Industrial Motion Control Solution – SANYO DENKI PQM1A150A5PGSSA | SANMOTION P Series
Where This Product Is Used
The SANYO DENKI PQM1A150A5PGSSA AC servo driver is engineered for demanding industrial motion control environments. Typical deployment scenarios include:
- CNC Machining Centers – Precision axis control for milling, turning, and grinding operations requiring sub-micron positioning repeatability.
- Industrial Robotics – Joint actuation in articulated arms, SCARA robots, and gantry systems where dynamic response and torque accuracy are critical.
- Automated Assembly Lines – Pick-and-place, press-fit, and conveyor indexing applications demanding synchronized multi-axis coordination.
- Semiconductor & Electronics Manufacturing – Wafer handling, PCB drilling, and SMT placement equipment requiring ultra-low vibration and high-speed positioning.
- Packaging Machinery – Servo-driven filling, sealing, and labeling systems with high cycle rates and precise torque control.
- Textile & Printing Equipment – Tension control and registration systems where consistent speed regulation is essential.
Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | PQM1A150A5PGSSA |
| Brand | SANYO DENKI |
| Series | SANMOTION P |
| Drive Type | AC Servo Driver |
| Rated Output | 1.5 kW |
| Input Voltage | 200–230 V AC, 3-Phase |
| Control Mode | Position / Speed / Torque |
| Encoder Interface | Incremental / Absolute (model-dependent) |
| Communication | Pulse train input; optional fieldbus |
| Protection Class | IP20 |
| Cooling Method | Forced air cooling |
| Weight | Approx. 300 g |
| Compliance | CE, UL, RoHS |
Why Engineers Specify This Model
- High-Resolution Positioning – SANMOTION P Series delivers exceptional encoder resolution for tight tolerance applications.
- Robust Vibration Suppression – Built-in adaptive notch filters minimize mechanical resonance, extending machine life.
- Flexible Control Architecture – Supports position, speed, and torque control modes, compatible with major PLC brands including Mitsubishi, Siemens, Omron, and Fanuc.
- Compact Form Factor – Space-efficient design simplifies panel integration in retrofit and new-build control cabinets.
- Proven Reliability – SANYO DENKI’s SANMOTION series is trusted in mission-critical production environments globally.
Complete System Bill of Materials
For a fully operational servo axis, engineers typically specify the following alongside the PQM1A150A5PGSSA:
- SANYO DENKI SANMOTION P Series AC Servo Motor (matched 1.5 kW rating)
- Regenerative resistor unit (for high-inertia or frequent deceleration cycles)
- EMC line filter (CE compliance for conducted emissions)
- 24 VDC control power supply
- Encoder cable (shielded, matched to motor encoder type)
- Motor power cable (shielded, rated for servo duty)
- PLC or motion controller with pulse/analog output or fieldbus master
- DIN rail mounting hardware and terminal blocks
Compliance & Industry Standards
- CE Marking – Low Voltage Directive (LVD) and EMC Directive compliant.
- UL Listed – Recognized for use in North American industrial installations.
- RoHS Compliant – Meets EU Restriction of Hazardous Substances requirements.
- ISO 9001 – Manufactured under SANYO DENKI’s certified quality management system.
Quality Assurance & Sourcing
Konmask.com sources the PQM1A150A5PGSSA through verified industrial distribution channels. Each unit undergoes incoming inspection including:
- Visual and mechanical integrity check
- Label and serial number authentication against manufacturer records
- Functional power-on verification where applicable
- Anti-static packaging for safe transit
We supply OEM-original parts only. No refurbished or counterfeit stock.
How to Source This Part
- Add the PQM1A150A5PGSSA to your cart and proceed to checkout.
- For volume orders (5+ units), contact support@konmask.com for a dedicated quote.
- Lead time: In-stock units ship within 1–3 business days. Out-of-stock lead time quoted on request.
- Global shipping available. Export documentation (commercial invoice, packing list, COO) provided upon request.
- For urgent requirements, call/WhatsApp: +0086 19859288691
Application-Specific FAQ
Q: Is the PQM1A150A5PGSSA compatible with Mitsubishi MELSEC PLCs?
A: Yes. The driver accepts standard pulse train (PULSE/DIR or CW/CCW) signals output by Mitsubishi Q/L/iQ-R series PLCs. Verify I/O voltage levels before wiring.
Q: Can this driver be used for vertical axis (gravity load) applications?
A: Yes, with appropriate configuration of the holding brake output and regenerative resistor sizing. Contact our technical team for axis-specific recommendations.
Q: What is the difference between PQM1A150A5PGSSA and similar SANMOTION P models?
A: The suffix characters encode rated current, voltage class, encoder type, and option codes. The PQM1A150A5PGSSA is a 1.5 kW, 200 V class unit. Contact us to cross-reference alternative models.
Q: Do you provide a warranty?
A: Yes. All units carry a 12-month warranty against manufacturing defects from the date of shipment.
Q: Can you supply the matching SANMOTION P servo motor?
A: Yes. Contact us with your torque, speed, and encoder requirements and we will recommend the correct motor pairing.
