Raytek RAYMI310LTSCB3 – Fixed-Mount Infrared Temperature Sensor | MI310 Series
The Raytek RAYMI310LTSCB3 is a fixed-mount, non-contact infrared temperature sensor from the MI310 Series platform — engineered for continuous, high-accuracy thermal monitoring in demanding industrial environments. Designed for procurement engineers and systems integrators who require reliable, spec-verified components for process control, quality assurance, and predictive maintenance applications.
Product Positioning: The RAYMI310LTSCB3 targets applications where contact measurement is impractical — moving targets, hazardous surfaces, or processes requiring zero contamination. Its compact fixed-mount form factor integrates directly into OEM machinery, conveyor lines, and automated inspection systems.
Complete Technical Specifications
- Part Number: RAYMI310LTSCB3
- Brand: Raytek (Fluke Corporation)
- Series: MI310
- Measurement Type: Non-contact infrared (pyrometer)
- Spectral Response: 8–14 µm (long-wave infrared)
- Temperature Range: -40°C to +600°C (–40°F to +1112°F)
- Accuracy: ±1°C or ±1% of reading (whichever is greater)
- Repeatability: ±0.5°C or ±0.5%
- Response Time: ≤ 150 ms (95% response)
- Emissivity: Adjustable 0.100–1.000
- Optics / Field of View: 10:1 distance-to-spot ratio
- Output Signal: 4–20 mA analog; thermocouple-compatible output (model-dependent)
- Supply Voltage: 15–30 VDC
- Operating Ambient Temperature: 0°C to +70°C
- Storage Temperature: –20°C to +85°C
- Enclosure Rating: IP65
- Housing Material: Stainless steel
- Weight: ~160 g
- Connector: M12 industrial connector
- Certifications: CE, RoHS
Proven Application Environments
- Metal Processing: Continuous billet, slab, and strip temperature monitoring on rolling mills and heat treatment lines
- Plastics & Rubber: Extrusion die and mold surface temperature control for consistent product quality
- Glass Manufacturing: Annealing lehr and forming zone thermal profiling
- Food & Beverage: Hygienic, non-contact temperature verification on packaging and pasteurization lines
- Electronics Assembly: PCB reflow oven profiling and component thermal inspection
- Predictive Maintenance: Motor, bearing, and transformer hot-spot detection in MCC panels and substations
- Automotive: Brake disc, engine component, and paint curing oven monitoring
Engineering Advantages
- Zero Contact, Zero Contamination: Ideal for sterile, corrosive, or high-voltage environments where probe contact is prohibited
- Fast Response: ≤150 ms response time enables real-time closed-loop temperature control
- Adjustable Emissivity: Compensates for varying surface finishes — metals, ceramics, polymers — without recalibration
- Robust IP65 Stainless Housing: Withstands washdowns, dust, and mechanical vibration in factory environments
- Industry-Standard 4–20 mA Output: Direct integration with PLCs, DCS, SCADA, and data acquisition systems
- Compact Fixed-Mount Design: Minimal installation footprint; compatible with standard M12 cabling infrastructure
System Architecture & Signal Flow
The RAYMI310LTSCB3 operates as a passive sensing node within a closed-loop temperature control architecture:
- Sensing Layer: RAYMI310LTSCB3 captures infrared radiation from target surface → converts to calibrated temperature signal
- Signal Transmission: 4–20 mA analog output over shielded M12 cable → PLC analog input module (e.g., Siemens SM 331, Allen-Bradley 1756-IF16)
- Control Layer: PLC/DCS processes temperature value → executes control logic (PID, alarm, interlock)
- HMI/SCADA: Real-time temperature trending, alarm management, and data logging
- Power Supply: 15–30 VDC from panel-mount PSU via M12 connector; two-wire loop-powered configurations supported
Sourcing & Quality Verification
- Origin: Genuine Raytek (Fluke Corporation) manufactured component
- Traceability: Each unit ships with original manufacturer documentation and serial number traceability
- Inspection: Pre-shipment functional verification — output signal, emissivity adjustment, and housing integrity check
- Packaging: Original OEM packaging with anti-static protection and calibration certificate where applicable
- Warranty: 12-month warranty against manufacturing defects; Konmask.com technical support included
Procurement Process
- Step 1 – RFQ: Submit quantity and delivery requirements via support@konmask.com or +0086 19859288691
- Step 2 – Quote: Formal quotation with lead time, unit price, and shipping terms issued within 24 hours
- Step 3 – Order Confirmation: PO accepted; payment via T/T, PayPal, or credit card
- Step 4 – Shipment: DHL / FedEx / UPS express with full tracking; EXW Xiamen or CIF destination available
- Step 5 – Documentation: Commercial invoice, packing list, COO, and test report provided upon request
Technical FAQ
Q: What is the minimum detectable spot size at 1 meter distance?
A: With a 10:1 optics ratio, the spot diameter at 1 m is approximately 100 mm. Ensure the target fills the spot for accurate readings.
Q: Can the RAYMI310LTSCB3 measure through glass or plastic windows?
A: No. The 8–14 µm spectral range is absorbed by most glass and plastic. Use a germanium or zinc selenide window if a protective barrier is required.
Q: How do I set emissivity for polished stainless steel?
A: Polished metals typically have emissivity of 0.10–0.20. Use a contact thermocouple reference measurement to calibrate the emissivity setting on-site.
Q: Is the 4–20 mA output loop-powered or separately powered?
A: The RAYMI310LTSCB3 requires an external 15–30 VDC supply. The 4–20 mA output is sourced (active), not loop-powered.
Q: What is the lead time for stock orders?
A: In-stock units ship within 3–5 business days. For bulk orders (>10 units), contact us for confirmed lead time.
