PANASONIC MSD5AZA1Y AC Servo Driver 500W Single-Phase 200V – MINAS A5 Series
When a servo driver fails on the production line, the consequences are immediate and costly: conveyor systems halt, robotic arms freeze mid-cycle, CNC spindles lose position feedback, and entire manufacturing cells go dark. Every minute of unplanned downtime translates directly into lost output, missed delivery windows, and escalating maintenance costs. The PANASONIC MSD5AZA1Y AC Servo Driver is the precision motion control component that keeps these critical systems running — delivering reliable, high-response torque control that modern automated production demands.
Within the MINAS A5 Series — Panasonic’s flagship line of high-performance AC servo systems — the MSD5AZA1Y occupies the 500W single-phase 200V tier, making it the preferred choice for mid-range axis control in compact machine designs. The MINAS A5 platform is globally recognized for its industry-leading frequency response of 2.0 kHz, full closed-loop compatibility, and seamless integration with Panasonic’s RTEX and EtherCAT network architectures. This model is deployed across thousands of installations in Asia, Europe, and North America, underpinning everything from semiconductor handling equipment to precision packaging lines.
Technical Specifications
- Model Number: MSD5AZA1Y
- Brand: PANASONIC (Panasonic Industry Co., Ltd.)
- Series: MINAS A5
- Rated Output Power: 500W
- Input Voltage: Single-Phase AC 200–240V, 50/60Hz
- Control Method: IGBT PWM Sinusoidal Drive
- Encoder Compatibility: 20-bit Incremental / Absolute Encoder
- Frequency Response: 2.0 kHz (industry-leading)
- Communication Interface: RTEX (Real-Time Express) / Pulse Train
- Protection Functions: Overcurrent, Overvoltage, Undervoltage, Overload, Encoder Error, Regeneration Error
- Ambient Operating Temperature: 0°C to 55°C
- Storage Temperature: -20°C to 65°C
- Cooling Method: Natural Convection / Forced Air
- Weight: Approx. 1.36 kg
- Compliance: CE, UL, RoHS
Key Features & Benefits
- 2.0 kHz Frequency Response: Enables ultra-fast position and velocity loop closure, critical for high-speed pick-and-place and precision cutting applications.
- Full Closed-Loop Control: Supports external linear scale feedback for nanometer-level positioning accuracy in semiconductor and optical equipment.
- Auto-Tuning (Real-Time): Adaptive gain tuning automatically compensates for load inertia changes, reducing commissioning time significantly.
- Vibration Suppression: Built-in notch filter and damping control minimize mechanical resonance in long-arm or belt-driven systems.
- Compact Form Factor: Space-saving design allows dense multi-axis panel layouts without sacrificing thermal performance.
- Safe Torque Off (STO): IEC 61800-5-2 compliant safety function for integration into safety-rated machine designs.
- Rich I/O: Configurable digital inputs/outputs support complex sequencing logic without external PLCs for simple applications.
Industry & Equipment Applications
- Electronics Manufacturing: SMT pick-and-place machines, PCB drilling, AOI inspection gantries
- Semiconductor Equipment: Wafer handling robots, die bonding, wire bonding systems
- Packaging Machinery: Horizontal flow wrappers, cartoning machines, labeling systems
- CNC Machine Tools: Milling centers, grinding machines, EDM axis drives
- Printing & Converting: Web tension control, register mark tracking, slitter-rewinders
- Medical Devices: Diagnostic imaging positioners, surgical robot joints, infusion pump drives
- Textile Machinery: Yarn tension control, warp beam drives, knitting machine feeders
System Integration & Compatible Parts
The MSD5AZA1Y is designed for seamless integration within the Panasonic MINAS A5 ecosystem. Compatible and commonly paired components include:
- Servo Motors: MSMF042L1U2M, MSMF082L1U2M, MQMF042L1U2M (500W class MINAS A5 motors)
- Regenerative Resistors: DV0P4283 (external braking resistor for high-duty-cycle applications)
- Cables: MFECA0030EAM (encoder cable), MFMCA0030EAM (motor power cable)
- Communication Cards: RTEX network master cards for multi-axis synchronization
- PLC Controllers: Compatible with Panasonic FP-X, FP0R series; also integrates with Mitsubishi Q/iQ-R, Siemens S7-1500 via pulse/analog interface
- Safety Modules: Compatible with Pilz PNOZ, Sick safety relays for STO circuit wiring
Our Quality Assurance Process
At Konmask.com, every PANASONIC MSD5AZA1Y unit undergoes a rigorous multi-stage verification process before shipment:
- Source Verification: Units are sourced exclusively from authorized distributors and verified original-manufacturer channels. Counterfeit screening is performed on every batch.
- Visual Inspection: Full exterior inspection for label integrity, connector condition, housing damage, and date code consistency.
- Functional Pre-Check: Where applicable, power-on verification and parameter read-back are performed to confirm firmware and hardware integrity.
- Packaging: Anti-static ESD bags, foam-lined cartons, and moisture-barrier packaging ensure safe transit to any global destination.
- Documentation: Each shipment includes a packing list, inspection record, and certificate of conformity upon request.
How to Order
- Submit your inquiry via the Contact / Request a Quote form on this page, specifying model MSD5AZA1Y and required quantity.
- Our technical sales team will respond within 1 business day with availability, lead time, and a formal quotation.
- Upon PO confirmation, we arrange payment (T/T, L/C, or agreed terms) and prepare export documentation.
- Shipment via DHL, FedEx, UPS, or sea freight — with full tracking provided.
- After-sales technical support available for installation and commissioning questions.
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation Components — PLC, DCS, servo systems, HMI, and drives from 200+ global brands
- ✅ Genuine Parts Guaranteed — Strict anti-counterfeit sourcing with full traceability
- ✅ Global Export Experience — Serving customers in 60+ countries with compliant export documentation
- ✅ Technical Expertise — Our team includes certified automation engineers who can advise on compatibility and integration
- ✅ Fast Response — Quotations within 24 hours, urgent orders prioritized
- ✅ Flexible MOQ — Single-unit orders accepted; volume pricing available for OEM/MRO procurement
Frequently Asked Questions
Q: Is the PANASONIC MSD5AZA1Y compatible with third-party servo motors?
A: The MSD5AZA1Y is optimized for use with Panasonic MINAS A5 series servo motors. While pulse-train control mode allows connection to some third-party motors, full performance and safety features require matched Panasonic motors with compatible 20-bit encoders.
Q: What is the difference between MSD5AZA1Y and MSD5A3A1Y?
A: Both are 500W MINAS A5 drivers. The MSD5AZA1Y supports RTEX network communication, while the MSD5A3A1Y is a pulse-train-only variant. Choose MSD5AZA1Y for multi-axis network synchronization applications.
Q: Can this driver be used with 110V single-phase input?
A: No. The MSD5AZA1Y is rated for single-phase AC 200–240V input only. For 100–120V applications, please inquire about the appropriate MINAS A5 variant.
Q: Do you provide the Panasonic PANATERM setup software?
A: Yes, we can provide guidance on obtaining PANATERM software and USB setup cables (DV0P4460) for parameter configuration. Please mention this in your inquiry.
Q: What is the typical lead time for MSD5AZA1Y?
A: Stock availability varies. In-stock units ship within 3–5 business days. For non-stock orders, lead time is typically 2–4 weeks. Contact us for real-time availability.
Q: Do you offer warranty on this product?
A: Yes. We offer a 12-month warranty against manufacturing defects on all genuine units. Warranty claims are handled directly by our technical team.
