PRO-FACE PFXFP5700TPD – 5.7″ TFT Touch Screen HMI Panel | GP4000 Series Platform
Engineering Background: The PFXFP5700TPD is part of Pro-face’s GP4000 Series — one of the most widely deployed HMI platforms in discrete manufacturing, process control, and machine automation globally. Engineered for demanding industrial environments, this panel integrates seamlessly with PLCs from Mitsubishi, Siemens, Omron, Allen-Bradley, and Schneider Electric via native protocol drivers.
Product Positioning: Designed for procurement engineers and system integrators who require a compact, high-reliability HMI with proven field performance. The PFXFP5700TPD delivers a cost-effective touchscreen interface solution for retrofit projects, OEM machine builds, and new control panel installations where space and reliability are critical constraints.
Complete Technical Specifications
- Part Number / SKU: PFXFP5700TPD
- Brand / Manufacturer: PRO-FACE (Schneider Electric)
- Series / Platform: GP4000 Series
- Display Type: 5.7″ TFT Color LCD
- Resolution: 640 × 480 pixels (VGA)
- Touch Panel Type: Analog Resistive Touch Screen
- Display Colors: 65,536 colors (16-bit)
- Backlight: LED (long-life, no mercury)
- CPU: 32-bit RISC Processor
- User Memory: 60 MB (application + data)
- Communication Ports: RS-232C / RS-422 / RS-485 (COM1), USB Host, USB Device, Ethernet 10/100BASE-T
- Supported Protocols: Modbus RTU/TCP, PROFIBUS DP (optional), EtherNet/IP, CC-Link, and 1,000+ native PLC drivers
- Power Supply: 24 VDC ±10%
- Power Consumption: Approx. 15 W
- Operating Temperature: 0°C to +50°C
- Storage Temperature: -20°C to +60°C
- Humidity: 10% to 90% RH (non-condensing)
- Protection Rating: IP65 (front panel)
- Vibration Resistance: 10–57 Hz, 0.075 mm amplitude; 57–150 Hz, 9.8 m/s²
- Panel Cutout: 192 × 138 mm (W × H)
- Overall Dimensions: 216 × 162 × 55 mm (W × H × D)
- Weight: Approx. 1,500 g
- Certifications: CE, UL, cUL, RoHS
- Development Software: GP-Pro EX (Windows compatible)
Proven Application Environments
- Discrete Manufacturing: Assembly line HMI stations, robotic cell operator panels, conveyor control interfaces
- Process Industries: Water treatment SCADA terminals, chemical dosing control, HVAC building automation
- Food & Beverage: Hygienic machine interfaces (IP65 front seal), batch control panels
- Packaging Machinery: OEM machine builder standard HMI, filling and labeling line control
- Energy & Utilities: Substation monitoring terminals, generator control panels
- Retrofit Projects: Direct replacement for legacy GP2000/GP3000 series panels with GP-Pro EX migration tools
Engineering Advantages
- Universal PLC Connectivity: 1,000+ built-in protocol drivers eliminate custom gateway hardware costs
- IP65 Front Panel: Suitable for wash-down environments and dusty factory floors without additional enclosure protection
- LED Backlight: 50,000+ hour rated lifespan reduces maintenance downtime vs. CCFL predecessors
- GP-Pro EX Software: Drag-and-drop screen development with simulation mode — reduces commissioning time by up to 40%
- Compact Footprint: 5.7″ form factor fits standard DIN-rail enclosure cutouts; ideal for space-constrained panels
- Dual USB Ports: USB Host for data logging to flash drive; USB Device for PC programming without network access
- Ethernet Standard: Supports remote monitoring, VNC viewer access, and FTP data transfer natively
System Architecture & Signal Flow
The PFXFP5700TPD operates as a standalone HMI terminal in a typical PLC-HMI architecture:
- PLC Layer: Connects to host PLC via RS-232/422/485 serial or Ethernet (EtherNet/IP, Modbus TCP, etc.) — reads/writes registers and coils in real time
- HMI Layer: PFXFP5700TPD renders operator screens, alarms, trends, and recipes stored in internal 60 MB memory
- Operator Layer: Resistive touch input with configurable function keys; supports multi-language display (Unicode)
- Data Layer: CSV data logging to USB flash drive; alarm history with timestamp; recipe management up to 2,000 records
- Remote Layer: Ethernet port enables VNC-based remote monitoring from SCADA/PC without additional hardware
Sourcing & Quality Verification
- Origin: Genuine PRO-FACE (Schneider Electric) manufactured unit
- Condition: New / Refurbished / Tested — please confirm with our sales team at time of order
- Traceability: Each unit ships with serial number documentation for warranty and maintenance records
- Testing Protocol: 48-hour burn-in test; functional verification of all communication ports and touch calibration prior to dispatch
- Packaging: Anti-static ESD bag + foam-lined export carton; suitable for international air and sea freight
- Lead Time: In-stock units ship within 1–3 business days; contact us for volume availability
Procurement Process
- Inquiry: Submit your RFQ via email to [email protected] or WhatsApp +0086 19859288691 with quantity and required delivery date
- Quotation: Receive formal quotation with unit price, lead time, and shipping options within 4 business hours
- Order Confirmation: Place order via Shopify checkout or wire transfer (T/T) for volume orders
- Quality Check: Unit tested and documented before dispatch
- Shipping: DHL / FedEx / UPS express worldwide; sea freight available for bulk orders
- After-Sales: 12-month warranty; technical support for integration and GP-Pro EX programming
Technical FAQ
Q: Is the PFXFP5700TPD compatible with Mitsubishi MELSEC Q-series PLCs?
A: Yes. GP-Pro EX includes native Mitsubishi MELSEC Q/QnA/iQ-R series drivers. No additional gateway required.
Q: Can I replace a GP-2501S with the PFXFP5700TPD?
A: Yes. GP-Pro EX provides a migration wizard to convert GP2000/GP3000 series projects. Screen layout adjustments may be required due to resolution differences.
Q: What is the maximum number of alarm messages supported?
A: Up to 32,000 alarm messages with timestamp logging. Alarm history can be exported to CSV via USB or FTP.
Q: Does the unit support multi-language display?
A: Yes. Unicode support allows simultaneous display of Chinese, English, Japanese, Korean, and European languages within a single project.
Q: What warranty is provided?
A: Konmask.com provides a 12-month warranty covering manufacturing defects. Repair and replacement service available for out-of-warranty units.
