SCHNEIDER 140DDO36400 Discrete Output Module | Replacement, Equivalent & Selection Guide
The Schneider Electric 140DDO36400 is a 32-channel discrete output module designed for the Modicon Quantum PLC platform. It delivers reliable 24 VDC sourcing output capability for demanding industrial automation environments. This page provides full technical specifications, compatible replacement options, application guidance, and sourcing information to help engineers and procurement teams make confident decisions.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 140DDO36400 |
| Brand | Schneider Electric (Modicon) |
| Module Type | Discrete Output Module |
| Platform | Modicon Quantum |
| Number of Outputs | 32 channels |
| Output Voltage | 24 VDC |
| Output Type | Sourcing (PNP) |
| Output Current per Channel | 0.5 A |
| Total Output Current | 8 A max |
| Isolation | Optical isolation |
| Backplane Bus | Modicon Quantum I/O bus |
| Operating Temperature | 0 °C to 60 °C |
| Weight | 910 g |
| Certifications | CE, UL, cUL |
Compatible Replacement & Equivalent Models
When the 140DDO36400 is unavailable or end-of-life, the following models are commonly evaluated as functional replacements. Always verify electrical and firmware compatibility before substitution.
| Model | Brand | Channels | Output Type | Notes |
|---|---|---|---|---|
| 140DDO36400C | Schneider Electric | 32 | 24 VDC Sourcing | Conformal-coated variant; direct drop-in for harsh environments |
| 140DDO88500 | Schneider Electric | 32 | 24 VDC Sourcing | Higher current per channel (1 A); verify load compatibility |
| 140DDO15310 | Schneider Electric | 16 | 24 VDC Sourcing | Half-channel count; use two modules for full replacement |
| 140DDO36400 (Refurbished) | OEM | 32 | 24 VDC Sourcing | Tested & certified refurbished units available from Konmask |
Note: Third-party or cross-brand replacements may require I/O configuration changes in Unity Pro / Control Expert software.
Why Choose the Original Model
- Guaranteed firmware compatibility with Modicon Quantum racks and Unity Pro / Control Expert without re-mapping I/O addresses.
- Proven field reliability in continuous 24/7 industrial operations across process, energy, and manufacturing sectors.
- OEM support lifecycle: Schneider Electric provides long-term spare parts and technical documentation.
- Optical isolation protects the backplane from field-side transients and ground loops.
- Conformal-coat option (140DDO36400C) available for corrosive or high-humidity environments.
Typical Applications
- Solenoid valve control in oil & gas and water treatment plants
- Motor starter and contactor switching in manufacturing lines
- Conveyor and material handling system control
- Building automation and HVAC control panels
- Power generation and substation automation
- Batch process control in chemical and pharmaceutical plants
System Compatibility
- PLC Platform: Modicon Quantum (140 series)
- Racks: 140XBP01600, 140XBP00600, 140XBP00400, and all standard Quantum backplanes
- Power Supplies: 140CPS11100, 140CPS11420, 140CPS21100
- CPUs: 140CPU31110, 140CPU43412A, 140CPU65150, and all Quantum CPU modules
- Programming Software: Unity Pro XL / Schneider Control Expert (all versions)
- Communication: Compatible with Modbus Plus, Ethernet I/O, and Profibus DP adapters
Selection Guide
Use the criteria below to confirm the 140DDO36400 is the right module for your application, or to identify the best alternative:
| Requirement | Recommended Model |
|---|---|
| 32 outputs, 0.5 A/ch, standard environment | 140DDO36400 ✓ (this model) |
| 32 outputs, 0.5 A/ch, corrosive/humid environment | 140DDO36400C (conformal coat) |
| 32 outputs, higher current (1 A/ch) | 140DDO88500 |
| 16 outputs only needed | 140DDO15310 |
| Relay output required (dry contact) | 140DRA84000 or 140DRC83000 |
| AC output (120/240 VAC) | 140DAO84010 or 140DAO84000 |
Quality Assurance & Sourcing
- Origin: Genuine Schneider Electric OEM units sourced from authorized distribution channels.
- Testing: Each unit undergoes functional power-on testing and visual inspection before shipment.
- Packaging: Anti-static ESD packaging with original or equivalent protective foam.
- Warranty: 12-month warranty against manufacturing defects.
- Lead Time: In-stock units ship within 1–3 business days; contact us for bulk order lead times.
- Traceability: Serial number and date code documentation available on request.
How to Order
- Confirm your part number: 140DDO36400
- Specify quantity and required delivery date.
- Contact us via email or phone for a formal quotation.
- Submit a purchase order — we accept T/T, L/C, and major payment platforms.
- Receive tracking information within 24 hours of shipment.
📧 Email: support@konmask.com
📞 Phone/WhatsApp: +0086 19859288691
🌐 Website: https://Konmask.com
Replacement & Compatibility FAQ
Q: Can I replace 140DDO36400 with 140DDO36400C without software changes?
A: Yes. The conformal-coat variant is a direct hardware drop-in with identical I/O mapping and firmware behavior.
Q: Is the 140DDO36400 still in production?
A: Schneider Electric has transitioned some Quantum series modules to end-of-life status. Konmask maintains stock of both new and certified-refurbished units. Contact us to confirm current availability.
Q: Can this module work with a Modicon Premium or M340 rack?
A: No. The 140DDO36400 is exclusively designed for the Modicon Quantum (140 series) backplane and is not cross-compatible with Premium or M340 platforms.
Q: What is the difference between sourcing (PNP) and sinking (NPN) output?
A: Sourcing outputs supply current to the load (common negative/0V). Sinking outputs sink current from the load (common positive/24V). Verify your field device wiring before selecting a replacement.
Q: Do you provide a test report or certificate of conformance?
A: Yes. A functional test report and certificate of conformance (CoC) are available upon request for all units.
