PROSOFT PLX31-EIP-PND EtherNet/IP to PROFINET Gateway | Replacement, Equivalent & Selection Guide
The PROSOFT PLX31-EIP-PND is an industrial protocol gateway that bridges EtherNet/IP (Allen-Bradley / Rockwell Automation) networks with PROFINET IO (Siemens / IEC 61158) networks. It enables seamless data exchange between PLCs, drives, and field devices across these two dominant industrial Ethernet protocols — without custom programming or middleware.
At Konmask.com, we specialize in sourcing, cross-referencing, and supplying automation components including the PLX31-EIP-PND and its verified compatible alternatives.
Technical Specifications
- Part Number: PLX31-EIP-PND
- Manufacturer: ProSoft Technology
- Series: PLX31 (Standalone Protocol Gateway)
- Function: EtherNet/IP Adapter ↔ PROFINET IO Device
- EtherNet/IP Role: Adapter (Slave)
- PROFINET Role: IO Device (Slave)
- Network Ports: 2 × RJ45 Ethernet (independent)
- Data Exchange: Up to 500 words input / 500 words output
- Power Supply: 24 VDC (±10%)
- Operating Temperature: 0°C to +60°C
- Storage Temperature: -40°C to +85°C
- Humidity: 5% to 95% non-condensing
- Mounting: DIN rail
- Dimensions (W×H×D): Approx. 45 × 100 × 115 mm
- Weight: ~750 g
- Certifications: CE, UL, cUL, RoHS
- Configuration Tool: ProSoft Configuration Builder (PCB) — free download
- Firmware Update: Supported via USB / Ethernet
Compatible Replacement & Equivalent Models
If the PLX31-EIP-PND is unavailable, end-of-life, or over budget, the following models offer compatible or equivalent functionality. Always verify I/O capacity, protocol roles, and firmware compatibility before substitution.
| Model | Manufacturer | EtherNet/IP Role | PROFINET Role | Notes |
|---|---|---|---|---|
| PLX31-EIP-PND | ProSoft Technology | Adapter | IO Device | Original — this product |
| PLX32-EIP-PND | ProSoft Technology | Scanner + Adapter | IO Controller + Device | Upgraded dual-role model |
| PLX51-EIP-PND | ProSoft Technology | Adapter | IO Device | ControlLogix in-chassis version |
| HMS AnyBus X-Gateway AB7007 | HMS Networks | Adapter | IO Device | Direct functional equivalent |
| Moxa MGate MB3170 | Moxa | — | — | Modbus variant; verify protocol match |
| Hilscher NT 100-RE-EN | Hilscher | Adapter | IO Device | Alternative gateway platform |
| Turck TBEN-L-PNS-EIS | Turck | Adapter | IO Device | I/O block with gateway function |
⚠ Disclaimer: Cross-reference data is provided for reference only. Konmask.com recommends engineering validation before substitution in safety-critical or production systems.
Why Choose the Original PLX31-EIP-PND
- ✅ Proven interoperability with Allen-Bradley ControlLogix, CompactLogix, and Siemens S7-300/400/1200/1500 PLCs
- ✅ No custom code required — configured entirely via ProSoft Configuration Builder GUI
- ✅ Deterministic data mapping — up to 500 words each direction with configurable data tables
- ✅ Standalone DIN-rail form factor — no host PLC backplane slot required
- ✅ Dual independent Ethernet ports — isolates EtherNet/IP and PROFINET network segments
- ✅ Active manufacturer support — firmware updates, PCB software, and technical documentation available
- ✅ Wide certification coverage — CE, UL, cUL, RoHS for global deployment
Typical Applications
- Connecting Allen-Bradley ControlLogix / CompactLogix PLCs to Siemens PROFINET IO devices (drives, HMIs, remote I/O)
- Integrating legacy EtherNet/IP systems into new PROFINET-based production lines
- Bridging multi-vendor automation islands in automotive, food & beverage, and packaging plants
- Enabling data exchange between Rockwell Automation and Siemens control architectures without replacing existing hardware
- OEM machine builders supplying equipment to customers with mixed PLC environments
System Compatibility
| Side | Compatible Controllers / Devices |
|---|---|
| EtherNet/IP | Allen-Bradley ControlLogix (1756), CompactLogix (1769), MicroLogix 1100/1400, SoftLogix 5800 |
| PROFINET IO | Siemens S7-300, S7-400, S7-1200, S7-1500, ET 200SP, ET 200M; any PROFINET IO Controller per IEC 61158 |
| Config Software | ProSoft Configuration Builder (PCB) v4.x+, Windows 7/10/11 |
| GSD File | Provided for PROFINET IO Controller import (TIA Portal / STEP 7) |
Selection Guide
Use this guide to confirm the PLX31-EIP-PND is the right model for your application:
- Step 1 — Identify protocol roles: Is your EtherNet/IP controller a Scanner (master)? Is your PROFINET controller an IO Controller (master)? The PLX31-EIP-PND acts as slave on both sides — confirm your PLCs are masters.
- Step 2 — Verify data volume: Does your application require ≤500 words input and ≤500 words output? If more, consider the PLX32-EIP-PND.
- Step 3 — Check mounting: DIN rail installation available? If backplane mounting is preferred, consider PLX51-EIP-PND (ControlLogix chassis).
- Step 4 — Confirm power: 24 VDC available at installation point?
- Step 5 — Environmental rating: Operating within 0–60°C? For harsh environments, consult ProSoft for extended-temp variants.
📧 Not sure which model fits? Contact our selection team with your PLC models and I/O requirements.
Quality Assurance & Sourcing
- 🔍 Authenticity verification — all units sourced from authorized distributors or verified secondary market with traceability documentation
- 📦 Pre-shipment inspection — visual, label, and functional checks performed before dispatch
- 📄 Documentation included — datasheet, quick-start guide, and PCB software download link provided with every order
- 🌐 Global shipping — DHL / FedEx / UPS express available; export documentation for CN customs compliance
- 🔄 Return policy — 30-day return for unused, unopened units in original packaging
How to Order
- Click Add to Cart or Buy Now on this page.
- For bulk orders (5+ units), RFQ pricing, or lead-time inquiries — email support@konmask.com with quantity and delivery location.
- For cross-reference or replacement confirmation, include your existing part number and PLC model in your inquiry.
- Payment: T/T (wire transfer), PayPal, credit card via Shopify Payments.
- Lead time: In-stock units ship within 1–3 business days; sourced units 5–15 business days.
Replacement & Compatibility FAQ
Q: Can the PLX31-EIP-PND replace an HMS AnyBus X-Gateway AB7007?
A: In most cases yes — both act as EtherNet/IP Adapter and PROFINET IO Device. Verify I/O word count and GSD file compatibility in your PROFINET controller project.
Q: Is the PLX31-EIP-PND compatible with Siemens TIA Portal?
A: Yes. ProSoft provides a GSD file that imports directly into TIA Portal V13 and later for PROFINET IO configuration.
Q: What is the difference between PLX31-EIP-PND and PLX32-EIP-PND?
A: The PLX32 supports Scanner and Controller roles on both sides (master-capable), while the PLX31 is slave-only on both networks. Choose PLX32 if your gateway needs to initiate communication.
Q: Can I use this gateway with CompactLogix 5380?
A: Yes. The PLX31-EIP-PND is compatible with all EtherNet/IP Scanner-capable ControlLogix and CompactLogix platforms including the 5380 series.
Q: Does Konmask.com provide the ProSoft Configuration Builder software?
A: PCB is free to download from ProSoft Technology’s website. We provide the download link and configuration guidance with every order.
