Analog Signal Conditioning Solution – Schneider Electric 140AMM09000 | Modicon Quantum Series
Where This Product Is Used
The Schneider Electric 140AMM09000 is a mixed analog I/O module designed for the Modicon Quantum PLC platform. It is deployed across demanding industrial environments where precise analog signal acquisition and output control are critical to process integrity. Typical installation sites include:
- Oil & Gas Processing Plants – Monitoring pressure transmitters, flow meters, and temperature sensors across pipeline segments; driving control valves via 4–20 mA output loops.
- Water & Wastewater Treatment Facilities – Closed-loop level and flow control in clarifiers, dosing systems, and pump stations requiring simultaneous multi-channel analog I/O.
- Power Generation & Utilities – Turbine governor feedback loops, generator excitation control, and substation SCADA integration where signal fidelity is non-negotiable.
- Chemical & Pharmaceutical Manufacturing – Reactor temperature profiling, pH and conductivity monitoring, and batch process control under cGMP or ATEX-adjacent requirements.
- Automotive & Heavy Industry – Press force monitoring, conveyor tension control, and robotic welding current feedback in high-cycle production lines.
- Building Automation & HVAC – VAV damper positioning, chiller plant optimization, and BMS integration via analog setpoint signals.
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | 140AMM09000 |
| Brand | Schneider Electric (Modicon) |
| Series | Modicon Quantum |
| Module Type | Mixed Analog Input / Output |
| Analog Inputs | 4 Channels |
| Analog Outputs | 2 Channels |
| Input Signal Range | 4–20 mA / 0–10 V (configurable per channel) |
| Output Signal Range | 4–20 mA / 0–10 V (configurable per channel) |
| Resolution | 12-bit (4096 steps) |
| Isolation | Optical isolation between field and backplane |
| Backplane Bus | Modicon Quantum local / remote I/O rack |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Relative Humidity | 5–95% non-condensing |
| Weight | 450 g (approx.) |
| Mounting | Quantum I/O rack slot (local or remote) |
| Certifications | CE, UL, cUL |
Why Engineers Specify This Model
- Consolidated I/O Density – Combining 4 inputs and 2 outputs in a single slot reduces rack space consumption and lowers total BOM cost versus separate dedicated modules.
- Flexible Signal Configuration – Per-channel configurability between current (4–20 mA) and voltage (0–10 V) modes accommodates heterogeneous field instrumentation without additional signal conditioners.
- Native Quantum Integration – Plug-and-play compatibility with Unity Pro / Control Expert software; no custom driver development required. Channel mapping is automatic via rack addressing.
- 12-Bit Resolution – Provides 0.024% full-scale resolution, meeting the accuracy demands of most process control loops without requiring higher-cost 16-bit modules.
- Optical Isolation – Protects the PLC backplane from field-side ground loops, transients, and common-mode noise — essential in electrically noisy industrial environments.
- Proven Platform Longevity – The Modicon Quantum platform has an extensive installed base with long-term spare parts availability, making the 140AMM09000 a low-risk specification for brownfield expansions and MRO procurement.
Complete System Bill of Materials
For a fully operational Modicon Quantum analog control node, the following components are typically required alongside the 140AMM09000:
- CPU Module – e.g., 140CPU65160 or 140CPU67160 (Hot Standby)
- Power Supply Module – e.g., 140CPS11420 (115/230 VAC input)
- I/O Rack – e.g., 140XBP01600 (16-slot local rack)
- Communication Module – e.g., 140NOE77101 (Ethernet TCP/IP) or 140NOM21100 (Modbus Plus)
- Field Wiring Terminal Block – Compatible Quantum I/O terminal block for 140AMM09000 (verify pinout per hardware reference manual)
- Shielded Instrumentation Cable – 2-conductor shielded, 18–22 AWG, for 4–20 mA field loops
- DIN Rail & Enclosure – Rated for installation environment (IP54 minimum recommended for plant floor)
Contact Konmask for complete system quotations and compatibility verification.
Compliance & Industry Standards
- CE Marking – Compliant with EU Low Voltage Directive and EMC Directive
- UL / cUL Listed – Recognized for use in North American industrial control panels
- IEC 61131-2 – Programmable controller hardware standard compliance
- RoHS – Restriction of Hazardous Substances compliant
- WEEE – Registered for proper end-of-life disposal in applicable regions
Buyers operating under IEC 61511 (functional safety) or ISO 13849 frameworks should verify SIL/PLd suitability with their system integrator prior to specification.
Quality Assurance & Sourcing
Konmask.com sources the 140AMM09000 through verified industrial distribution channels with full traceability. Every unit offered is subject to the following quality controls:
- Visual Inspection – Label authenticity, housing integrity, connector condition, and date code verification
- Functional Pre-check – Power-on self-test and backplane communication verification where applicable
- Anti-Counterfeit Screening – Cross-referenced against known genuine Schneider Electric part markings and holographic label standards
- Documented Traceability – Batch records and sourcing documentation available upon request for regulated industries
- Packaging – Shipped in ESD-safe packaging with desiccant; original OEM packaging preserved where available
How to Source This Part
- Add to Cart – Click “Add to Cart” above to proceed directly to checkout.
- Request a Quote – For volume orders (5+ units), OEM pricing, or project-based procurement, email [email protected] with your project details and required delivery timeline.
- Expedited Availability – If you have a critical shutdown or emergency MRO requirement, call or WhatsApp +0086 19859288691 for same-day response.
- System Integration Support – Our technical team can assist with rack configuration, compatibility checks, and Unity Pro / Control Expert parameter setup.
Application-Specific FAQ
Q: Can the 140AMM09000 be used in a remote I/O drop?
A: Yes. It is compatible with both local Quantum racks and remote I/O drops connected via RIO cable (140CRP93100 head-end required).
Q: Is this module compatible with Unity Pro / EcoStruxure Control Expert?
A: Yes. The module is natively supported in both Unity Pro and its successor EcoStruxure Control Expert. DTM/device type manager files are available from Schneider Electric’s Exchange portal.
Q: What is the difference between 140AMM09000 and 140ACI04000?
A: The 140ACI04000 is a dedicated 4-channel analog input-only module. The 140AMM09000 provides mixed I/O (4 in / 2 out) in a single slot, making it more cost-effective when both input and output channels are required in the same rack position.
Q: Can I use this module for thermocouple or RTD inputs?
A: No. The 140AMM09000 accepts standard current/voltage analog signals only. For thermocouple inputs, specify the 140ATI03000; for RTD inputs, specify the 140ARI03010.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days. For out-of-stock situations, contact us for sourcing timeline — typical lead time is 5–15 business days depending on global availability.
