Prosoft MVI56-ADM Programmable Application Development Module – MVI56 Series
When a critical communication link between your ControlLogix PLC and a proprietary or legacy field device goes unsupported, production lines stall, engineers scramble, and costly downtime accumulates by the hour. Standard off-the-shelf communication modules simply cannot bridge every protocol gap that exists in real-world industrial environments. The Prosoft MVI56-ADM exists precisely to eliminate this vulnerability — a field-programmable application development module that empowers engineers to implement custom communication protocols directly within the Allen-Bradley ControlLogix backplane, without compromise.
Within the MVI56 Series — Prosoft Technology’s flagship ControlLogix communication platform — the MVI56-ADM occupies a unique position as the developer-grade solution. While other MVI56 modules deliver fixed-protocol connectivity (Modbus, DNP3, PROFIBUS, etc.), the ADM variant provides a blank-canvas programmable environment for engineers who need to define their own serial communication logic. This flexibility has made it a trusted tool in specialized OEM applications, legacy system integrations, and custom automation projects across global process and discrete manufacturing industries.
Technical Specifications
- Module Type: Programmable Application Development Module
- Platform Compatibility: Allen-Bradley ControlLogix (1756 backplane)
- Series: MVI56 (ProSoft Technology)
- Communication Ports: Serial (application-defined configuration)
- Programming Environment: Prosoft Application Development Kit (ADK)
- Data Exchange: Shared memory interface with ControlLogix processor via backplane
- Form Factor: Single-slot ControlLogix module
- Weight: Approx. 200 g
- Certifications: Refer to official Prosoft MVI56-ADM datasheet for current agency approvals
Note: All specifications above are based on publicly available Prosoft documentation. Contact us to confirm the latest revision details before ordering.
Key Features & Benefits
- Custom Protocol Development: Implement proprietary or non-standard serial protocols not covered by fixed-function modules, using Prosoft’s ADK toolchain.
- ControlLogix Backplane Integration: Seamless data exchange with the 1756 processor via shared memory — no external gateways or converters required.
- Reduced Engineering Risk: Develop and test communication logic in a controlled module environment before deploying to production systems.
- OEM & System Integrator Friendly: Ideal for machine builders who need repeatable, embedded communication solutions across multiple installations.
- Legacy System Bridge: Connect aging field devices with non-standard interfaces to modern ControlLogix architectures without replacing existing hardware.
- Scalable Architecture: Multiple MVI56-ADM modules can be deployed in the same chassis for parallel communication channel management.
Industry & Equipment Applications
- Oil & Gas: Custom SCADA polling protocols for wellhead RTUs and flow computers
- Water & Wastewater: Proprietary telemetry interfaces for remote pump stations
- Automotive Manufacturing: Legacy robot controller integration via non-standard serial links
- Power Generation: Custom IED communication for protection relay monitoring
- Pharmaceutical: Validated data acquisition from legacy analytical instruments
- OEM Machine Builders: Embedded protocol engines for proprietary HMI or sensor networks
System Integration & Compatible Parts
The MVI56-ADM is designed for use within the Allen-Bradley 1756 ControlLogix chassis ecosystem. Compatible and commonly paired components include:
- Allen-Bradley 1756 ControlLogix chassis (any slot count)
- Allen-Bradley 1756-L series ControlLogix processors (L61, L71, L83E, etc.)
- Prosoft MVI56 series communication modules (for mixed-protocol chassis configurations)
- Prosoft Application Development Kit (ADK) — required for custom firmware development
- RS-232 / RS-485 serial cables and terminal adapters (application-dependent)
Contact our technical team at support@konmask.com for system compatibility verification before ordering.
Our Quality Assurance Process
Every Prosoft MVI56-ADM unit sourced through Konmask.com undergoes a structured verification process before shipment:
- Authenticity Check: Visual inspection of module labeling, firmware revision markings, and packaging integrity against known-genuine references.
- Functional Pre-screening: Where applicable, modules are powered and basic communication diagnostics are verified.
- Documentation Package: Each shipment includes available datasheets, revision notes, and a packing list for your records.
- Traceability: Batch and serial number records are maintained for post-sale support and warranty claims.
How to Order
- Submit an inquiry via the “Get a Quote” button or email support@konmask.com with your required quantity and delivery timeline.
- Our team will confirm stock availability, lead time, and provide a formal quotation within 1 business day.
- Upon PO confirmation, we arrange packaging, export documentation, and shipment via your preferred freight method.
- Tracking information and commercial invoice are provided upon dispatch.
For urgent requirements or large-volume orders, please call us directly at +0086 19859288691.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC, DCS, and automation hardware — not a generalist distributor.
- Global Sourcing Network: Access to both new and hard-to-find discontinued modules from verified supply channels.
- Technical Pre-sales Support: Our engineers can assist with compatibility checks, system design questions, and application guidance.
- Responsive Quotation: Most RFQs receive a formal quote within 24 hours.
- Secure Packaging & Export Compliance: All shipments are properly packaged for international transit with accurate commercial documentation.
Frequently Asked Questions
- Q: What programming tools are required to develop firmware for the MVI56-ADM?
- A: The MVI56-ADM requires Prosoft Technology’s Application Development Kit (ADK), which includes the development environment, API libraries, and documentation. Contact Prosoft directly or our team for ADK licensing information.
- Q: Is the MVI56-ADM compatible with all ControlLogix chassis sizes?
- A: Yes, the MVI56-ADM occupies a single slot in any 1756 ControlLogix chassis (4, 7, 10, 13, or 17-slot configurations) and communicates with the local processor via the backplane.
- Q: Can the MVI56-ADM replace a fixed-protocol MVI56 module (e.g., MVI56-MCM)?
- A: Physically yes — it fits the same slot. However, the ADM requires custom firmware development to replicate a fixed-protocol module’s behavior. It is best suited for applications where no standard MVI56 protocol module exists.
- Q: Do you supply new or refurbished units?
- A: We supply both new and tested-used units depending on availability. The condition will be clearly stated in your quotation. All units pass our QA process before shipment.
- Q: What is the typical lead time for the MVI56-ADM?
- A: Lead time varies by stock availability. In-stock units typically ship within 3–5 business days. For out-of-stock items, our team will provide an estimated lead time with your quotation.
