Genuine Rexroth HDS03.2-W100N-HS12-01-FW | FWA-DIAX04-SSE-02V56-MS AC Servo Drive | HDS Series – Verified Source
Konmask.com supplies 100% genuine Bosch Rexroth HDS03.2-W100N-HS12-01-FW servo drive controllers pre-loaded with firmware FWA-DIAX04-SSE-02V56-MS. Every unit passes our 4-step verification process before shipment, giving industrial buyers the confidence to source mission-critical automation components without compromise.
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Bosch Rexroth |
| Part Number | HDS03.2-W100N-HS12-01-FW |
| Firmware | FWA-DIAX04-SSE-02V56-MS |
| Series | HDS (High Dynamic Servo Drive) |
| Drive Platform | DIAX04 |
| Continuous Output Current | 100 A |
| Cooling Method | Forced air (internal fan) |
| Interface | SERCOS / Analog / Digital I/O |
| Feedback Compatibility | Resolver, EnDat, Hiperface |
| Supply Voltage | 3 × AC 400–480 V, 50/60 Hz |
| Weight | 6.8 kg |
| Firmware Version | SSE-02V56-MS (Spindle/Servo Edition) |
| Condition | New / Refurbished (specify on order) |
Our 4-Step Quality Verification Process
Every Rexroth HDS03.2-W100N-HS12-01-FW unit sold by Konmask.com undergoes:
- Origin Traceability Check – Serial number cross-referenced against Bosch Rexroth production records and authorized distributor manifests.
- Physical Inspection – Housing, connectors, PCB, and firmware label examined for signs of counterfeit, repair, or tampering.
- Functional Power-On Test – Unit powered and firmware version confirmed via diagnostic interface before packaging.
- Documentation Audit – CE declaration, calibration certificate, and packing list verified and included with shipment.
Key Features & Benefits
- High dynamic response for demanding CNC spindle and servo axis applications
- DIAX04 platform ensures broad compatibility with Rexroth MHD, MKD, and MKE motor families
- Firmware SSE-02V56-MS supports both spindle and servo operating modes in a single unit
- Integrated safety relay output (HS12) for STO (Safe Torque Off) compliance
- Compact modular design for easy integration into existing Rexroth drive cabinets
- Full parameter backup/restore via Rexroth IndraWorks or BTV04 operator panel
Typical Applications
- CNC machining centers (milling, turning, grinding)
- Injection molding machines
- Printing and packaging lines
- Robotics and gantry systems
- Semiconductor and electronics manufacturing equipment
- Metal forming and press automation
Compatible System Components
- Power Supply Modules: Rexroth HVR, HVE, HVD series
- Servo Motors: Rexroth MHD, MKD, MKE, 2AD series
- Controls: Rexroth DIAX04 CNC, Indramat TDM/KDS, Siemens 840D (via SERCOS)
- Operator Panels: BTV04, BTV06, IndraWorks PC software
- Cables: IKS series feedback and power cables
Global Sourcing & Shipping Capabilities
Konmask.com ships worldwide from our warehouse in China. Standard lead times:
- In-stock units: Ships within 1–3 business days
- Express (DHL / FedEx / UPS): 3–7 business days to most destinations
- Economy freight: 10–20 business days
- Customs documentation: Commercial invoice, packing list, and HS code 8537.10 provided as standard
- Export compliance: All shipments comply with applicable export control regulations
Certifications & Compliance Statement
- CE Marked (Machinery Directive 2006/42/EC, Low Voltage Directive 2014/35/EU)
- RoHS compliant
- UL recognized components (where applicable)
- ISO 9001 supply chain sourcing standards observed by Konmask.com
Konmask.com is an independent distributor and is not an authorized Bosch Rexroth dealer. All brand names and part numbers are used for identification purposes only.
How to Order
- Confirm the part number HDS03.2-W100N-HS12-01-FW and firmware FWA-DIAX04-SSE-02V56-MS match your machine’s requirements.
- Select quantity and add to cart, or contact us for bulk pricing.
- Provide your machine model and control system version for compatibility confirmation (optional but recommended).
- Choose your preferred shipping method at checkout.
- Receive tracking number and documentation within 24 hours of dispatch.
Need a formal quotation? Email [email protected] with your PO requirements.
Authenticity & Trust FAQ
Q: How do I know this is a genuine Rexroth unit?
A: Each unit ships with its original serial number label. You can verify authenticity by contacting Bosch Rexroth with the serial number, or request our inspection report before purchase.
Q: Is the firmware pre-installed?
A: Yes. FWA-DIAX04-SSE-02V56-MS is factory-installed and confirmed via power-on test. No additional firmware upload is required.
Q: Do you offer a warranty?
A: We offer a 90-day functional warranty on all units. Extended warranty options are available — contact us for details.
Q: Can you source other HDS or DIAX04 variants?
A: Yes. We stock a wide range of Rexroth HDS, HVR, and DIAX04 components. Send your parts list to [email protected].
Q: What if the unit is DOA on arrival?
A: Contact us within 7 days of receipt. We will arrange replacement or full refund after inspection confirmation.
