Omron CP1W-40EDT1 Digital Expansion Unit – CP1W Series I/O Expansion Module
When a production line loses its I/O expansion module, the consequences are immediate and severe: PLCs lose contact with field devices, conveyor systems halt, robotic arms freeze mid-cycle, and entire manufacturing cells go dark. Downtime in modern industrial environments can cost thousands of dollars per minute — and sourcing a certified replacement quickly becomes the single most critical task on the floor. The Omron CP1W-40EDT1 is precisely the component that restores control, restores output, and gets your line running again.
Within the CP1W expansion series, the CP1W-40EDT1 occupies a high-density, NPN transistor output position — offering 24 digital inputs and 16 NPN transistor outputs in a single compact unit. Designed to integrate seamlessly with Omron’s CP1H and CP1L PLC families, this module is a globally recognized standard in discrete manufacturing, packaging automation, and machine tool control. Its transistor output architecture makes it the preferred choice for high-speed, high-cycle applications where relay outputs would degrade prematurely.
Technical Specifications
- Model: CP1W-40EDT1
- Manufacturer: Omron Corporation
- Series: CP1W Expansion I/O
- Compatible PLCs: CP1H, CP1L series
- Input Points: 24 digital inputs
- Output Points: 16 NPN transistor outputs (sink type)
- Total I/O Points: 40
- Input Voltage: 24 VDC
- Output Type: NPN open-collector transistor
- Output Current: 0.3 A per point
- Connection Method: Screw terminal block
- Mounting: DIN rail or direct panel mount via CP1W bus connector
- Operating Temperature: 0 to 55°C
- Storage Temperature: -20 to 75°C
- Dimensions (W×H×D): Refer to Omron official datasheet
- Weight: Approx. 100 g
- Certifications: CE, UL (verify with official Omron documentation)
Key Features & Benefits
- High-Density I/O in Compact Form: 40 I/O points in a single slim module reduces panel space requirements and simplifies wiring.
- NPN Transistor Outputs for High-Speed Switching: Transistor outputs support rapid on/off cycles without mechanical wear — ideal for pulse outputs, solenoid valves, and servo enable signals.
- Plug-and-Play CP1W Bus Integration: Connects directly to CP1H/CP1L CPU units via the proprietary expansion bus — no additional communication configuration required.
- Robust Industrial Design: Built to withstand vibration, electrical noise, and temperature variation typical of factory floor environments.
- Screw Terminal Connectivity: Reliable field wiring with standard screw terminals, compatible with common wire gauges used in industrial panels.
- Scalable Architecture: Multiple CP1W expansion units can be chained to the same CPU, allowing I/O expansion as machine complexity grows.
Industry & Equipment Applications
- Discrete Manufacturing: Assembly line control, part detection, conveyor sequencing
- Packaging Machinery: Filling machines, labeling systems, case erectors
- Machine Tools: CNC auxiliary I/O, spindle enable, coolant control
- Food & Beverage Processing: Valve control, sensor interfacing, batch sequencing
- Automotive Assembly: Fixture control, weld gun enable, part-present sensing
- Building Automation: HVAC control panels, access control integration
- Water Treatment: Pump control, level sensing, dosing system automation
System Integration & Compatible Parts
The CP1W-40EDT1 is designed for use within the Omron CP1 ecosystem. Typical system configurations include:
- Compatible CPU Units: CP1H-X40DR-A, CP1H-XA40DR-A, CP1L-M60DR-D, CP1L-L20DR-D, and other CP1H/CP1L variants
- Other CP1W Expansion Modules: CP1W-8ED (8-point input), CP1W-8ET (8-point NPN output), CP1W-AD041 (analog input), CP1W-DA021 (analog output)
- Programming Software: Omron CX-Programmer, Sysmac Studio (for compatible models)
- Power Supply: CP1W-PA205R or equivalent CP1W power supply unit
- Communication Options: Pair with CP1W-CIF01 (RS-232C) or CP1W-CIF11 (RS-422/485) for serial communication expansion
Our Quality Assurance Process
At Konmask.com, every Omron CP1W-40EDT1 unit we supply undergoes a structured verification process before shipment:
- Source Verification: Units are sourced from authorized distributors or verified surplus channels with full traceability documentation.
- Visual Inspection: Each unit is inspected for physical damage, label integrity, and connector condition.
- Authenticity Check: Holographic labels, serial number formats, and packaging are cross-referenced against Omron’s known genuine product standards.
- Functional Testing (where applicable): Select units undergo power-on and I/O point verification prior to dispatch.
- Secure Packaging: Anti-static packaging with moisture protection for safe international transit.
How to Order
- Submit your inquiry via the Contact / Request a Quote form on this page.
- Provide your required quantity, delivery timeline, and destination country.
- Our technical team will confirm availability, lead time, and pricing within 1 business day.
- Upon agreement, we issue a proforma invoice and arrange shipment via your preferred carrier (DHL, FedEx, UPS, or sea freight for bulk orders).
- Tracking information and shipping documents (commercial invoice, packing list) are provided upon dispatch.
📧 Email: support@konmask.com
📞 Phone/WhatsApp: +0086 19859288691
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation Components — PLC modules, DCS parts, servo drives, and HMI panels from leading global brands.
- ✅ B2B Inquiry-First Model — We serve OEMs, system integrators, MRO buyers, and plant engineers with volume pricing and technical support.
- ✅ Global Shipping — Reliable export logistics to Southeast Asia, the Middle East, Europe, and the Americas.
- ✅ Fast Response — Dedicated account managers respond to all inquiries within 24 hours.
- ✅ Competitive Pricing — Direct sourcing relationships allow us to offer market-competitive pricing on both new and surplus stock.
- ✅ Technical Expertise — Our team includes experienced automation engineers who can assist with compatibility, wiring, and system design questions.
Frequently Asked Questions
- Q: Is the CP1W-40EDT1 compatible with the CP1E series?
- A: No. The CP1W expansion bus is designed for CP1H and CP1L series PLCs. The CP1E series uses a different expansion architecture (CP1E expansion units). Please verify your CPU model before ordering.
- Q: What is the difference between CP1W-40EDT and CP1W-40EDT1?
- A: The CP1W-40EDT features PNP (source type) transistor outputs, while the CP1W-40EDT1 features NPN (sink type) transistor outputs. Selection depends on your field device wiring convention — NPN is more common in Asian markets, PNP in European applications.
- Q: How many CP1W-40EDT1 units can I connect to one CPU?
- A: The maximum number of expansion units depends on the specific CP1H or CP1L CPU model. Refer to the Omron CP1H/CP1L hardware manual for the expansion unit limit applicable to your CPU variant.
- Q: Do you provide a warranty on this product?
- A: Yes. We offer a standard warranty period on all units supplied. Specific warranty terms are confirmed at the time of order. Please contact us for details.
- Q: Can you supply in bulk quantities for a production project?
- A: Absolutely. We regularly fulfill bulk orders for system integrators and OEM manufacturers. Contact us with your project BOM for a consolidated quotation.
