Schneider Electric 140CPU43412A – High-Performance PLC CPU Module | Modicon Quantum Platform
Engineering Background: The Modicon Quantum series represents Schneider Electric’s flagship programmable automation controller platform, engineered for mission-critical process and discrete manufacturing environments. Introduced as the successor to the Modicon 984 architecture, the Quantum platform delivers deterministic scan performance, hot-standby redundancy capability, and an open I/O backplane that supports thousands of distributed I/O points across a single control domain.
Product Positioning: The 140CPU43412A is a mid-to-high range CPU within the Quantum family, targeting applications that demand substantial user memory, multi-network connectivity, and reliable real-time execution. It is the preferred choice for petrochemical, power generation, water treatment, and large-scale discrete assembly lines where downtime is not an option.
Complete Technical Specifications
| Part Number | 140CPU43412A |
| Platform | Modicon Quantum |
| Manufacturer | Schneider Electric (formerly Modicon) |
| CPU Type | 32-bit RISC Processor |
| User Memory (RAM) | 512 KB |
| Executive Memory (Flash) | 2 MB |
| Max I/O Points | Up to 64,000 discrete / 4,000 analog |
| Max Local Racks | 16 racks (with CRP modules) |
| Communication Ports | Modbus Plus (2×), RS-232 Modbus (1×) |
| Ethernet Option | Via 140NOE module (not onboard) |
| Programming Software | Unity Pro / Control Expert |
| IEC 61131-3 Languages | LD, FBD, SFC, ST, IL |
| Scan Time | ~0.1 ms/K boolean instructions |
| Hot Standby Redundancy | Supported (with 140CPS redundancy modules) |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Relative Humidity | 5% to 95% non-condensing |
| Power Supply Voltage | 5 VDC (via backplane) |
| Power Consumption | ≤ 3.5 W (backplane) |
| Weight | Approx. 580 g |
| Mounting | Quantum backplane rack (Slot 1) |
| Certifications | CE, UL, CSA, FM Class I Div 2 |
| Country of Origin | France |
| RoHS Compliance | Yes |
Proven Application Environments
- Oil & Gas: Pipeline SCADA, compressor station control, emergency shutdown systems (ESD)
- Power Generation: Turbine sequencing, boiler management, substation automation
- Water & Wastewater: Pump station control, SCADA integration, dosing systems
- Petrochemical: Batch reactor control, distillation column management, DCS integration
- Discrete Manufacturing: Automotive assembly, press line control, conveyor systems
- Building Automation: Large HVAC systems, chiller plant management
Engineering Advantages
- Dual Modbus Plus Ports: Enables peer-to-peer networking with up to 64 nodes per segment without additional hardware, reducing wiring complexity in distributed architectures.
- 512 KB User RAM: Sufficient for complex ladder logic programs with extensive data tables, PID loops, and structured data blocks — no memory expansion modules required for most applications.
- Hot Standby Ready: Supports 1:1 CPU redundancy with bumpless transfer, critical for continuous process industries where any control interruption causes product loss or safety incidents.
- Unity Pro / Control Expert Compatibility: Full support for IEC 61131-3 structured programming, function block libraries, and online modification without stopping the PLC scan.
- Proven Field Reliability: MTBF exceeding 300,000 hours in industrial environments; widely deployed in safety-instrumented and non-safety control loops globally.
- Backward Compatibility: Drop-in replacement for earlier 140CPU43412 revisions; retains compatibility with existing Quantum I/O modules and backplanes.
System Architecture & Signal Flow
The 140CPU43412A occupies Slot 1 of any Modicon Quantum backplane rack (140XBP series). The CPU communicates with local I/O modules via the high-speed backplane bus (up to 200 Mbps internal bandwidth). Remote I/O expansion is achieved through 140CRP modules (Remote I/O Head) connected via the Quantum Remote I/O coaxial cable network, supporting up to 31 remote drops at distances up to 4,500 m. Peer-to-peer data exchange with other Quantum or Momentum PLCs is handled natively over the dual Modbus Plus ports. Ethernet connectivity for SCADA/HMI integration requires a dedicated 140NOE Ethernet module installed in an adjacent backplane slot.
Typical Signal Flow: Field Sensors → Quantum I/O Modules → Backplane Bus → 140CPU43412A (Scan & Execute Logic) → Backplane Bus → Output Modules → Actuators / Drives
Sourcing & Quality Verification
- Source: Sourced from authorized distributors, decommissioned OEM lines, and certified refurbishers — never grey-market or counterfeit channels.
- Inspection: Every unit undergoes visual inspection (PCB, connectors, firmware label), functional power-on test, and Modbus Plus communication verification before shipment.
- Firmware: Firmware version confirmed and documented; units with corrupted or unknown firmware are reflashed to the latest stable Schneider-released version.
- Packaging: Anti-static bag + foam-lined carton; humidity indicator card included for long-distance shipments.
- Warranty: 12-month replacement warranty against DOA or functional failure under normal operating conditions.
Procurement Process
- Confirm Requirement: Verify part number 140CPU43412A matches your existing Quantum rack slot and firmware revision requirements.
- Request Quote: Contact us via support@konmask.com or +0086 19859288691 for volume pricing, lead time, and availability confirmation.
- Order & Payment: Secure checkout via Shopify; T/T bank transfer and PayPal accepted for B2B orders.
- Inspection Report: Full test report and photos provided upon request before shipment.
- Shipping: DHL / FedEx / UPS express worldwide; EXW Xiamen or CIF destination available. Typical lead time: 3–7 business days.
- After-Sales: Technical support available for integration questions; RMA process initiated within 24 hours for any quality claims.
Technical FAQ
Q: Is the 140CPU43412A compatible with Unity Pro XL?
A: Yes. It is fully supported by Unity Pro (all editions) and the successor Schneider Electric Control Expert software.
Q: Can this CPU run hot standby redundancy without additional hardware?
A: The CPU supports hot standby, but requires a dedicated 140CPS redundancy power supply and a second 140CPU43412A unit configured as the standby CPU.
Q: What is the difference between 140CPU43412A and 140CPU43412?
A: The “A” suffix denotes a hardware revision with improved EMC performance and updated firmware baseline. Both are functionally interchangeable in existing Quantum racks.
Q: Does this module support Ethernet/IP natively?
A: No. Ethernet connectivity requires a separate 140NOE771x1 Ethernet module. The CPU itself provides Modbus Plus and RS-232 Modbus ports only.
Q: What programming cable is required?
A: Use the Modicon USB-to-Modbus Plus adapter (TSXCUSB485) or the RS-232 programming cable connected to the CPU’s Modbus port for Unity Pro/Control Expert communication.
