Genuine Omron CS1W-FLN22 FL-net Communication Unit | CS1 Series – Verified Source
The Omron CS1W-FLN22 is an FL-net (OPCN-2) communication unit designed for the CS1 Series Programmable Controller platform. Sourced through verified supply channels, every unit shipped by Konmask.com undergoes rigorous authenticity and functional checks before dispatch — giving industrial buyers the confidence they need for mission-critical automation projects.
Technical Specifications
| Attribute | Detail |
|---|---|
| Part Number | CS1W-FLN22 |
| Brand | Omron |
| Series | CS1 / CJ1 Compatible |
| Module Type | FL-net (OPCN-2) Communication Unit |
| Network Standard | FL-net (OPCN-2), IEEE 802.3 Ethernet-based |
| Transmission Speed | 10 Mbps |
| Max Nodes | 254 nodes per network |
| Cyclic Data Area | Word area: 512 words; Bit area: 8192 bits |
| Message Communication | Supported (token-passing protocol) |
| Connector | RJ-45 (10BASE-T) |
| Power Consumption | 5 VDC, 0.49 A (from backplane) |
| Operating Temperature | 0 °C to 55 °C |
| Storage Temperature | -20 °C to 75 °C |
| Humidity | 10% to 90% RH (non-condensing) |
| Weight | Approx. 200 g |
| Compliance | CE, UL, cUL |
Our 4-Step Quality Verification Process
Every Omron CS1W-FLN22 unit sold by Konmask.com passes through a documented 4-step verification process before shipment:
- Step 1 — Source Authentication: Units are procured exclusively from authorized distributors, certified resellers, or verified OEM surplus channels. All supply documentation is retained on file.
- Step 2 — Physical Inspection: Each unit is inspected for label integrity, housing condition, connector quality, and correct firmware/revision markings. Counterfeit indicators are cross-checked against Omron’s published authenticity guidelines.
- Step 3 — Functional Bench Test: Where applicable, units are powered up and communication parameters are verified. LED status indicators, network handshake behavior, and self-diagnostic outputs are confirmed.
- Step 4 — Packaging & Documentation Review: Original packaging, manuals, and accessories are verified for completeness. Units are repackaged in anti-static, shock-resistant materials for safe international transit.
Key Features & Benefits
- FL-net (OPCN-2) open-standard protocol — interoperable with multi-vendor factory networks
- High-speed cyclic data exchange with deterministic timing for real-time control
- Supports both cyclic (area) and message (acyclic) communication modes
- Easy integration into existing CS1 backplane — no external power supply required
- Robust industrial-grade design rated for continuous 24/7 operation
- Compatible with Omron CX-Programmer and CX-Integrator for seamless configuration
- Genuine Omron firmware — no third-party modifications
Typical Applications
- Automotive assembly line control and inter-PLC coordination
- Food & beverage processing with distributed I/O networks
- Semiconductor and electronics manufacturing automation
- Building automation and HVAC control systems
- Water treatment and utility infrastructure SCADA integration
- Pharmaceutical batch processing with multi-node synchronization
- Intralogistics and conveyor system coordination
Compatible System Components
The CS1W-FLN22 is designed for use within the Omron CS1 Series ecosystem. Verified compatible components include:
- CPU Units: CS1G-CPU42H, CS1G-CPU43H, CS1G-CPU44H, CS1G-CPU45H, CS1H-CPU63H, CS1H-CPU64H, CS1H-CPU65H, CS1H-CPU66H, CS1H-CPU67H
- Power Supply Units: CS1W-PA204, CS1W-PA204S, CS1W-PD024
- Backplane Units: CS1W-BC023, CS1W-BC033, CS1W-BC053, CS1W-BC083, CS1W-BC103
- Programming Software: CX-Programmer v9.x+, CX-Integrator v2.x+
- Network Infrastructure: Standard 10BASE-T Ethernet switches (unmanaged or managed)
Global Sourcing & Shipping Capabilities
- Stock Availability: In-stock and ex-stock units available for immediate dispatch; long-lead items sourced on request with lead-time confirmation within 24 hours
- Shipping Origins: Shenzhen, China (primary); Hong Kong (express routing); EU/US partner warehouses for select regions
- Carriers: DHL Express, FedEx International Priority, UPS Worldwide, TNT — with full tracking and insurance
- Export Compliance: All shipments include commercial invoice, packing list, and certificate of origin. HS Code: 8537.10 (programmable controllers/communication units)
- Lead Time: In-stock orders typically ship within 1–3 business days. Custom sourcing: 5–15 business days depending on region
- Minimum Order: 1 unit (no MOQ restriction for standard orders)
Certifications & Compliance Statement
The Omron CS1W-FLN22 carries the following certifications as issued by Omron Corporation:
- CE Marking — Compliant with EU EMC Directive (2014/30/EU) and Low Voltage Directive (2014/35/EU)
- UL / cUL Listed — Recognized under UL 508 (Industrial Control Equipment)
- FL-net (OPCN-2) Certified — Conformance tested per JEMA FL-net specification
- RoHS Compliant — Restriction of Hazardous Substances Directive 2011/65/EU
Konmask.com does not modify, re-label, or alter any certification markings. All compliance documentation reflects the original Omron factory specification.
How to Order
- Add to Cart — Select quantity and click “Add to Cart” or “Buy Now” for immediate checkout.
- Request a Quote — For bulk orders (5+ units), OEM projects, or custom sourcing requirements, email support@konmask.com with your part number, quantity, and required delivery date.
- Payment Methods — We accept T/T (bank wire), PayPal, credit card (Visa/Mastercard), and LC at sight for large orders.
- Order Confirmation — You will receive a proforma invoice and stock confirmation within 4 business hours of inquiry.
- Shipping Notification — Tracking number and export documents are provided upon dispatch.
Authenticity & Trust FAQ
- Q: How do I know the CS1W-FLN22 I receive is genuine Omron?
- A: Every unit is sourced from documented supply channels and passes our 4-step verification process. We provide supply chain documentation upon request for enterprise and OEM buyers.
- Q: Do you offer a warranty?
- A: Yes. All units carry a minimum 90-day functional warranty from date of shipment. Extended warranty options are available — contact us for details.
- Q: Can I return a unit if it does not match specifications?
- A: Absolutely. We offer a 30-day return policy for units that do not match the advertised specification or arrive in non-functional condition. Return shipping is covered by Konmask for verified defects.
- Q: Do you supply to system integrators and OEMs?
- A: Yes. We regularly supply to system integrators, panel builders, and OEM manufacturers across Asia, Europe, and the Americas. Volume pricing and blanket order arrangements are available.
- Q: Is the CS1W-FLN22 still in production?
- A: Please contact us to confirm current production status and availability. We maintain access to both current-production and certified surplus stock to support legacy system maintenance.
- Q: Can you provide a Certificate of Conformance (CoC)?
- A: Yes. A CoC can be issued upon request for orders of 3 units or more. Please specify this requirement at the time of order.
