Panasonic AFPX-C40R-F Compact PLC Control Unit – FP-X Series
Imagine a high-speed packaging line suddenly halting mid-shift, or a water treatment facility losing synchronized pump control — all because a single PLC control unit fails. In modern industrial environments, the programmable logic controller is the nerve center of every automated process. Without a reliable, spec-matched unit like the Panasonic AFPX-C40R-F, entire production lines grind to a halt, causing costly downtime, safety risks, and missed delivery commitments. This is precisely why sourcing the correct, verified replacement or expansion unit matters so much.
The AFPX-C40R-F is a flagship control unit within Panasonic’s renowned FP-X Series — one of the most widely deployed compact PLC families in global industrial automation. Offering 40 I/O points with relay output configuration, it strikes the ideal balance between processing power and physical footprint. Trusted by OEMs, system integrators, and plant engineers across Asia, Europe, and the Americas, the FP-X Series has established itself as a benchmark for reliability in discrete manufacturing, building automation, and process control applications.
Technical Specifications
- Model / SKU: AFPX-C40R-F
- Series: FP-X Series (Panasonic Industrial Devices SUNX)
- Unit Type: Compact PLC Control Unit
- Total I/O Points: 40 (24 Inputs / 16 Outputs)
- Output Type: Relay Output
- Program Capacity: 32,000 steps
- Processing Speed: 0.32 μs/step (basic instructions)
- Built-in Functions: High-speed counter, pulse output, PWM output
- Communication Ports: USB (programming), RS232C / RS485 (optional)
- Power Supply: 100–240 VAC
- Operating Temperature: 0°C to 55°C
- Weight: Approx. 4,460 g (unit with packaging)
- Compliance: CE, UL, cUL
Note: Specifications are based on Panasonic official documentation. Always verify against the latest datasheet for your application.
Key Features & Benefits
- High-Density I/O in Compact Form: 40 I/O points in a slim DIN-rail mountable housing — ideal for space-constrained control panels.
- Relay Output Versatility: Relay outputs provide robust switching for AC/DC loads, motors, solenoids, and indicator lamps without additional interface relays.
- Fast Scan Time: 0.32 μs per basic instruction ensures real-time responsiveness for high-speed machinery.
- Expandable Architecture: Supports FP-X expansion units to scale I/O as your system grows — no need to replace the base unit.
- Built-in Motion Control: Integrated pulse output and high-speed counter support basic positioning and encoder feedback without external modules.
- FPWIN Pro / GX Works Compatible: Programmed via Panasonic’s FPWIN Pro software, with IEC 61131-3 language support (Ladder, SFC, ST).
- Long Service Life: Panasonic’s industrial-grade components ensure MTBF performance suitable for 24/7 continuous operation.
Industry & Equipment Applications
- Packaging Machinery: Conveyor sequencing, labeling, filling, and capping line control.
- Food & Beverage Processing: Temperature-controlled mixing, batch processing, and CIP cycle management.
- Building Automation: HVAC control, lighting management, and access control integration.
- Water & Wastewater Treatment: Pump sequencing, level monitoring, and dosing control.
- Textile & Printing Equipment: Tension control, register mark detection, and web guiding.
- General Discrete Manufacturing: Assembly line interlocking, safety circuit integration, and production counting.
System Integration & Compatible Parts
The AFPX-C40R-F is designed to work seamlessly within the Panasonic FP-X ecosystem. Compatible and commonly paired components include:
- Expansion I/O Units: AFPX-E16R, AFPX-E30R, AFPX-E16T
- Communication Cassettes: AFPX-COM1 (RS232C), AFPX-COM2 (RS485), AFPX-COM5 (Ethernet)
- Analog I/O Cassettes: AFPX-A21, AFPX-A22
- Programming Cable: USB-miniUSB (standard)
- Software: FPWIN Pro 7 (IEC 61131-3 compliant)
If you need help identifying compatible expansion modules or communication options for your existing system, contact our technical team at support@konmask.com.
Our Quality Assurance Process
At Konmask.com, every Panasonic AFPX-C40R-F unit undergoes a rigorous multi-stage verification process before shipment:
- Authenticity Verification: Cross-referenced against Panasonic’s official part numbering and date code standards.
- Visual Inspection: Checked for physical damage, connector integrity, and label authenticity.
- Functional Pre-check: Power-on test and communication port verification where applicable.
- Secure Packaging: Anti-static packaging with moisture barrier and shock-absorbing materials for international transit.
- Documentation: Certificate of conformity and packing list included with every shipment.
How to Order
- Submit your inquiry via the “Get a Quote” button or email support@konmask.com.
- Provide your required quantity, delivery destination, and any urgency requirements.
- Receive a formal quotation within 1 business day.
- Confirm order and arrange payment via T/T, PayPal, or other agreed methods.
- Shipment dispatched within 3–7 business days; tracking number provided.
For urgent requirements or large-volume orders, please contact us directly at +0086 19859288691.
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation Components — PLC, DCS, HMI, servo drives, and more.
- ✅ Verified Authentic Parts — No counterfeits. Every unit traceable to authorized supply chains.
- ✅ Global B2B Export Experience — Serving engineers and procurement teams in 30+ countries.
- ✅ Technical Pre-Sales Support — Our engineers help you confirm compatibility before you buy.
- ✅ Competitive Lead Times — In-stock items ship within days; hard-to-find parts sourced on request.
- ✅ Flexible MOQ — Single units to bulk orders welcome.
Frequently Asked Questions
Q: Is the AFPX-C40R-F the same as the AFPX-C40R?
A: The “-F” suffix typically denotes a specific regional or firmware variant. Please confirm your existing system’s part number before ordering to ensure full compatibility.
Q: Can I expand the I/O beyond 40 points?
A: Yes. The FP-X series supports expansion units (e.g., AFPX-E16R, AFPX-E30R) that connect directly to the control unit to increase total I/O capacity.
Q: What programming software is required?
A: Panasonic FPWIN Pro 7 is the recommended programming environment. It supports IEC 61131-3 languages including Ladder Diagram (LD), Structured Text (ST), and Sequential Function Chart (SFC).
Q: Do you provide a warranty?
A: Yes. We offer a standard 90-day warranty against manufacturing defects. Extended warranty options are available for bulk orders.
Q: Can you source other FP-X Series models not listed on your site?
A: Absolutely. Contact us with your required part number and we will provide availability and pricing within 24 hours.
