Machine Control & HMI Solution — REXROTH VCP05.1BSN.PB-NN-PW | VCP05 Series
Where This Product Is Used
The REXROTH VCP05.1BSN.PB-NN-PW is a compact operator terminal (HMI panel) from Bosch Rexroth’s VCP05 series, designed for demanding industrial environments where reliable human-machine interaction is critical. Typical deployment scenarios include:
- Packaging & Labelling Lines — Local operator control of conveyor speed, batch counts, and fault acknowledgement at the machine level.
- Injection Moulding & Plastics Machinery — Parameter entry and process monitoring for cycle time, temperature, and pressure setpoints.
- Hydraulic Press & Metal Forming — Rexroth-native integration with IndraControl and IndraDrive systems for press-force visualisation and stroke control.
- Assembly & Test Stations — Step-by-step operator guidance, torque/force readout, and pass/fail indication on semi-automated lines.
- Material Handling & Conveyor Systems — Zone-level HMI for start/stop, speed reference, and alarm display without a centralised SCADA screen.
- Food & Beverage Processing — Washdown-compatible panel mounting for recipe selection and CIP cycle management.
- PROFIBUS-DP Networks — Acts as a DP slave or master HMI node within existing PROFIBUS fieldbus architectures, enabling seamless integration with Siemens, ABB, and other DP-compatible PLCs.
Technical Specifications
| Part Number | VCP05.1BSN.PB-NN-PW |
| Manufacturer | Bosch Rexroth |
| Series | VCP05 |
| Device Type | Operator Terminal / HMI Panel |
| Fieldbus Interface | PROFIBUS-DP (PB) |
| Display | Compact monochrome / graphic LCD (series-standard) |
| Keypad | Membrane function keys + numeric/navigation keys |
| Power Supply | 24 V DC (PW suffix) |
| Mounting | Panel cut-out, front-flush installation |
| Protection Rating | IP65 front face (panel-mounted) |
| Weight | 8,800 g (shipping weight) |
| SKU / Order Code | VCP05.1BSN.PB-NN-PW |
| Condition | New / Surplus / Refurbished — confirm at inquiry |
Why Engineers Specify This Model
- Native Rexroth Ecosystem Fit — Designed to pair directly with IndraControl L/M/XM controllers and IndraDrive servo drives, eliminating gateway hardware and reducing commissioning time.
- PROFIBUS-DP Ready — The PB suffix confirms onboard PROFIBUS-DP connectivity, making it drop-in compatible with the world’s most widely installed fieldbus network in manufacturing.
- Compact Footprint — The VCP05 form factor fits tight control-cabinet doors and machine-side enclosures where larger panels cannot be accommodated.
- 24 V DC Operation — Standard industrial supply voltage (PW suffix) simplifies power distribution and eliminates the need for a dedicated AC transformer.
- Rugged Membrane Keypad — Sealed against dust and splash, suitable for metalworking coolant mist and light washdown environments.
- Long Product Lifecycle — Rexroth’s industrial product lines carry extended availability commitments, reducing obsolescence risk for OEMs building multi-year production runs.
Complete System Bill of Materials
For a fully operational VCP05-based HMI station, engineers typically source the following alongside this terminal:
- PROFIBUS-DP cable (shielded, 9-pin D-Sub connectors) — e.g., Siemens 6XV1830-0EH10
- PROFIBUS termination resistor plugs (both ends of the DP segment)
- 24 V DC DIN-rail power supply (e.g., Phoenix Contact QUINT series, ≥ 3 A)
- Panel cut-out gasket and mounting clamps (included or sourced per Rexroth installation guide)
- IndraControl or compatible PLC with PROFIBUS-DP master port
- WinStudio / IndraWorks HMI project software for screen configuration
- Grounding / shielding bus bar for cabinet EMC compliance
Contact support@konmask.com to source any of the above components as a bundled order.
Compliance & Industry Standards
- CE Marking — Compliant with EU Machinery Directive and EMC Directive as part of the Rexroth VCP05 product family.
- PROFIBUS International — DP protocol conformance per IEC 61158 / EN 50170.
- UL / cUL — Listed under applicable industrial control equipment standards (verify certificate on Rexroth product documentation).
- RoHS — Manufactured in compliance with EU RoHS Directive 2011/65/EU.
- IP65 Front Protection — Per IEC 60529 when correctly panel-mounted with supplied gasket.
Quality Assurance & Sourcing
Konmask.com specialises in industrial automation components for B2B buyers who cannot afford downtime. Our sourcing and QA process for the VCP05.1BSN.PB-NN-PW includes:
- Visual and functional inspection prior to dispatch
- Traceability documentation retained (batch/serial records where available)
- Anti-static packaging with humidity indicator cards for long-haul shipment
- Optional third-party test report available on request for critical applications
- Transparent condition grading: New OEM, Surplus New, or Certified Refurbished — stated clearly on invoice
How to Source This Part
- Confirm your requirement — Verify the full part number VCP05.1BSN.PB-NN-PW against your Rexroth system documentation or existing BOM.
- Request a quote — Email support@konmask.com or call +0086 19859288691 with your required quantity and delivery deadline.
- Receive proforma invoice — We confirm stock condition, lead time, and pricing within 1 business day.
- Place order & arrange payment — T/T bank transfer, PayPal, or platform checkout accepted.
- Shipment & tracking — Dispatched via DHL / FedEx / SF Express with full tracking; export documentation provided for cross-border orders.
Application-Specific FAQ
Q: Can the VCP05.1BSN.PB-NN-PW communicate with a Siemens S7 PLC over PROFIBUS-DP?
A: Yes. The terminal’s PROFIBUS-DP interface is protocol-standard compliant (IEC 61158), so it can operate as a DP slave on any PROFIBUS master network, including Siemens S7-300/400/1500 with CP or integrated DP ports.
Q: What HMI software is used to develop screens for this terminal?
A: Bosch Rexroth’s IndraWorks or WinStudio engineering environment is the native toolchain. Third-party PROFIBUS-DP masters may use GSD files provided by Rexroth for integration.
Q: Is this unit available new or only as surplus?
A: Konmask.com stocks both new OEM and surplus-new units depending on current inventory. Contact us to confirm availability and condition at time of order.
Q: What is the lead time for international orders?
A: In-stock units typically ship within 2–3 business days. Express international delivery (DHL/FedEx) is 3–7 business days to most destinations. Custom clearance timelines vary by country.
Q: Can you supply a full machine retrofit kit including the PLC and drives?
A: Yes. Konmask.com offers multi-line BOM sourcing for Rexroth, Siemens, ABB, and other major automation brands. Submit your full BOM to support@konmask.com for a consolidated quote.
