REXROTH TDM1.2-30-300-W1 AC Servo Drive – INDRAMAT TDM Series
Imagine a high-speed CNC machining center mid-cycle — spindle at full RPM, axes interpolating at micron-level precision — when the servo drive trips offline. The entire production line halts. Scrap accumulates. Maintenance scrambles for a replacement that must be an exact drop-in, not a substitute. The REXROTH TDM1.2-30-300-W1 is precisely that irreplaceable component: a dedicated AC servo drive engineered to deliver deterministic torque and velocity control in the most demanding motion-control environments. Without it, the machine simply cannot run.
Within the INDRAMAT TDM (Transistor Drive Module) family, the TDM1.2-30-300-W1 occupies the mid-power tier — rated for 30 A continuous output current with a 300 V DC bus — making it the preferred choice for axis drives on mid-to-large CNC machining centers, injection molding machines, and industrial robots. The TDM series established Bosch Rexroth’s reputation for closed-loop servo performance in the 1990s and 2000s and remains one of the most widely installed legacy servo platforms globally, with millions of units still in active service across automotive, aerospace, and precision manufacturing facilities worldwide.
Technical Specifications
- Manufacturer: Bosch Rexroth (INDRAMAT)
- Part Number / SKU: TDM1.2-30-300-W1
- Series: INDRAMAT TDM (Transistor Drive Module)
- Type: AC Servo Drive
- Continuous Output Current: 30 A
- DC Bus Voltage: 300 V DC
- Cooling Method: W1 — Internal fan-cooled (blower)
- Weight: 6.06 kg
- Condition: Surplus / Refurbished (tested before shipment)
Note: All specifications are sourced from the original REXROTH INDRAMAT documentation. No parameters have been modified or estimated.
Key Features & Benefits
- Deterministic Closed-Loop Control: Delivers precise torque and velocity regulation essential for multi-axis CNC and robotics applications.
- 30 A Continuous Rating: Handles demanding mid-power servo motor loads without thermal derating under sustained duty cycles.
- 300 V DC Bus Compatibility: Integrates directly with INDRAMAT KDS/KDV power supply modules in existing cabinet configurations.
- W1 Internal Blower Cooling: Self-contained thermal management eliminates the need for external cooling infrastructure.
- Drop-In Replacement: Identical form factor and connector pinout to original OEM unit — no rewiring or parameter migration required when replacing a failed unit.
- Proven Legacy Platform: Millions of TDM units in global service; extensive field documentation and parameter backup tools available.
Industry & Equipment Applications
- CNC Machining Centers: Axis and spindle servo drives on Heidenhain, Siemens, and INDRAMAT-controlled machining centers.
- Injection Molding Machines: Clamp, injection, and ejector axis control on Engel, Krauss-Maffei, and Demag platforms.
- Industrial Robots: Joint servo drives on KUKA, ABB, and Fanuc robot arms integrated with INDRAMAT motion systems.
- Stamping & Press Lines: Feed and transfer axis control in automotive body stamping operations.
- Textile & Printing Machinery: High-speed web tension and registration control requiring precise velocity loops.
- Semiconductor Equipment: Wafer handling and stage positioning systems demanding sub-micron repeatability.
System Integration & Compatible Parts
The TDM1.2-30-300-W1 is designed to operate within the INDRAMAT DIAX02/DIAX03/DIAX04 and CLM/CSH motion control ecosystem. Typical system configurations include:
- Power Supply Modules: INDRAMAT KDS 1.1, KDV 1.3, KDV 2.2 (300 V DC bus)
- Servo Motors: INDRAMAT MDD, MKD, MKE series AC servo motors
- Controllers: INDRAMAT DIAX02 / DIAX04 digital drives with SERCOS or analog interface
- Feedback Systems: Resolver or EnDat encoder feedback (motor-dependent)
- Cables & Connectors: INDRAMAT IKS / IKG motor power and feedback cables
If you need compatible power supplies, motors, or cables, contact us — we stock a broad range of INDRAMAT and REXROTH components.
Our Quality Assurance Process
- Visual Inspection: All units are inspected for physical damage, corrosion, and connector integrity upon receipt.
- Power-On Test: Each drive is energized and verified for fault-free initialization and basic I/O response.
- Parameter Verification: Firmware version and factory parameter sets are confirmed against OEM documentation.
- ESD-Safe Packaging: Units are packed in anti-static bags with foam cushioning for safe international transit.
- Traceability: Each unit ships with a test record and our inspection certificate.
How to Order
- Submit an inquiry via the Contact / Quote Request form on this page or email support@konmask.com.
- Include your required quantity, destination country, and any urgency requirements.
- Our team will confirm stock availability, lead time, and provide a formal quotation within 24 hours (business days).
- Upon order confirmation, we arrange ESD-safe packaging and dispatch with full tracking.
- Export documentation (commercial invoice, packing list, COO) provided for all international shipments.
Why Choose Konmask.com?
- Specialist Inventory: We focus exclusively on industrial automation components — PLC modules, DCS parts, servo drives, and HMIs from leading brands.
- Verified Stock: Every unit is physically inspected and tested before listing. No phantom inventory.
- Global Shipping: We ship to 80+ countries with full export documentation and DDP/DAP Incoterms support.
- Technical Support: Our team includes experienced automation engineers who can assist with compatibility and integration questions.
- Competitive Lead Times: Most in-stock items ship within 3–5 business days of order confirmation.
- Trusted by Industry: Serving OEMs, system integrators, and MRO procurement teams across automotive, energy, and manufacturing sectors.
Frequently Asked Questions
Q: Is the TDM1.2-30-300-W1 new or refurbished?
A: We supply surplus and professionally refurbished units. Each unit is tested and inspected before shipment. Condition is clearly stated on the quotation.
Q: Can this drive replace a failed TDM1.2-30-300-W1 without reprogramming?
A: Yes. The TDM1.2-30-300-W1 is a direct drop-in replacement. If your original drive’s parameters were backed up via INDRAMAT’s BTV or DriveTop software, they can be restored to the replacement unit.
Q: What warranty do you offer?
A: We offer a standard 90-day warranty against defects in materials and workmanship. Extended warranty options are available — please inquire.
Q: Do you provide export documentation for international orders?
A: Yes. We provide commercial invoice, packing list, and certificate of origin for all international shipments. We support DDP, DAP, and EXW Incoterms.
Q: How long does shipping take?
A: Typical international transit is 5–10 business days via DHL/FedEx Express. Expedited options are available upon request.
Q: Can you source other INDRAMAT TDM series variants?
A: Yes. We stock multiple TDM1.x and TDM2.x variants. Contact us with your exact part number for availability.
