Pro-face PS3651A-T42-5M-EM2G – HMI-Integrated AC Servo Motor | PS3651A Series Platform
Engineering Background
Pro-face (Digital Electronics Corporation) developed the PS3651A series as a tightly integrated HMI + motion control platform, eliminating the traditional boundary between operator interface and servo drive. The PS3651A-T42-5M-EM2G variant pairs a 4.2-inch TFT touch panel with a dedicated AC servo motor output stage, enabling single-cabinet machine architectures common in semiconductor handling, precision dispensing, and compact CNC applications.
Product Positioning
This unit is engineered for OEM machine builders and system integrators who require deterministic motion control with co-located HMI feedback. The 5-meter cable assembly (suffix 5M) and EM2G encoder interface make it a drop-in replacement for existing PS3651A-T42 installations without re-cabling. Konmask.com supplies this model as a verified OEM component with full traceability documentation available on request.
Complete Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Pro-face (Digital Electronics Corp.) |
| Part Number (P/N) | 480801-01 |
| Model Number | PS3651A-T42-5M-EM2G |
| Series / Platform | PS3651A – HMI Servo Series |
| Display Integration | 4.2-inch TFT Color Touch Panel |
| Motor Type | AC Servo Motor with Integrated Drive |
| Cable Length | 5 m (suffix: 5M) |
| Encoder Interface | EM2G Incremental Encoder |
| Country of Origin | Japan |
| Unit Weight | 3.8 kg (approx.) |
| Compliance | CE, UL (verify with datasheet for specific revision) |
| Condition | New / Surplus New / Refurbished (specify at order) |
Proven Application Environments
- Semiconductor wafer handling and pick-and-place systems
- Precision fluid dispensing and adhesive application machines
- Compact CNC milling and engraving centers
- Automated optical inspection (AOI) gantry axes
- Packaging machinery with integrated HMI recipe management
- Medical device assembly lines requiring IEC 61010 compliance
Engineering Advantages
- Single-unit HMI + Servo integration — reduces panel space by up to 40% vs. discrete HMI + drive configurations
- 5 m pre-terminated cable assembly — eliminates field wiring errors; plug-and-play replacement
- EM2G encoder feedback — high-resolution incremental signal for closed-loop position accuracy
- Pro-face GP-Pro EX compatibility — native tag-based programming without third-party middleware
- Compact form factor — optimized for space-constrained OEM machine cabinets
System Architecture & Signal Flow
The PS3651A-T42-5M-EM2G operates as a unified node in a Pro-face motion network. The HMI panel communicates operator commands via the internal bus to the servo drive stage. The EM2G encoder feeds position data back to the drive’s closed-loop controller, while status and alarm data are simultaneously rendered on the 4.2-inch touch display. The 5 m cable assembly carries both power and encoder signals in a single shielded harness, minimizing EMI susceptibility in high-frequency switching environments.
Sourcing & Quality Verification
- All units sourced through authorized distributor channels or verified surplus inventory
- Serial number and date code inspection performed prior to shipment
- Functional test report available for refurbished units upon request
- Original OEM packaging preserved where available
- Anti-static packaging and shock-absorbing foam used for all shipments
Procurement Process
- Confirm part number 480801-01 and model PS3651A-T42-5M-EM2G against your BOM
- Submit inquiry or place order via Konmask.com product page
- Receive order confirmation with lead time and stock condition details within 1 business day
- Unit ships with packing list, inspection record, and tracking number
- Post-delivery technical support available via [email protected]
Technical FAQ
Q: Is the PS3651A-T42-5M-EM2G a direct replacement for PS3651A-T42 without the 5M suffix?
A: The 5M suffix denotes the 5-meter integrated cable assembly. Units without this suffix use a different cable length. Verify your installation’s cable routing before ordering.
Q: What programming software is required?
A: Pro-face GP-Pro EX is the native development environment. Version compatibility should be confirmed against your existing project file revision.
Q: Can this unit be repaired if the encoder fails?
A: Yes. The EM2G encoder is a serviceable sub-assembly. Contact Konmask.com for repair referral or exchange options.
Q: What is the typical lead time?
A: In-stock units ship within 2–5 business days internationally. Contact us for expedited options.
Q: Do you provide a warranty?
A: All units carry a minimum 90-day functional warranty. Extended warranty terms available on request.
