series, MELSEC iQ-R Series, MELSEC iQ-F Series
- Motion Controllers: Q172DSCPU, Q173DSCPU, RD77MS Series
- HMI: GOT2000 Series (GT27, GT25)
- Network: SSCNET III/H fiber optic servo network
Selection Guide
Use the following criteria to confirm the SJ-PF7.5-01 is the correct model for your application:
- Power requirement: Confirm load torque and speed profile require 7.5 kW continuous output.
- Drive pairing: Match with MR-J3-70_ or MR-J4-70_ amplifier (70 = 7.0 kW class).
- Encoder suffix (-01): Indicates specific encoder variant — verify against your servo amplifier’s encoder input specification.
- Mounting interface: Confirm flange dimensions (IEC/JIS standard) and shaft diameter match your mechanical design.
- Environment: IP65 rating suitable for light coolant splash; not suitable for full immersion.
- Voltage supply: Requires 3-phase 200–230 V AC; confirm site power availability.
If your application requires a different power class, consider: SJ-PF4.0-01 (4.0 kW), SJ-PF5.5-01 (5.5 kW), or SJ-PF11-01 (11 kW).
Quality Assurance & Sourcing
- All units sourced from authorized Mitsubishi Electric distributors or verified surplus channels with full traceability.
- Each unit undergoes incoming inspection: visual check, label verification, and functional test where applicable.
- Original manufacturer packaging and documentation preserved where available.
- Certificate of conformity and test reports available upon request.
- Konmask.com maintains a no-counterfeit policy — all products are verified authentic before dispatch.
How to Order
- Confirm model number: SJ-PF7.5-01
- Specify quantity and required delivery timeline.
- Contact us via email or phone for stock availability and lead time confirmation.
- Receive proforma invoice and proceed with payment.
- Shipment with tracking number provided within 1–3 business days of payment confirmation.
Email: [email protected]
Phone/WhatsApp: +0086 19859288691
Website: https://konmask.com
Replacement & Compatibility FAQ
Q: Can I use the SJ-PF7.5-01 with an MR-J4 amplifier?
A: Yes, the SJ-PF series is compatible with MR-J4 amplifiers in the same power class. Verify the encoder cable connector type before installation.
Q: What is the difference between SJ-PF7.5 and SJ-PF7.5-01?
A: The -01 suffix denotes a specific encoder or design revision. Always match the full model number to your servo amplifier’s motor compatibility list.
Q: Is a Yaskawa SGMGH series motor a direct replacement?
A: No. Cross-brand substitution requires mechanical adaptation, drive parameter reconfiguration, and engineering validation. Contact us for guidance.
Q: Do you provide warranty on this product?
A: Yes. Konmask offers a standard 12-month warranty against manufacturing defects on all verified-authentic units.
Q: Can you source other SJ-PF series models?
A: Yes. We stock and can source the full SJ-PF range. Contact us with your model number for availability.
