MOOG IMI220-481A001 Interface Module | Replacement, Equivalent & Selection Guide
The MOOG IMI220-481A001 is a servo drive interface module designed for high-precision motion control systems. As an authorized sourcing partner, Konmask.com supplies genuine and compatible units with full traceability, supporting engineers and procurement teams worldwide in finding the right part — fast.
Technical Specifications
- Part Number: IMI220-481A001
- Manufacturer: MOOG Inc.
- Series: IMI220
- Module Type: Interface Module / Servo Drive Interface Card
- Form Factor: PCB Card Module
- Weight: ~80 g
- Application: Servo drive signal interface, motion control integration
- Condition Available: New, Refurbished, Tested
Compatible Replacement & Equivalent Models
If the IMI220-481A001 is discontinued or on long lead time, the following models may serve as functional equivalents depending on your system configuration. Always verify electrical and mechanical compatibility before substitution:
- MOOG IMI220-481A002 – Revised revision of the same series
- MOOG IMI220 Series variants – Same platform, different I/O configurations
- Third-party servo interface cards compatible with MOOG D136 / D137 drive platforms
Not sure which replacement fits your system? Use our Selection Guide below or contact our engineers at support@konmask.com.
Why Choose the Original MOOG IMI220-481A001
- OEM Precision: Engineered to MOOG’s exact motion control tolerances — no signal drift or compatibility guesswork.
- Plug-and-Play: Direct drop-in for existing MOOG servo drive systems without firmware changes.
- Long Service Life: Industrial-grade components rated for continuous duty in demanding environments.
- Full Traceability: Each unit sourced through verified supply chains with documentation available on request.
Typical Applications
- CNC machine tool servo axis control
- Aerospace ground support equipment
- Industrial robotics and multi-axis motion systems
- Semiconductor manufacturing equipment
- Defense and simulation platforms using MOOG servo drives
System Compatibility
The IMI220-481A001 is designed for integration with MOOG servo drive platforms. Confirm compatibility with your system by referencing:
- MOOG D136 / D137 Series Servo Drives
- MOOG Axis Controller platforms supporting IMI220 interface cards
- Systems requiring analog or digital command interface modules in the IMI220 form factor
Provide your drive model number when inquiring to receive a confirmed compatibility check.
Selection Guide
Use the following criteria to confirm the IMI220-481A001 is the right choice — or to identify the best alternative:
- Step 1 – Identify your drive platform: Confirm your MOOG drive model (D136, D137, or equivalent).
- Step 2 – Check interface type: Analog command, digital encoder, or fieldbus (EtherCAT, CANopen)?
- Step 3 – Verify revision: Check the PCB revision label on your existing card (A001, A002, etc.).
- Step 4 – Confirm form factor: Slot dimensions and connector pinout must match your drive chassis.
- Step 5 – Contact us: Send your drive nameplate photo and existing card part number for a free compatibility review.
Quality Assurance & Sourcing
- All units inspected and tested prior to shipment
- Sourced from authorized distributors and verified surplus channels
- Certificate of conformance and test reports available upon request
- Packaging: anti-static bag + foam-lined carton for safe international shipping
- Export compliance: HTS classification available; EAR99 / ECCN review on request
How to Order
- Add the MOOG IMI220-481A001 to your cart on this page.
- Or contact us directly with your PO or RFQ: support@konmask.com
- For bulk orders or urgent requirements, call/WhatsApp: +0086 19859288691
- Lead time: In-stock units ship within 1–3 business days. Special orders: 5–15 business days.
Replacement & Compatibility FAQ
Q: Can the IMI220-481A001 replace an IMI220-481A002?
A: In most cases yes, but revision differences may affect firmware compatibility. Contact us to confirm.
Q: Is a third-party equivalent available?
A: Third-party interface cards exist for some MOOG platforms. We can advise on tested alternatives — contact our engineering team.
Q: Do you supply refurbished units?
A: Yes. All refurbished units are fully tested and carry a 90-day warranty. New OEM units are also available.
Q: Can you help identify the right part from a photo?
A: Absolutely. Email a photo of your existing module and drive nameplate to support@konmask.com.
Q: Do you ship internationally?
A: Yes. We ship worldwide with DHL, FedEx, and UPS. Export documentation provided for all orders.
