Industrial Ethernet Networking Solution – Allen-Bradley 1783-BMS10CGN | Stratix 2000 Series
Where This Product Is Used
The Allen-Bradley 1783-BMS10CGN is a 10-port copper unmanaged Ethernet switch from the Stratix 2000 series, engineered for deterministic, high-reliability communication in industrial control environments. Typical deployment scenarios include:
- PLC Network Segments – Connecting ControlLogix, CompactLogix, and MicroLogix controllers to I/O modules, HMIs, and drives on a dedicated Ethernet segment.
- SCADA & DCS Integration – Bridging field-level devices to supervisory control systems in oil & gas, water treatment, and power generation plants.
- Machine Builder / OEM Panels – Providing plug-and-play Ethernet connectivity inside control cabinets where managed switching is unnecessary overhead.
- Conveyor & Material Handling Lines – Linking distributed motor drives, sensors, and safety relays along production lines.
- Automotive & Discrete Manufacturing – Supporting EtherNet/IP device-level ring (DLR) star topology segments in body-shop and assembly automation.
- Food & Beverage Processing – Washdown-adjacent panel installations requiring compact DIN-rail footprint and robust EMI tolerance.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number (SKU) | 1783-BMS10CGN |
| Series | Stratix 2000 |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Switch Type | Unmanaged |
| Total Ports | 10 × RJ45 Copper |
| Port Speed | 10/100 Mbps Auto-Negotiation |
| Protocol Support | EtherNet/IP, Modbus TCP, PROFINET (pass-through) |
| Mounting | DIN Rail (35 mm) |
| Input Voltage | 24 V DC (18–30 V DC) |
| Power Consumption | ≤ 4.5 W (typical) |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | −40 °C to +85 °C |
| Relative Humidity | 5–95 % (non-condensing) |
| Dimensions (H × W × D) | Approx. 100 × 75 × 55 mm |
| Weight | 1,560 g (with packaging) |
| Enclosure Rating | IP20 (panel-mount) |
| Certifications | UL 508, CE, cULus, RCM |
Why Engineers Specify This Model
- Zero-Configuration Deployment – No IP addressing or VLAN setup required; plug in and the switch is operational within seconds, reducing commissioning time on the plant floor.
- Rockwell Ecosystem Native – Designed alongside Studio 5000 / RSLogix 5000 architectures; fully validated for EtherNet/IP traffic patterns generated by Allen-Bradley PLCs and drives.
- Compact DIN-Rail Form Factor – Fits inside standard 24 V DC control panels without requiring additional mounting hardware or panel cutouts.
- Store-and-Forward Architecture – Eliminates runt frames and collision domains, protecting sensitive PLC I/O scan cycles from network noise.
- Wide DC Input Range – Accepts 18–30 V DC, tolerating voltage sag common in large panel power supplies during motor starts.
- Long Product Lifecycle – Rockwell Automation’s Stratix 2000 line carries extended lifecycle commitments, reducing obsolescence risk for long-running machine programs.
Complete System Bill of Materials
The following complementary components are commonly ordered alongside the 1783-BMS10CGN to complete an EtherNet/IP network segment:
- 1783-BMS10CGP – Stratix 2000 10-port copper switch with PoE (powers IP cameras or wireless APs)
- 1783-BMS06SA – Stratix 2000 6-port copper + 2-port SFP fiber uplink switch
- 1585J-M8CBJM-2 – Allen-Bradley EtherNet/IP patch cable, M12 to RJ45, 2 m
- 1606-XLP95E – Allen-Bradley 95 W 24 V DC power supply for panel feed
- 1492-CABLE010A – DIN rail terminal block wiring kit for 24 V DC distribution
- 9300-ENA – EtherNet/IP network adapter for legacy serial devices
Compliance & Industry Standards
- UL 508 – Industrial Control Equipment
- IEC 61131-2 – Programmable Controllers (environmental compatibility)
- IEEE 802.3 / 802.3u – 10BASE-T / 100BASE-TX Ethernet
- CE Marking – EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- RoHS 2 Compliant – Restriction of Hazardous Substances
- cULus Listed – Canadian and US safety certification
Quality Assurance & Sourcing
Every 1783-BMS10CGN unit offered through Konmask.com undergoes the following verification process before dispatch:
- Visual inspection of housing, port labeling, and DIN-rail clip integrity
- Power-on functional test: all 10 ports verified for link negotiation at 10/100 Mbps
- Firmware version check against Rockwell Automation’s current release matrix
- Original factory packaging, serial number, and documentation retained
- Traceability record maintained for each unit (available on request)
Units are sourced from authorized distribution channels and verified surplus stock with documented chain of custody. Counterfeit-risk screening is applied to all incoming inventory.
How to Source This Part
- Add to Cart – Click Add to Cart above and proceed to checkout. We accept T/T bank transfer, PayPal, and major credit cards.
- Request a Quote – For orders of 5+ units or project BOM pricing, email support@konmask.com with your required quantity and delivery timeline.
- Lead Time – In-stock units ship within 1–3 business days. ETA confirmation provided at order placement.
- Export & Customs – We handle export documentation (commercial invoice, packing list, COO) for international shipments. HS Code: 8517.62 (network switches).
- Warranty – 12-month warranty against manufacturing defects. DOA replacement within 7 days of receipt.
Application-Specific FAQ
Q: Can the 1783-BMS10CGN be used in a Device Level Ring (DLR) topology?
A: No. DLR requires managed switches with ring supervisor capability. The 1783-BMS10CGN is unmanaged and supports star topology only. For DLR, specify the 1783-MMS managed switch series.
Q: Is this switch compatible with Siemens PROFINET devices?
A: Yes, as a Layer 2 unmanaged switch it passes all Ethernet frames transparently, including PROFINET RT frames. However, PROFINET IRT (isochronous real-time) requires managed switches with PROFINET-aware firmware.
Q: What is the maximum cable length per port?
A: 100 m (328 ft) per IEEE 802.3 100BASE-TX specification using Cat5e or Cat6 UTP/STP cable.
Q: Does the switch support PoE (Power over Ethernet)?
A: No. The 1783-BMS10CGN (CGN suffix = copper, no PoE). For PoE, specify the 1783-BMS10CGP variant.
Q: Can I mount this switch horizontally or vertically on the DIN rail?
A: Rockwell Automation recommends vertical DIN-rail mounting for optimal convection cooling. Horizontal mounting is permissible if ambient temperature is kept below 50 °C.
Q: Is a managed alternative available for VLAN segmentation?
A: Yes. The Stratix 5700 (1783-BMS series managed) and Stratix 8000 lines provide VLAN, QoS, IGMP snooping, and SNMP management for more complex network architectures.
