Schneider Electric ATV312HU22N4 Variable Speed Drive 2.2kW | Replacement, Equivalent & Selection Guide
The Schneider Electric ATV312HU22N4 is a 2.2 kW (3 HP) three-phase variable speed drive (VFD/inverter) from the Altivar 312 series, designed for simple machine applications requiring reliable motor speed control. This page provides full technical specifications, compatible replacement models, selection guidance, and sourcing information for industrial buyers and OEM engineers.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number / SKU | ATV312HU22N4 |
| Brand | Schneider Electric |
| Series | Altivar 312 (ATV312) |
| Motor Power | 2.2 kW (3 HP) |
| Supply Voltage | 380–500 V AC, 3-Phase |
| Output Current | 5.5 A |
| Frequency Input | 50/60 Hz |
| Output Frequency | 0.1–500 Hz |
| Protection Rating | IP20 |
| Control Type | V/f, Sensorless Flux Vector |
| Communication | Modbus RTU (RJ45) |
| Braking | Built-in dynamic braking transistor |
| Weight | 2.26 kg |
| Certifications | CE, UL, cUL, RoHS |
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as direct or functional replacements for the ATV312HU22N4. Always verify electrical parameters and control wiring before substitution.
| Model | Brand | Power | Voltage | Compatibility Notes |
|---|---|---|---|---|
| ATV312HU22N4 | Schneider Electric | 2.2 kW | 380–500 V 3Ø | Original — reference model |
| ATV320U22N4B | Schneider Electric | 2.2 kW | 380–500 V 3Ø | Next-gen ATV320 series; direct upgrade, same power class |
| ATV312HU22N4S6 | Schneider Electric | 2.2 kW | 380–500 V 3Ø | Variant with Safe Torque Off (STO) function |
| FR-E740-2.2K | Mitsubishi Electric | 2.2 kW | 380–480 V 3Ø | Functional equivalent; different I/O wiring required |
| G120C-2.2/3 | Siemens | 2.2 kW | 380–480 V 3Ø | Functional equivalent; Profibus/PN option available |
| ACH580-01-05A6-4 | ABB | 2.2 kW | 380–480 V 3Ø | Functional equivalent; HVAC-optimized variant |
| PowerFlex 523-2P5 | Allen-Bradley | 2.2 kW | 380–480 V 3Ø | Functional equivalent; EtherNet/IP native |
⚠ Note: Third-party replacements require re-parameterization and wiring verification. Konmask recommends using original Schneider Electric parts for warranty-critical applications.
Why Choose the Original ATV312HU22N4
- Proven reliability — Millions of units deployed globally in OEM and panel-builder applications
- Native Modbus RTU — Plug-and-play integration with Schneider PLCs (M221, M241, Modicon) and third-party SCADA
- Compact footprint — Optimized for control cabinet space with DIN-rail or panel mounting
- Sensorless flux vector control — High starting torque without encoder feedback
- Built-in braking transistor — Reduces BOM cost for applications with regenerative loads
- Extensive parameter library — Compatible with SoMove software for offline commissioning
Typical Applications
- Conveyor and material handling systems
- Pump and fan speed control (HVAC, water treatment)
- Compressor and blower drives
- Packaging and food processing machinery
- Textile and printing equipment
- OEM machine tool spindle drives
System Compatibility
The ATV312HU22N4 integrates seamlessly with the following Schneider Electric ecosystems and third-party systems:
- PLCs: Modicon M221, M241, M251, M340; Zelio Logic; third-party Modbus RTU masters
- HMIs: Magelis HMIGTO/HMISCU series; Vijeo Designer
- Software: SoMove (free commissioning tool), EcoStruxure Machine Expert
- Communication options: CANopen, DeviceNet, PROFIBUS DP via optional VW3A3608/VW3A3609 cards
- Motors: Standard IEC/NEMA induction motors 380–500 V, 2.2 kW class
Selection Guide
Use the table below to select the correct ATV312 variant for your application:
| Requirement | Recommended Model |
|---|---|
| Standard 2.2 kW, 3-phase 400 V | ATV312HU22N4 ✓ |
| 2.2 kW with STO safety function | ATV312HU22N4S6 |
| 2.2 kW, single-phase 200–240 V input | ATV312HU22M2 |
| Upgrade to newer platform (same power) | ATV320U22N4B |
| Higher power (4 kW, 400 V) | ATV312HU40N4 |
| Lower power (1.5 kW, 400 V) | ATV312HU15N4 |
Naming convention: ATV312 H = IP20 | U22 = 2.2 kW | N4 = 380–500 V 3-phase
Quality Assurance & Sourcing
- ✅ Genuine Schneider Electric product — sourced from authorized distribution channels
- ✅ Factory sealed — original packaging with holographic authenticity label
- ✅ Batch traceability — serial number and date code verification available on request
- ✅ Pre-shipment inspection — visual and functional check before dispatch
- ✅ Export documentation — commercial invoice, packing list, and COO certificate provided
How to Order
- Confirm your motor power (kW/HP), supply voltage, and phase requirements
- Verify the part number: ATV312HU22N4
- Add to cart or contact us for bulk pricing and lead time
- Provide your shipping address and preferred Incoterm (EXW/FOB/CIF)
- Payment: T/T, PayPal, or trade assurance accepted
📧 Email: [email protected] | 📞 WhatsApp/Tel: +0086 19859288691
Replacement & Compatibility FAQ
Q: Can the ATV320U22N4B directly replace the ATV312HU22N4?
A: Yes, the ATV320 is the recommended next-generation replacement. Power and voltage ratings are identical; however, terminal layout and parameter mapping differ — refer to Schneider’s migration guide (document NVE41289).
Q: Is the ATV312HU22N4 compatible with single-phase input?
A: No. The N4 suffix denotes 3-phase 380–500 V input only. For single-phase 220 V, select the ATV312HU22M2.
Q: Can I use a third-party VFD as a drop-in replacement?
A: Electrically possible if ratings match, but control wiring, parameter settings, and communication protocols must be reconfigured. Konmask recommends original parts for critical applications.
Q: What is the warranty on this product?
A: Konmask provides a 12-month warranty against manufacturing defects. Schneider Electric’s standard warranty terms apply for factory-sealed units.
Q: Do you provide installation support?
A: Yes. Our technical team can assist with wiring diagrams, parameter setup, and SoMove configuration files. Contact us via email or WhatsApp.
