Industrial Drive Solution – MOTOR LINE 050745-E1CB | DC Gear Motor Series
Where This Product Is Used
The MOTOR LINE 050745-E1CB DC Gear Motor is engineered for demanding industrial and commercial drive applications where compact form factor, reliable torque output, and low-voltage operation are critical. Typical deployment environments include:
- Conveyor & Material Handling Systems – precise belt-speed control in packaging lines, sorting stations, and warehouse automation
- Robotics & Collaborative Arms – joint actuation in pick-and-place robots, AGVs, and end-of-arm tooling
- Medical & Laboratory Equipment – syringe pumps, sample carousels, and positioning stages requiring quiet, smooth rotation
- Building Automation – damper actuators, valve drives, and access-control barriers
- Agricultural Machinery – seeding mechanisms, irrigation valve drives, and feeder augers
- Vending & Dispensing Machines – product-delivery mechanisms requiring repeatable torque at low RPM
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 050745-E1CB |
| Brand | MOTOR LINE |
| Motor Type | DC Gear Motor |
| Rated Voltage | 12 V DC / 24 V DC (confirm with datasheet) |
| Output Configuration | Integrated gearbox, single output shaft |
| Enclosure | Compact metal housing |
| Weight (approx.) | 300 g |
| Mounting | Flange / bracket mount (application-specific) |
| Operating Temperature | –10 °C to +60 °C (typical) |
Note: Always verify final specifications against the official MOTOR LINE datasheet before design-in. Contact Konmask.com for the latest revision.
Why Engineers Specify This Model
- Compact Footprint – integrates gearbox and motor in a single housing, reducing BOM complexity and panel space
- High Torque-to-Size Ratio – delivers reliable output torque for its class, suitable for continuous-duty cycles
- Low Voltage Operation – compatible with 12 V / 24 V DC bus architectures common in PLC-controlled systems
- Drop-in Replacement Availability – MOTOR LINE part numbering ensures straightforward cross-referencing for MRO and OEM procurement
- Broad Application Compatibility – used across robotics, conveyor, medical, and building-automation verticals
Complete System Bill of Materials
For a fully integrated DC gear motor drive system, engineers typically specify:
- DC Gear Motor – MOTOR LINE 050745-E1CB (this unit)
- Motor Driver / PWM Controller – 12 V or 24 V H-bridge module (e.g., L298N, DRV8874)
- PLC or Microcontroller – for speed/direction command signals
- Power Supply – regulated 12 V / 24 V DC, sized to motor stall current
- Encoder (optional) – for closed-loop speed or position feedback
- Mounting Bracket & Coupling – application-specific mechanical interface
- Wiring Harness – rated for motor current with appropriate connector type
Compliance & Industry Standards
- Designed for integration into CE-marked machinery (end-product compliance is the system integrator’s responsibility)
- RoHS-compatible materials (verify current revision with MOTOR LINE documentation)
- Suitable for use in systems compliant with IEC 60034 (rotating electrical machines) guidelines
- UL recognition status: confirm with MOTOR LINE for specific market requirements
Quality Assurance & Sourcing
Konmask.com sources MOTOR LINE components through verified distribution channels. Each unit undergoes incoming inspection including:
- Visual and mechanical integrity check
- Label and part-number verification against purchase documentation
- Packaging integrity confirmation
We maintain traceability records for all stocked industrial components. Counterfeit-risk mitigation is a core part of our procurement process.
How to Source This Part
- In-Stock Orders: Add to cart and check out directly — most orders ship within 1–3 business days from our warehouse.
- Bulk / OEM Procurement: Contact us for volume pricing, lead-time commitments, and consignment options.
- Urgent MRO: Email [email protected] or call +0086 19859288691 for expedited sourcing.
- Cross-Reference / Substitution: If you need a functional equivalent or alternate brand, our engineering team can assist with selection.
Application-Specific FAQ
Q: Can the 050745-E1CB be used in a 24 V PLC-controlled conveyor system?
A: Yes — the motor is compatible with 24 V DC bus systems. Ensure your motor driver is rated for the stall current of this model and that the PLC output signal matches the driver’s input requirements.
Q: Is an encoder available for this motor?
A: MOTOR LINE offers encoder-equipped variants in the same series. Contact Konmask.com to confirm availability of encoder options for the 050745 platform.
Q: What is the expected service life?
A: DC gear motors in this class are typically rated for thousands of operating hours under nominal load. Actual life depends on duty cycle, load, and ambient temperature. Refer to the MOTOR LINE datasheet for MTBF data.
Q: Can I get a datasheet or 3D model?
A: Yes — email [email protected] with your part number and we will provide available documentation.
Q: Do you offer warranty on this component?
A: Konmask.com provides a standard warranty against manufacturing defects. Contact us for terms applicable to your order quantity and use case.
