Proportional Valve Control Solution – Rexroth VT5035-17 | VT5035 Amplifier Card Series
Where This Product Is Used
The Rexroth VT5035-17 Amplifier Card is a dedicated electronic control card designed to drive Rexroth proportional directional control valves and proportional pressure/flow valves in closed-loop and open-loop hydraulic systems. It is widely deployed across the following industrial sectors:
- Injection Molding Machines – Precise pressure and flow control during clamping, injection, and holding phases, ensuring consistent shot quality and cycle repeatability.
- Metal Forming & Press Systems – Servo-hydraulic press control requiring smooth ramp-up, force regulation, and position feedback integration.
- Steel Mill & Rolling Mill Equipment – High-force hydraulic actuator control in continuous casting, rolling, and strip tension systems.
- Plastic Extrusion Lines – Proportional back-pressure and screw-speed control for consistent melt quality.
- Marine & Offshore Hydraulics – Deck machinery, thruster control, and stabilizer systems requiring robust proportional valve amplification.
- Industrial Test Rigs & Simulation Benches – Fatigue testing, material testing, and hardware-in-the-loop (HIL) hydraulic simulation platforms.
- Mobile Hydraulics & Construction Equipment – Crane, excavator, and boom control systems integrating Rexroth proportional valve technology.
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Bosch Rexroth AG |
| Part Number | VT5035-17 |
| Series | VT5035 Proportional Amplifier Card |
| Card Type | Amplifier / Driver Card for Proportional Valves |
| Compatible Valves | Rexroth 4WRPH, 4WRKE, DBET, DBEM, DREM series proportional valves |
| Supply Voltage | 24 V DC (±15% tolerance) |
| Output Current | Proportional solenoid driver output (mA range, model-dependent) |
| Command Signal Input | ±10 V DC / 4–20 mA (configurable) |
| Enable Input | Digital enable signal (24 V DC logic) |
| Ramp Function | Adjustable ramp-up / ramp-down via onboard potentiometers |
| Dither Frequency | Adjustable (typically 50–200 Hz) |
| Mounting Format | DIN rail / panel-mount card (Euro card format) |
| Operating Temperature | 0 °C to +50 °C |
| Protection Class | IP20 (card-level) |
| Weight | Approx. 40 g (card only) |
| Certifications | CE marked; RoHS compliant |
Note: Detailed electrical parameters are available in Rexroth data sheet RE 30028. Contact us for the full technical documentation.
Why Engineers Specify This Model
- Drop-in Replacement Compatibility – The VT5035-17 is a direct replacement for legacy Rexroth amplifier cards in existing control cabinets, minimizing retrofit engineering time and downtime.
- Onboard Adjustment Flexibility – Potentiometer-accessible ramp, gain, dither, and zero-offset settings allow field calibration without external programming tools.
- Stable Proportional Control – Precision current regulation to the solenoid coil ensures linear valve response and repeatable positioning accuracy.
- Robust Industrial Design – Designed to Rexroth’s industrial-grade standards for vibration resistance, EMC immunity, and long service life in harsh factory environments.
- Broad Valve Compatibility – Supports a wide range of Rexroth proportional valve families, reducing the number of spare card variants required in a plant.
- Proven Global Install Base – Thousands of units deployed worldwide in mission-critical hydraulic systems across automotive, steel, plastics, and energy sectors.
Complete System Bill of Materials
For a fully functional Rexroth proportional valve control system, the following components are typically specified alongside the VT5035-17:
- Rexroth Proportional Directional Valve (e.g., 4WRPH 6 C3 B / 24Z4/M series)
- Rexroth VT-VSPA1 or VT-VSPA2 Power Supply Card (24 V DC regulated)
- Rexroth VT-HACD Hydraulic Axis Controller (for closed-loop position control)
- Linear Position Transducer / LVDT (for closed-loop feedback)
- Pressure Transducer (0–10 V or 4–20 mA output)
- DIN Rail Mounting Rack / Card Cage (Rexroth VT-RACK or equivalent)
- 24 V DC Power Supply Unit (Siemens SITOP or Phoenix Contact QUINT series)
- Shielded Signal Cable (for command and feedback wiring)
- Hydraulic Power Unit (HPU) with appropriate pump and reservoir
Contact Konmask for complete system sourcing and BOM verification support.
Compliance & Industry Standards
- CE Marking – Compliant with EU Machinery Directive and EMC Directive requirements.
- RoHS Directive – Restriction of Hazardous Substances compliant for EU market access.
- ISO 4413 – Designed for integration into hydraulic systems conforming to ISO 4413 (Hydraulic fluid power — General rules and safety requirements).
- IEC 61000 – EMC immunity and emission standards for industrial environments.
- Bosch Rexroth Internal Quality Standards – Manufactured under Rexroth’s ISO 9001-certified production and quality management system.
Quality Assurance & Sourcing
Konmask.com specializes in the procurement and supply of genuine and certified industrial automation components for B2B customers globally. For the Rexroth VT5035-17 Amplifier Card:
- Authenticity – All units are sourced from authorized distributors or verified surplus channels. Counterfeit screening is applied to every batch.
- Inspection – Each card undergoes visual inspection, label verification, and where applicable, functional bench testing prior to dispatch.
- Packaging – Anti-static ESD packaging with moisture barrier and shock-absorbing foam insert for safe international transit.
- Documentation – Certificate of conformity, packing list, and original manufacturer data sheet available upon request.
- Warranty – 12-month warranty against manufacturing defects. Replacement or full refund policy for verified defective units.
- Lead Time – In-stock units ship within 1–3 business days. Ex-stock and sourced units: 5–15 business days depending on origin.
How to Source This Part
- Confirm Your Part Number – Verify the full Rexroth material number on your existing card or system documentation (e.g., VT5035-17/1X or variant suffix).
- Request a Quote – Contact Konmask via email at support@konmask.com or WhatsApp/phone at +0086 19859288691 with your part number and required quantity.
- Receive Availability & Pricing – Our team will confirm stock status, lead time, and pricing within 24 business hours.
- Place Order & Confirm Payment – Secure payment via T/T bank transfer, PayPal, or other agreed methods. Proforma invoice issued upon order confirmation.
- Shipment & Tracking – Units dispatched via DHL, FedEx, or UPS Express with full tracking. Export documentation (commercial invoice, packing list, COO) included.
- After-Sales Support – Technical support available for installation, wiring, and commissioning questions post-delivery.
Application-Specific FAQ
Q: Is the VT5035-17 compatible with my existing Rexroth proportional valve without rewiring?
A: In most cases, yes. The VT5035-17 is designed as a plug-compatible replacement within the VT5035 series. However, always verify the solenoid coil resistance and command signal type against your existing wiring before installation.
Q: Can this card be used with non-Rexroth proportional valves?
A: The VT5035-17 is optimized for Rexroth solenoid specifications. Use with third-party valves is possible if the solenoid coil impedance and current requirements fall within the card’s output range, but is not officially supported by Rexroth.
Q: What is the difference between VT5035-17 and VT5035-1X?
A: The suffix (e.g., /1X, /2X, /17) typically denotes the design series or hardware revision. The /17 suffix indicates a specific revision with defined feature set. Contact Konmask to confirm cross-compatibility with your application.
Q: Do you supply the full Rexroth VT5035 series?
A: Yes. Konmask stocks and sources multiple variants across the VT5035 amplifier card family. Contact us with your specific part number for availability.
Q: Can Konmask provide technical support for commissioning?
A: Yes. Our engineering support team can assist with wiring diagrams, parameter setup, and troubleshooting via email or video call.
