DeviceNet Automation Solution – ProSoft Technology MVI69-DFNT | MVI69 Series
Where This Product Is Used
The ProSoft MVI69-DFNT is deployed in industrial environments where a CompactLogix PLC must communicate with DeviceNet field devices. Typical application scenarios include:
- Automotive Assembly Lines — Connecting CompactLogix controllers to DeviceNet-enabled robots, welding guns, and conveyor drives for synchronized motion control.
- Food & Beverage Processing — Integrating variable frequency drives (VFDs), sensors, and actuators on a DeviceNet network managed by a CompactLogix PLC.
- Material Handling & Packaging — Coordinating DeviceNet barcode scanners, photoelectric sensors, and servo drives within a CompactLogix-based control architecture.
- Water & Wastewater Treatment — Bridging legacy DeviceNet pump controllers and valve actuators into modern EtherNet/IP-based SCADA systems via CompactLogix.
- Discrete Manufacturing — Enabling a single CompactLogix rack to act as DeviceNet Master, polling up to 63 slave nodes for real-time I/O data exchange.
Technical Specifications
| Attribute | Value |
|---|---|
| Part Number (SKU) | MVI69-DFNT |
| Manufacturer | ProSoft Technology |
| Series | MVI69 (CompactLogix In-Chassis) |
| Protocol | DeviceNet (CAN-based, IEC 62026-3) |
| Network Role | Master and/or Slave (configurable) |
| Max DeviceNet Nodes | 63 slave nodes per network |
| Baud Rates | 125 kbps / 250 kbps / 500 kbps (auto-detect) |
| Backplane Interface | CompactLogix 1769 local I/O bus |
| Configuration Tool | ProSoft Configuration Builder (PCB) — free download |
| Power Consumption | 800 mA @ 5 VDC (from backplane) |
| Operating Temperature | 0 °C to 60 °C (32 °F to 140 °F) |
| Storage Temperature | -40 °C to 85 °C |
| Humidity | 5% to 95% non-condensing |
| Dimensions (H × W × D) | 94 mm × 40 mm × 87 mm |
| Weight | 180 g |
| Certifications | UL Listed, CE Marked, cUL |
| Compatible PLCs | 1769-L16, L18, L24, L27, L30, L33, L35, L43, L45 |
Why Engineers Specify This Model
- Dual-Role Flexibility — Operates simultaneously as DeviceNet Master and Slave, eliminating the need for two separate gateway modules in complex topologies.
- In-Chassis Integration — Mounts directly in the CompactLogix 1769 local rack; no external power supply or DIN-rail gateway required, reducing panel footprint.
- Deterministic Data Exchange — Uses explicit and implicit messaging to deliver sub-millisecond I/O updates, critical for motion-sensitive applications.
- Free Configuration Software — ProSoft Configuration Builder (PCB) provides a graphical node-mapping interface, cutting commissioning time significantly.
- Proven Field Reliability — MVI69 series modules are installed in tens of thousands of sites globally across automotive, oil & gas, and utilities sectors.
- Rockwell Ecosystem Compatible — Fully compatible with Studio 5000 / RSLogix 5000 Add-On Instructions (AOI) for seamless ladder logic integration.
Complete System Bill of Materials
A typical CompactLogix + DeviceNet control node using the MVI69-DFNT includes:
- CompactLogix Controller (e.g., Allen-Bradley 1769-L33ER)
- ProSoft MVI69-DFNT — DeviceNet Master/Slave Communication Module
- 1769-PA2 or 1769-PB2 Power Supply
- 1769-ECR / 1769-ECL End Cap
- DeviceNet Trunk Cable (thick or thin, per network length)
- DeviceNet Network Power Supply (24 VDC, min. 4 A)
- DeviceNet Terminating Resistors (121 Ω, both ends of trunk)
- ProSoft Configuration Builder (PCB) Software — free
Compliance & Industry Standards
- DeviceNet: ODVA DeviceNet Specification, IEC 62026-3
- Safety: UL 508 (Industrial Control Equipment), CE (EN 61131-2), cUL
- EMC: EN 55011 Class A, EN 61000-4 series immunity
- RoHS: Compliant (Directive 2011/65/EU)
- ODVA Conformance: Tested and certified by ODVA for DeviceNet interoperability
Quality Assurance & Sourcing
Konmask.com sources the ProSoft MVI69-DFNT through verified industrial automation distributors and authorized supply channels. Every unit undergoes:
- Visual and mechanical inspection upon receipt
- Firmware version verification against ProSoft Technology release notes
- Functional power-on test prior to dispatch
- Anti-static packaging with humidity indicator card
All products are shipped with original manufacturer labeling and documentation where available. Traceability records are maintained for each order.
How to Source This Part
- In Stock Orders: Add to cart and complete checkout — standard lead time is 1–3 business days for dispatch.
- Bulk / Project Quotes: Contact [email protected] for volume pricing and project BOM support.
- Urgent Requirements: Call or WhatsApp +0086 19859288691 for expedited sourcing and same-day quotation.
- Datasheet & Manuals: Available upon request or via ProSoft Technology’s official documentation portal.
Application-Specific FAQ
Q: Can the MVI69-DFNT act as both Master and Slave on the same DeviceNet network simultaneously?
A: Yes. The module supports concurrent Master and Slave operation, allowing it to poll field devices while also responding to commands from an upstream DeviceNet scanner.
Q: Is the MVI69-DFNT compatible with Studio 5000 Logix Designer?
A: Yes. ProSoft provides Add-On Instructions (AOI) and sample ladder logic fully compatible with Studio 5000 v20 and later.
Q: What is the maximum cable length for a DeviceNet network using this module?
A: Thick trunk cable supports up to 500 m at 125 kbps. Thin cable supports up to 100 m. Drop lines are limited to 6 m each, with a cumulative drop limit of 156 m.
Q: Does this module require a separate 24 VDC power supply?
A: The module itself is powered from the CompactLogix backplane (5 VDC). However, the DeviceNet network requires a dedicated 24 VDC network power supply separate from the PLC power supply.
Q: Can I use this module with a MicroLogix or ControlLogix platform?
A: No. The MVI69 series is designed exclusively for the CompactLogix 1769 local I/O bus. For ControlLogix, specify the MVI56-DFNT; for MicroLogix, a different gateway solution is required.
