Panasonic AFP2720 FP2-MW Memory Cassette – High-Capacity Program Storage | FP2 Series PLC Platform
Engineering Background
The Panasonic FP2 Series represents one of the most robust mid-to-large scale PLC platforms in industrial automation, widely deployed across Asia-Pacific and global manufacturing facilities since the 1990s. Engineered under the NAIS/Panasonic Industrial Devices brand, the FP2 architecture is renowned for its modular expandability, high-speed scan cycles, and long-term parts availability — making it a preferred backbone for continuous-process and discrete manufacturing alike.
Product Positioning
The AFP2720 is a dedicated Memory Cassette (FP2-MW) designed to extend or replace the internal program memory of FP2 CPU units. It enables engineers to store larger ladder/instruction list programs, retain data across power cycles without battery dependency, and facilitate rapid program transfer during maintenance or line changeover. For procurement engineers managing aging FP2 installations or executing system upgrades, the AFP2720 is a critical spare and a direct OEM-compatible replacement.
Complete Technical Specifications
| Part Number / SKU | AFP2720 |
| Series | FP2 Series |
| Module Type | Memory Cassette (FP2-MW) |
| Manufacturer | Panasonic Industrial Devices (NAIS) |
| Country of Origin | Japan |
| Compatible CPU Units | FP2 Series CPU modules (AFP2211, AFP2212, AFP2311, AFP2411, AFP2431, AFP2432, etc.) |
| Memory Type | Flash / EEPROM non-volatile memory cassette |
| Program Capacity | Refer to FP2 CPU datasheet for cassette-specific capacity mapping |
| Data Retention | Non-volatile; retains program without battery backup |
| Interface | Direct plug-in to FP2 CPU memory cassette slot |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -20 °C to +70 °C |
| Humidity | 10 % to 90 % RH (non-condensing) |
| Vibration Resistance | Per IEC 61131-2 standard |
| Approvals / Standards | CE, UL (per FP2 platform certification) |
| Weight | Approx. 4.46 kg (packaged) |
| Programming Software | FPWIN Pro / FPWIN GR (Panasonic) |
Proven Application Environments
- Automotive Assembly Lines – Program storage for multi-station transfer lines requiring zero-battery maintenance
- Food & Beverage Processing – Hygienic environments where battery replacement is restricted; non-volatile memory eliminates risk
- Semiconductor Fabrication – Clean-room compatible; supports rapid recipe changeover via memory swap
- Textile & Printing Machinery – Long-run production with infrequent but critical program updates
- Water Treatment & Utilities – 24/7 continuous operation; eliminates program loss risk during power outages
- MRO & Spare Parts Management – Pre-programmed cassettes as hot-swap spares to minimize downtime
Engineering Advantages
- Battery-Free Retention – Flash/EEPROM architecture eliminates battery maintenance schedules and associated failure modes
- Rapid Program Transfer – Plug-and-play cassette swap enables sub-minute CPU program restoration during field maintenance
- OEM Direct Compatibility – Genuine Panasonic part; no firmware adaptation or compatibility risk with FP2 CPU units
- Long Service Life – Designed for industrial duty cycles; rated for thousands of write cycles with data integrity
- Compact Form Factor – Mounts directly inside CPU housing; no external wiring or mounting hardware required
- FPWIN Pro Integration – Fully supported by Panasonic’s current programming environment for seamless upload/download
System Architecture & Signal Flow
The AFP2720 integrates directly into the FP2 CPU’s internal memory cassette bay. Upon power-up, the FP2 CPU automatically detects and loads the program stored on the cassette into execution memory. The signal/data flow is as follows:
- Program Development → FPWIN Pro on engineering workstation
- Download → Via RS232C / USB programming port to FP2 CPU
- Storage → CPU writes program to AFP2720 cassette (non-volatile)
- Execution → On power cycle, CPU loads from cassette → executes scan cycle
- Backup / Transfer → Cassette removed → inserted into replacement CPU → instant program restore
This architecture is particularly valuable in multi-machine environments where standardized program versions must be maintained across identical production cells.
Sourcing & Quality Verification
- Source: Procured through verified Panasonic authorized distribution channels and certified industrial surplus networks
- Inspection: Each unit undergoes visual inspection, label verification, and functional pre-shipment check
- Authenticity: Genuine OEM part with original Panasonic markings; counterfeit screening applied
- Condition: New or refurbished-to-spec; condition disclosed at order confirmation
- Packaging: Anti-static ESD packaging with desiccant; suitable for international air/sea freight
- Documentation: Certificate of conformance and packing list provided upon request
Procurement Process
- Inquiry – Submit your part number (AFP2720) and required quantity via email or the contact form
- Quote – Receive a formal quotation with lead time, unit price, and shipping options within 24 hours
- Order Confirmation – Purchase order or online checkout; proforma invoice issued for wire transfer if required
- Quality Check – Pre-shipment inspection completed; photos provided on request
- Shipment – DHL / FedEx / EMS with full tracking; export documentation (commercial invoice, packing list, COO) included
- After-Sales – 30-day return policy for DOA units; technical support available via email
Technical FAQ
Q: Is the AFP2720 compatible with all FP2 CPU models?
A: The AFP2720 is designed for the FP2 Series platform. Compatibility depends on the specific CPU model and firmware version. Please confirm your CPU part number before ordering — our engineers will verify compatibility at no charge.
Q: Does the AFP2720 require any special tools for installation?
A: No. The cassette is a tool-free plug-in module. Power down the CPU, insert the cassette into the designated slot, and power up. The CPU auto-detects the cassette on boot.
Q: Can I use the AFP2720 to clone programs across multiple FP2 CPUs?
A: Yes. This is one of the primary use cases. Write the program to the cassette via FPWIN Pro, then physically transfer the cassette to each target CPU for rapid, identical program deployment.
Q: What is the write endurance of the memory cassette?
A: Flash/EEPROM memory in industrial cassettes is rated for a minimum of 100,000 write cycles under standard conditions, far exceeding typical PLC programming frequency.
Q: Do you provide a warranty?
A: Yes. We offer a 30-day DOA (Dead on Arrival) warranty. Extended warranty options are available for volume orders. Contact us for details.
Q: Can you supply multiple units or arrange blanket orders?
A: Yes. We support single-unit spot buys and multi-unit blanket purchase agreements. Volume pricing is available for orders of 5+ units.
