Allen-Bradley 1769-OV16 Solid State Output Module – CompactLogix 1769 Series
Imagine a high-speed packaging line suddenly losing control of its conveyor actuators, or a water treatment plant’s valve sequencing going dark mid-cycle. Without a reliable digital output module, the entire control architecture collapses — field devices go unresponsive, safety interlocks fail to actuate, and unplanned downtime cascades into costly production losses. The Allen-Bradley 1769-OV16 is the precision interface that prevents exactly this scenario, delivering deterministic, solid-state switching between your CompactLogix controller and the 16 discrete field devices that keep your process running.
Within the CompactLogix 1769 family, the 1769-OV16 occupies the high-density, 24VDC sourcing output tier — the workhorse configuration trusted by system integrators across automotive assembly, food & beverage processing, material handling, and municipal infrastructure worldwide. As part of Rockwell Automation’s globally standardized I/O platform, this module is engineered to slot directly into any 1769 bus system, enabling rapid expansion without re-engineering the control cabinet. Its solid-state design eliminates mechanical relay wear, making it the preferred choice for applications demanding millions of switching cycles and zero tolerance for contact degradation.
Technical Specifications
- Catalog Number: 1769-OV16
- Series: A
- Platform: CompactLogix / MicroLogix 1500 (1769 I/O Bus)
- Output Type: Solid-State (Sourcing / PNP)
- Number of Output Points: 16
- Output Voltage Range: 10–28.8V DC
- Output Current per Point: 0.5A continuous
- Total Module Current: 4A maximum (all points ON)
- Backplane Current Draw (5V): 75mA
- Backplane Current Draw (24V): 0mA
- Output Delay (OFF→ON): ≤1ms
- Output Delay (ON→OFF): ≤1ms
- Short-Circuit Protection: Electronic (per point)
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Relative Humidity: 5–95% non-condensing
- Enclosure Rating: Open-style (IP20)
- Agency Certifications: UL, CE, CSA
- Weight: Approx. 200g
Note: All specifications are sourced from Rockwell Automation official documentation. Konmask.com does not fabricate or modify published parameters.
Key Features & Benefits
- 16-Point High Density: Maximizes I/O capacity per slot, reducing cabinet footprint and wiring complexity in space-constrained panels.
- Solid-State Switching: No mechanical contacts means zero arcing, zero contact wear, and a service life measured in tens of millions of operations — ideal for high-cycle applications.
- Per-Point Electronic Short-Circuit Protection: Isolates faults at the individual channel level, preventing a single wiring fault from taking down the entire output bank.
- Sub-millisecond Response: ≤1ms ON/OFF delay ensures tight synchronization with fast-moving process equipment and servo-driven axes.
- Plug-and-Play 1769 Bus Compatibility: Side-mount bus connector enables tool-free installation and hot-swap capability (with appropriate controller configuration).
- Diagnostic LED per Channel: Green status LEDs provide instant visual confirmation of output state, accelerating fault isolation during commissioning and maintenance.
- Wide Supply Voltage Tolerance: 10–28.8V DC input range accommodates real-world power supply fluctuations without nuisance tripping.
Industry & Equipment Applications
- Automotive Manufacturing: Controlling solenoid valves, pneumatic actuators, and indicator lamps on body-in-white welding and assembly lines.
- Food & Beverage Processing: Driving conveyor motor starters, filling valve solenoids, and CIP (Clean-in-Place) sequence actuators in hygienic environments.
- Material Handling & Logistics: Activating diverter gates, sorter actuators, and zone conveyor drives in distribution center automation.
- Water & Wastewater Treatment: Sequencing pump motor contactors, valve actuators, and alarm annunciators in municipal SCADA systems.
- Oil & Gas / Chemical Processing: Interfacing with field solenoids and motor control centers in hazardous-area control panels (with appropriate enclosure).
- Machine Tool & Packaging OEM: Embedded in OEM machine builds requiring compact, reliable I/O with deterministic scan-time performance.
System Integration & Compatible Parts
The 1769-OV16 is designed for seamless integration within the Allen-Bradley CompactLogix and MicroLogix 1500 ecosystems. Compatible and commonly paired components include:
- Controllers: 1769-L16ER-BB1B, 1769-L18ER-BB1B, 1769-L24ER-QB1B, 1769-L30ER, 1769-L33ER, 1769-L36ERM
- Input Modules: 1769-IQ16 (16-pt 24VDC sink input), 1769-IA16 (16-pt 120VAC input)
- Power Supplies: 1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4
- Bus Expansion: 1769-ECR (right-end cap), 1769-ECL (left-end cap), 1769-BOOM (bus expansion cable)
- Programming Software: Studio 5000 Logix Designer v21.00 or later (RSLogix 5000 for legacy projects)
- Communication Adapters: 1769-L19ER-BB1B (EtherNet/IP), 1769-ADN (DeviceNet adapter)
Our Quality Assurance Process
Every 1769-OV16 unit sourced and supplied by Konmask.com undergoes a structured verification process before shipment:
- Authenticity Verification: Visual inspection of Rockwell Automation holographic labels, date codes, and catalog number markings against known-genuine references.
- Functional Pre-Check: Where applicable, modules are bench-tested for backplane communication and output channel continuity prior to packaging.
- Condition Grading: Units are clearly graded as New (factory-sealed), Refurbished (tested & restored), or Surplus (tested used) — no ambiguity in product condition.
- Secure Packaging: Anti-static bags, foam-lined boxes, and moisture-barrier packaging protect modules during international transit.
- Documentation: Test reports and certificates of conformance available upon request for quality-critical procurement.
How to Order
- Submit an inquiry via the Contact / RFQ form on this page with your required quantity and delivery timeline.
- Our technical team will confirm availability, condition grade, lead time, and provide a formal quotation within 1 business day.
- Upon PO confirmation, we arrange payment via T/T (bank transfer), PayPal, or other agreed terms.
- Modules are shipped via DHL / FedEx / UPS Express with full tracking and export documentation (commercial invoice, packing list).
- Post-delivery technical support is available for integration questions.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC, DCS, HMI, and industrial drive components — not a generalist marketplace.
- Global Supply Network: Access to both new and surplus Allen-Bradley inventory from verified distributor and OEM channels worldwide.
- Technical Expertise: Our team includes engineers with hands-on CompactLogix commissioning experience — we speak your language.
- Fast Response: RFQ responses within 24 hours; emergency sourcing support available for critical downtime situations.
- Transparent Grading: No misleading condition descriptions — every unit is graded and documented before it ships.
- Export Compliance: Full export documentation, EAR99 classification support, and experience shipping to 40+ countries.
Frequently Asked Questions
Q: Is the 1769-OV16 compatible with CompactLogix 5370 controllers?
A: Yes. The 1769-OV16 is compatible with all controllers that support the 1769 I/O bus, including the CompactLogix 5370 (L1, L2, L3) family, as well as MicroLogix 1500 systems.
Q: What is the difference between 1769-OV16 and 1769-OB16?
A: Both are 16-point 24VDC solid-state sourcing output modules. The 1769-OB16 is a later catalog revision with minor specification updates. The 1769-OV16 (Series A) is the original release and is functionally interchangeable in most applications. Always verify with your system’s I/O tree configuration in Studio 5000.
Q: Can I use this module for 120VAC output loads?
A: No. The 1769-OV16 is rated for 10–28.8V DC loads only. For 120VAC outputs, consider the 1769-OA16 (16-point 120VAC output module).
Q: Do you supply new or used units?
A: We supply both. All units are clearly graded (New / Refurbished / Surplus) and tested before shipment. Condition and pricing are confirmed in the quotation.
Q: What is the lead time for the 1769-OV16?
A: Lead time depends on current stock levels. Submit an RFQ and we will confirm availability and estimated delivery within 1 business day. Emergency sourcing for critical downtime is available.
Q: Is a warranty provided?
A: Yes. Konmask.com provides a 90-day functional warranty on all tested units. Extended warranty terms are available for volume orders — contact us for details.
