Phoenix Contact IBS ST ME 24-BK-T – Inline Bus Terminal Module | INTERBUS Platform
Engineering Background: The INTERBUS (IBS) inline system from Phoenix Contact is a proven fieldbus architecture widely deployed in discrete manufacturing, process automation, and machine-building applications across Europe and Asia-Pacific. The IBS ST ME 24-BK-T serves as a critical bus terminal node within the inline station, providing the electrical and logical interface between the INTERBUS remote bus and the local I/O modules.
Product Positioning: Part number 2754367 is the OEM-designated inline bus terminal module for 24 VDC INTERBUS stations. It is the mandatory head-of-station component that manages bus communication, power distribution, and diagnostic signaling for all downstream inline I/O modules. Procurement engineers specifying INTERBUS expansions or executing like-for-like replacements will find this module essential for maintaining system continuity without re-engineering the station architecture.
Complete Technical Specifications
- Manufacturer: Phoenix Contact GmbH & Co. KG
- Part Number (OEM): 2754367
- Model: IBS ST ME 24-BK-T
- Series / Platform: INTERBUS Inline (IBS ST)
- Function: Inline Bus Terminal – INTERBUS remote bus interface & station head
- Supply Voltage: 24 V DC (nominal)
- Voltage Range: 19.2 V DC … 30 V DC
- Current Consumption (Logic): Typ. 100 mA @ 24 V DC
- INTERBUS Data Rate: 500 kbps (fixed)
- Remote Bus Connection: 9-pin D-Sub (RS-485 differential)
- Local Bus Interface: Inline connector system (proprietary Phoenix Contact)
- Max. I/O Modules per Station: Up to 63 inline modules
- Process Data Width: Up to 512 bytes I/O
- Diagnostic LEDs: PWR, BF (Bus Fault), RD (Remote Disable), BA (Bus Active)
- Mounting: DIN rail EN 60715 (35 mm)
- Protection Class: IP 20
- Operating Temperature: -25 °C … +55 °C
- Storage Temperature: -25 °C … +85 °C
- Relative Humidity: 5 % … 95 % (non-condensing)
- Dimensions (W × H × D): Approx. 12.2 mm × 120 mm × 71.5 mm
- Weight: Approx. 200 g
- Certifications: CE, UL, cUL, ATEX (refer to datasheet for specific approvals)
- RoHS Compliance: Yes
Proven Application Environments
- Automotive Assembly Lines: Body-in-white welding stations and transfer lines using INTERBUS as the primary fieldbus backbone.
- Packaging Machinery: High-speed form-fill-seal and cartoning machines requiring deterministic I/O response times.
- Semiconductor Fab Equipment: Cleanroom-compatible distributed I/O stations where compact inline form factor is mandatory.
- Water & Wastewater Treatment: Remote pump and valve control panels with extended cable runs leveraging INTERBUS RS-485 topology.
- Machine Tool & CNC: Retrofit and expansion of existing INTERBUS-based CNC machining centers without PLC reprogramming.
- MRO & Spare Parts Inventory: Direct like-for-like replacement for failed bus terminal modules to minimize unplanned downtime.
Engineering Advantages
- Zero Re-Engineering: Drop-in OEM replacement — same part number, same pinout, same firmware behavior. No PLC program changes required.
- Deterministic Communication: INTERBUS ring topology guarantees fixed cycle times, critical for motion-synchronized I/O applications.
- Compact Inline Form Factor: 12.2 mm width minimizes panel footprint while supporting up to 63 downstream I/O modules per station.
- Integrated Diagnostics: Four onboard LEDs provide immediate fault isolation — bus fault, remote disable, and power status visible without tooling.
- Wide Temperature Range: -25 °C to +55 °C operating range supports outdoor enclosures and unheated industrial environments.
- Long Product Lifecycle: Phoenix Contact maintains INTERBUS inline compatibility across generations, protecting existing infrastructure investments.
System Architecture & Signal Flow
The IBS ST ME 24-BK-T occupies the head position of an INTERBUS inline station. The remote bus (RS-485, 9-pin D-Sub) connects upstream to the INTERBUS master controller (e.g., Phoenix Contact IBS SYS or third-party INTERBUS master cards). The module decodes the INTERBUS frame, extracts local process data, and distributes it across the inline local bus to downstream I/O modules via the proprietary inline connector. Power (24 V DC) is fed through the terminal’s power connector and distributed to the logic rail of all connected inline modules. The -T suffix denotes the terminal block variant, providing screw-clamp field wiring connections directly on the bus terminal body.
Sourcing & Quality Verification
- Origin: Sourced from authorized Phoenix Contact distribution channels and verified OEM surplus inventory.
- Inspection: Each unit undergoes visual inspection for label integrity, connector condition, and housing damage prior to shipment.
- Part Number Verification: OEM label with part number 2754367 confirmed on every unit — cross-referenced against Phoenix Contact’s official product catalog.
- Packaging: Anti-static bag + foam-lined carton. ESD-safe handling throughout the fulfillment process.
- Warranty: 90-day functional warranty against defects in materials and workmanship.
Procurement Process
- Confirm Part Number: Verify 2754367 against your existing module label or Phoenix Contact documentation before ordering.
- Request Quote: Contact [email protected] for volume pricing, lead time confirmation, and export documentation (CO, packing list, commercial invoice).
- Place Order: Secure checkout via Konmask.com. Payment terms available for qualified B2B accounts.
- Shipping: DHL Express / FedEx International Priority standard. EXW Xiamen available for freight forwarder arrangements.
- Receive & Verify: Inspect OEM label and part number upon receipt. Contact us within 7 days for any discrepancy resolution.
Technical FAQ
Q: Is the IBS ST ME 24-BK-T compatible with all Phoenix Contact INTERBUS masters?
A: Yes. It is compatible with all Phoenix Contact INTERBUS master controllers (IBS SYS series, IBS PCI SC/I-T, etc.) and third-party INTERBUS masters conforming to the IEC 61158 / EN 50254 standard.
Q: Can this module be used with non-Phoenix Contact inline I/O modules?
A: No. The inline local bus uses a proprietary Phoenix Contact connector and protocol. Only Phoenix Contact inline I/O modules are compatible downstream.
Q: What does the -T suffix indicate?
A: The -T suffix designates the terminal block (screw-clamp) field wiring variant, as opposed to spring-cage or push-in connection variants.
Q: Is firmware update required after replacement?
A: No firmware update is required. The IBS ST ME 24-BK-T is a hardware module; configuration is managed by the INTERBUS master controller, not the terminal module itself.
Q: Do you provide a Certificate of Conformance (CoC)?
A: Yes, a CoC is available upon request for orders of 5 units or more. Contact [email protected].
