Industrial Motion Control Solution – MOOG IMI220-405A001 | TMC400 Series
Where This Product Is Used
The MOOG IMI220-405A001 TMC400 Series Total Machine Controller is engineered for demanding industrial environments where precision motion control and real-time machine coordination are critical. Typical deployment scenarios include:
- CNC Machining Centers – Multi-axis contouring and spindle synchronization in high-throughput metal cutting operations
- Industrial Robotics – Coordinated joint control for articulated arms in automotive assembly and material handling
- Semiconductor Fabrication Equipment – Sub-micron positioning stages requiring deterministic real-time control
- Printing & Packaging Machinery – Register control and web tension management at high line speeds
- Injection Molding Machines – Closed-loop hydraulic and servo axis management for cycle repeatability
- Test & Measurement Systems – Dynamic load simulation and hardware-in-the-loop (HIL) test rigs
Technical Specifications
| Part Number | IMI220-405A001 |
| Series | TMC400 – Total Machine Controller |
| Manufacturer | MOOG Inc. |
| Controller Type | Multi-axis Motion & Machine Controller |
| Architecture | Real-time deterministic control kernel |
| Communication Interfaces | EtherCAT, CANopen, Ethernet (application-dependent) |
| Programming Environment | IEC 61131-3 compliant (LD, FBD, ST, SFC, IL) |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -25 °C to +70 °C |
| Protection Rating | IP20 (panel-mount installation) |
| Power Supply | 24 VDC nominal |
| Weight | Approx. 80 g (module only) |
| Condition | New / Refurbished – Tested & Verified |
Why Engineers Specify This Model
- Unified Machine Control – The TMC400 integrates motion, logic, and HMI communication into a single controller, eliminating the need for separate PLC and motion controller hardware.
- Deterministic Real-Time Performance – Hard real-time kernel ensures microsecond-level cycle consistency, critical for synchronized multi-axis applications.
- MOOG Ecosystem Compatibility – Seamlessly interfaces with MOOG servo drives, amplifiers, and actuators, reducing integration risk and commissioning time.
- Open Standards Programming – IEC 61131-3 compliance allows engineers to reuse existing PLC code and leverage standard toolchains.
- Compact Panel-Mount Form Factor – Optimized for control cabinet integration with minimal footprint.
- Long Product Lifecycle Support – MOOG’s industrial product lines are supported for extended periods, protecting capital investment in machine platforms.
Complete System Bill of Materials
For a complete MOOG TMC400-based control system, engineers typically specify the following complementary components:
- MOOG Servo Drive / Amplifier (series-matched to axis count and power requirements)
- MOOG Brushless Servo Motor (matched by frame size and encoder type)
- EtherCAT or CANopen I/O Expansion Modules
- 24 VDC DIN-rail Power Supply (appropriately rated)
- MOOG programming software license (TMC Studio or equivalent)
- Shielded motion-grade encoder and power cables
- Safety relay module (STO – Safe Torque Off, per IEC 62061)
Contact [email protected] for complete BOM assistance and cross-reference support.
Compliance & Industry Standards
- IEC 61131-3 – Programmable Controller Programming Languages
- IEC 62061 / ISO 13849 – Functional Safety for Machinery
- CE Marking – EU Machinery Directive compliance
- RoHS Compliant – Restriction of Hazardous Substances
- UL Listed components (where applicable per regional variant)
Quality Assurance & Sourcing
All MOOG IMI220-405A001 units supplied by Konmask.com undergo a structured verification process:
- Visual Inspection – Connector integrity, label authenticity, and housing condition check
- Functional Power-On Test – Verified against MOOG factory diagnostic protocols where applicable
- Serialization Verification – Serial number cross-referenced against known authentic MOOG production batches
- Anti-Counterfeit Screening – Components sourced exclusively from authorized distributors or verified OEM surplus channels
- ESD-Safe Packaging – Shipped in anti-static bags with foam cushioning and moisture barrier
How to Source This Part
Konmask.com maintains stock of industrial automation components including the MOOG IMI220-405A001. To place an order or request a quote:
- Online: Add to cart directly on this page
- Email RFQ: [email protected]
- Phone / WhatsApp: +0086 19859288691
- Lead Time: In-stock units ship within 1–3 business days; ex-stock orders confirmed at time of inquiry
- Payment: T/T (Wire Transfer), PayPal, and major credit cards accepted
- Export: Worldwide shipping available; export documentation provided upon request
Application-Specific FAQ
Q: Is the IMI220-405A001 compatible with third-party EtherCAT slave devices?
A: Yes. The TMC400 controller supports standard EtherCAT protocol, allowing integration with compliant third-party I/O modules, drives, and sensors. Compatibility testing is recommended for non-MOOG devices.
Q: Can this controller replace an older MOOG TMC300 series unit?
A: In many cases yes, but hardware I/O mapping and software migration must be validated. Contact our technical team for a compatibility assessment.
Q: What programming software is required?
A: MOOG’s TMC Studio software environment is used for configuration, programming, and diagnostics. License requirements depend on the specific firmware version installed on the unit.
Q: Do you provide a warranty?
A: Yes. Konmask.com provides a 90-day functional warranty on all tested units. Extended warranty options are available upon request.
Q: Can you supply multiple units for a production line retrofit?
A: Yes. Contact us with your quantity requirements for volume pricing and lead time confirmation.
