NORDAC SK700E-112-340-A-GBB-EL 11kW Inverter | Replacement, Equivalent & Selection Guide
The NORDAC SK700E-112-340-A-GBB-EL is a high-performance AC variable frequency drive (VFD) manufactured by Nord Drivesystems (NORDAC). Designed for demanding industrial motor control applications, this unit delivers reliable, energy-efficient speed regulation for 3-phase induction motors. At Konmask.com, we supply genuine and verified-equivalent units with full traceability documentation.
Technical Specifications
- Model / SKU: SK700E-112-340-A-GBB-EL
- Brand: NORDAC (Nord Drivesystems)
- Series: SK 700E
- Rated Power: 11 kW (15 HP)
- Input Voltage: 3-phase, 340 V AC (±10%)
- Output Frequency: 0 – 400 Hz
- Control Mode: V/f, Sensorless Vector Control
- Protection Class: IP55 (standard enclosure)
- Communication: Integrated fieldbus options (GBB = built-in bus)
- Braking: Built-in braking transistor (EL suffix)
- Weight: approx. 7.5 kg
- Certifications: CE, UL (series-level)
Compatible Replacement & Equivalent Models
If the SK700E-112-340-A-GBB-EL is unavailable or discontinued, the following models may serve as functional equivalents depending on your system configuration. Always verify electrical and mechanical compatibility before substitution.
- NORDAC SK700E-112-340-A – Base variant without integrated bus; requires external fieldbus adapter
- NORDAC SK750E-112-340-A – Next-generation SK 750E series; enhanced EMC and expanded I/O
- NORDAC FLEX SK 200E-112-340-A – Compact decentralized drive; suitable for distributed architectures
- Siemens SINAMICS G120 PM240-2 11kW – Cross-brand equivalent; requires parameter re-mapping
- ABB ACS580-01-023A-4 – 11kW 400V class; compatible for general pump/fan/conveyor duty
Note: Cross-brand replacements require full parameter audit. Contact our engineering team for a compatibility assessment.
Why Choose the Original Model
- Drop-in Compatibility: Identical mounting footprint and terminal layout — no panel modification required
- Parameter Retention: Existing drive parameters can be cloned directly via NORDAC ACCESS software
- Integrated Fieldbus (GBB): Eliminates the need for an external bus module, reducing wiring complexity
- Built-in Braking Transistor (EL): Supports dynamic braking without additional hardware
- Proven Reliability: SK 700E series has a documented MTBF exceeding 50,000 hours in continuous duty
- OEM Spare Part Compliance: Meets OEM spare part specifications for Nord-driven machinery
Typical Applications
- Conveyor and material handling systems
- Pump and fan speed control (HVAC, water treatment)
- Compressor and blower drives
- Packaging and filling machinery
- Textile and printing equipment
- Crane and hoist applications (with appropriate braking resistor)
- Food & beverage processing lines
System Compatibility
- Motor Types: Standard 3-phase asynchronous induction motors, IE2/IE3 efficiency class
- Fieldbus Protocols (GBB): PROFIBUS DP, CANopen, DeviceNet, Modbus RTU (module-dependent)
- Control Interfaces: Analog 0–10V / 4–20mA, digital I/O, relay outputs
- Braking Resistors: Compatible with Nord external braking resistors (SK BRW series)
- Software: NORDAC ACCESS (parameter backup, diagnostics, firmware update)
- PLC Integration: Siemens S7, Beckhoff TwinCAT, Mitsubishi MELSEC via fieldbus
Selection Guide
Use the following criteria to confirm the SK700E-112-340-A-GBB-EL is the correct drive for your application:
- Motor Power: Confirm motor nameplate rating ≤ 11 kW
- Supply Voltage: Verify 3-phase 340 V AC supply (suitable for 380V systems with ±10% tolerance)
- Fieldbus Requirement: GBB suffix confirms integrated bus — specify your protocol when ordering
- Braking Duty: EL suffix = built-in braking transistor; add external resistor for high-inertia loads
- Enclosure: IP55 standard; confirm suitability for your installation environment
- Ambient Temperature: Operating range 0°C to +40°C (derate above 40°C)
Not sure which model fits your system? Send us your motor nameplate data and we will confirm compatibility within 24 hours.
Quality Assurance & Sourcing
- Verified Supply Chain: All units sourced from authorized Nord distributors or certified industrial surplus channels
- 4-Step Inspection: Visual inspection → Functional power-on test → Parameter read-back → Packaging integrity check
- Documentation: Serial number traceability, test report, and certificate of conformity provided on request
- Warranty: 12-month warranty against manufacturing defects; DOA replacement within 7 days
- Anti-Counterfeit: Holographic label verification and Nord factory serial number cross-check
How to Order
- Confirm model number: SK700E-112-340-A-GBB-EL
- Specify quantity and required delivery timeline
- Request a formal quotation via support@konmask.com or WhatsApp +0086 19859288691
- Receive proforma invoice with lead time confirmation
- Payment → Quality inspection → Worldwide shipping with tracking
We support DHL / FedEx / UPS Express and sea freight for bulk orders. Export documentation (commercial invoice, packing list, CO) included.
Replacement & Compatibility FAQ
Q: Can I replace SK700E-112-340-A-GBB-EL with SK750E series?
A: Yes, the SK 750E is the successor series. Mounting dimensions are compatible but parameter migration via NORDAC ACCESS is required. Contact us for a migration checklist.
Q: Is the GBB fieldbus module removable or integrated?
A: The GBB suffix indicates an integrated fieldbus interface. It is not a removable module — the bus interface is built into the drive’s control board.
Q: What does the EL suffix mean?
A: EL indicates a built-in braking transistor. You still need to connect an external braking resistor for dynamic braking; the transistor is internal but the resistor is external.
Q: Do you supply new or refurbished units?
A: We supply both. All units — new or refurbished — pass our 4-step inspection. Condition is clearly stated on the quotation and invoice.
Q: Can you supply the matching Nord gearmotor?
A: Yes. We stock a wide range of Nord SK series gearmotors. Provide your torque and speed requirements and we will recommend a matched drive-motor set.
