Schneider Electric 140CPS12420 AC Power Supply | Replacement, Equivalent & Selection Guide
The Schneider Electric 140CPS12420 is a dual-voltage AC power supply module for the Modicon Quantum PLC platform, accepting 115 V AC or 230 V AC input and delivering regulated DC power to the backplane. Identified by its red front panel, this module is a critical infrastructure component in process control, utilities, and heavy-industry automation systems. This page provides full technical specifications, verified compatible replacements, and a structured selection guide to help engineers source the right part with confidence.
Technical Specifications
- Manufacturer: Schneider Electric (formerly Modicon)
- Part Number: 140CPS12420
- Series: Modicon Quantum
- Module Type: AC Power Supply (LMS AC PS)
- Input Voltage: 115 V AC / 230 V AC (auto-ranging or switch-selectable)
- Input Frequency: 47–63 Hz
- Output: Regulated DC backplane power
- Front Panel Indicator: RED (power/fault status LED)
- Form Factor: Single-slot Quantum backplane module
- Weight: Approx. 800 g
- Certifications: CE, UL, cUL (refer to current Schneider Electric datasheet for revision-specific listings)
- Operating Temperature: 0 °C to 60 °C
- Humidity: 5–95 % RH, non-condensing
- Mounting: Modicon Quantum backplane slot 1 (dedicated PSU slot)
Compatible Replacement & Equivalent Models
When the 140CPS12420 is discontinued, obsolete, or on extended lead time, the following alternatives are evaluated by engineers for drop-in or near-drop-in replacement:
- 140CPS12420C — Revised production variant of the same module; functionally identical, updated PCB revision
- 140CPS11420 — Lower-capacity AC PS for smaller Quantum racks; verify backplane power budget before substitution
- 140CPS21400 — DC input variant (24 V DC); not a direct replacement but used when AC supply is unavailable
- 140CPS52400 — High-capacity redundant-ready AC PS; suitable upgrade for systems requiring N+1 power redundancy
- Third-party compatible units — Select industrial PSU manufacturers offer Quantum-compatible modules; always validate backplane connector pinout, output voltage tolerance, and inrush current rating before installation
⚠ Konmask recommends bench-testing any replacement module against your specific Quantum rack configuration before live deployment.
Why Choose the Original Model
- Guaranteed backplane compatibility: Factory-validated for all Modicon Quantum rack sizes (2–16 slot)
- Firmware & diagnostics integration: Native fault reporting via Unity Pro / EcoStruxure Control Expert
- Regulatory traceability: Original CE/UL markings preserved for audit and insurance compliance
- Proven MTBF: Schneider Electric’s published reliability data supports long-term plant lifecycle planning
- Warranty & support: Eligible for Schneider Electric service contracts and spare-parts programs
Typical Applications
- Oil & gas upstream/downstream DCS and safety systems
- Water treatment and wastewater SCADA infrastructure
- Power generation and substation automation panels
- Automotive and heavy manufacturing PLC control cabinets
- Pharmaceutical batch control systems requiring validated hardware
- Mining and minerals processing plant automation
System Compatibility
- PLC Platform: Modicon Quantum (all standard backplane sizes)
- Programming Software: Unity Pro, EcoStruxure Control Expert (all versions)
- Communication Modules: Compatible with all 140-series CPU, NOE, and I/O modules
- Redundancy: Can be paired with a second PSU slot for redundant power configurations (verify rack model supports dual PSU)
- Not compatible with: Modicon M340, M580, Premium, or Momentum platforms (different form factor and backplane voltage)
Selection Guide
Use the following criteria to confirm the 140CPS12420 is the correct module for your application:
- Step 1 — Confirm platform: Verify your rack is Modicon Quantum (140-series backplane)
- Step 2 — Check input voltage: Confirm your panel supplies 115 V AC or 230 V AC; if DC supply only, consider 140CPS21400
- Step 3 — Calculate power budget: Sum the current draw of all installed I/O and CPU modules; confirm 140CPS12420 output capacity is sufficient
- Step 4 — Assess redundancy requirement: Single PSU or dual-PSU redundant? If redundant, confirm rack model and order two units
- Step 5 — Check slot position: PSU must occupy the designated power slot (typically slot 1) on the Quantum backplane
- Step 6 — Verify certifications: For SIL-rated or FDA-validated systems, confirm module revision meets your validation documentation requirements
Quality Assurance & Sourcing
- Authenticity: All units sourced by Konmask.com are inspected for genuine Schneider Electric labeling, holographic seals, and date codes
- Functional testing: Modules undergo power-on and output voltage verification prior to shipment
- Packaging: Shipped in anti-static ESD bags with original or equivalent protective packaging
- Traceability: Batch records and supplier documentation available on request for regulated industries
- Warranty: 12-month warranty against manufacturing defects from date of shipment
- Stock status: Contact us for real-time availability; we maintain safety stock of high-demand Quantum PSU modules
How to Order
- Part Number: 140CPS12420
- Minimum Order Quantity: 1 unit
- Lead Time: In-stock orders ship within 1–3 business days; contact us for urgent requirements
- Payment: T/T bank transfer, PayPal, and major credit cards accepted
- Export: We ship worldwide; export documentation (CO, packing list, commercial invoice) provided
- RFQ: For volume orders or project BOM requirements, email support@konmask.com with quantity and delivery schedule
Replacement & Compatibility FAQ
Q: Is the 140CPS12420 still in production?
A: Schneider Electric has transitioned some Quantum PSU variants to end-of-life status. Contact Konmask for current availability of new, refurbished, or equivalent stock.
Q: Can I replace a 140CPS12420 with a 140CPS12420C?
A: Yes — the “C” suffix denotes a PCB revision with no functional change. It is a direct drop-in replacement with identical electrical and mechanical specifications.
Q: Will a third-party Quantum-compatible PSU void my Schneider Electric support contract?
A: Potentially yes. If your system is under an active Schneider Electric service agreement, consult your contract terms before installing non-OEM hardware.
Q: Can this module be used in a Modicon M580 rack?
A: No. The M580 uses a different backplane architecture and dedicated BMX/BME-series power supplies. The 140CPS12420 is exclusively for Quantum-series racks.
Q: What does the red front panel indicate?
A: The red panel is a visual identification feature for the AC input variant of the Quantum PSU family, distinguishing it from DC input models. It does not indicate a fault condition.
Q: Do you provide a certificate of conformance?
A: Yes. A certificate of conformance (CoC) is available upon request for all shipments.
