Allen-Bradley 1769-IQ32T CompactLogix 32-Point 24VDC Sinking Input Module | Replacement, Equivalent & Selection Guide
The Allen-Bradley 1769-IQ32T is a high-density 32-point digital input module designed for the CompactLogix platform. It accepts 24VDC sinking (NPN) field devices and is engineered for space-constrained control panels requiring maximum I/O density. This page provides full technical specifications, compatible replacement options, and a structured selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
- Part Number: 1769-IQ32T
- Series: A
- Manufacturer: Allen-Bradley / Rockwell Automation
- Platform: CompactLogix 1769 Compact I/O
- Number of Inputs: 32 points
- Input Voltage: 24VDC
- Input Type: Sinking (NPN)
- Input Current: 6 mA per point (nominal)
- ON-State Voltage: 15–26.4 VDC
- OFF-State Voltage: 0–5 VDC
- Response Time: 0.1 ms (hardware filter off)
- Backplane Current: 120 mA @ 5VDC
- Power Dissipation: 3.5 W (max)
- Operating Temperature: 0–60°C (32–140°F)
- Connector Type: Removable terminal block (RTB), 40-pin
- Dimensions (H × W × D): 118 × 35 × 87 mm
- Weight: Approx. 0.18 kg
- Certifications: UL, CE, CSA, RCM
Compatible Replacement & Equivalent Models
The following modules are commonly evaluated as replacements or functional equivalents for the 1769-IQ32T. Always verify firmware compatibility and I/O configuration before substitution.
- 1769-IQ32 — 32-point 24VDC sourcing (PNP) input; same form factor, opposite polarity. Suitable if field wiring supports sourcing topology.
- 1769-IQ16 — 16-point 24VDC sinking input; half the density, same signal type. Use when only 16 inputs are required.
- 1769-IQ16F — 16-point fast-response sinking input; suitable for high-speed encoder or pulse applications.
- 1769-IM12 — 12-point 120VAC input module; for legacy AC field devices in the same rack.
- 5069-IB16 — Compact 5000 platform 16-point 24VDC sinking input; next-generation replacement for new system designs.
- 5069-IB32 — Compact 5000 platform 32-point 24VDC sinking input; direct density equivalent for system migrations to the 5069 platform.
Note: Cross-platform replacements (5069 series) require a compatible Compact 5000 controller and updated Studio 5000 project configuration.
Why Choose the Original 1769-IQ32T
- Proven field reliability — Widely deployed in automotive, food & beverage, and material handling industries worldwide.
- Maximum I/O density — 32 points in a single 35 mm wide slot reduces panel footprint and wiring complexity.
- Seamless integration — Native CompactLogix backplane communication; no gateway or adapter required.
- Removable terminal block — RTB design allows module replacement without rewiring field cables.
- Rockwell Automation ecosystem — Full support in Studio 5000 Logix Designer with Add-On Instructions (AOI) and diagnostics.
Typical Applications
- Discrete manufacturing: conveyor control, part detection, end-of-line testing
- Packaging machinery: proximity sensor arrays, position feedback
- Automotive assembly: robot cell I/O, safety interlock monitoring
- Water & wastewater: pump status, valve position feedback
- Building automation: HVAC control panels, access control integration
- Food & beverage: wash-down environments with IP-rated field devices
System Compatibility
- Compatible Controllers: 1769-L16ER, 1769-L18ER, 1769-L24ER, 1769-L27ERM, 1769-L30ER, 1769-L33ER, 1769-L36ERM, and all CompactLogix L3x series
- Programming Software: Studio 5000 Logix Designer v20.0 and later; RSLogix 5000 v16.0 and later
- Backplane Bus: 1769 Compact I/O backplane (left-side or right-side expansion)
- Power Supply: Requires 1769-PA2, 1769-PB2, or equivalent 1769 series power supply
- Maximum Modules per System: Up to 30 expansion modules per controller (subject to backplane current budget)
Selection Guide
Use the criteria below to confirm the 1769-IQ32T is the right module for your application, or to identify the best alternative:
- Input count needed: If ≤16 points → consider 1769-IQ16; if 32 points → 1769-IQ32T is optimal.
- Wiring topology: NPN/sinking field devices → 1769-IQ32T; PNP/sourcing field devices → 1769-IQ32.
- Signal voltage: 24VDC → 1769-IQ32T; 120VAC → 1769-IM12.
- Response speed: Standard (>1 ms) → 1769-IQ32T; high-speed (<0.1 ms) → 1769-IQ16F.
- Platform migration: New system design → evaluate Compact 5000 (5069-IB32) for future scalability.
- Series A vs. later series: Series A is fully supported; verify firmware version compatibility with your controller revision.
Quality Assurance & Sourcing
- Authenticity: All units sourced through verified industrial distribution channels. Counterfeit risk mitigation is a core part of our procurement process.
- Inspection: Each module undergoes visual inspection and label verification prior to shipment.
- Condition: New, surplus-new, and refurbished options available — condition clearly stated on each listing.
- Warranty: 12-month replacement warranty on all stocked units.
- Lead Time: In-stock units ship within 1–3 business days. Contact us for urgent requirements.
How to Order
- Confirm your part number: 1769-IQ32T (Series A)
- Verify quantity and required condition (new / surplus / refurbished)
- Add to cart or contact us directly for bulk pricing and lead time confirmation
- Provide your shipping address and preferred freight method at checkout
- Receive order confirmation with tracking within 24 hours of shipment
For OEM orders, system integrators, or MRO procurement, contact support@konmask.com for a formal quotation.
Replacement & Compatibility FAQ
Q: Can I replace a 1769-IQ32T with a 1769-IQ32 without rewiring?
A: No. The IQ32T is sinking (NPN) and the IQ32 is sourcing (PNP). Swapping requires reversing field wiring polarity.
Q: Is the 1769-IQ32T compatible with MicroLogix controllers?
A: No. The 1769 Compact I/O series is designed exclusively for CompactLogix controllers. MicroLogix uses a different I/O bus.
Q: Can I mix Series A and Series B modules in the same rack?
A: Yes, different series can coexist in the same rack. Verify that your controller firmware supports all installed module series.
Q: What is the maximum number of 1769-IQ32T modules per CompactLogix system?
A: Up to 30 expansion modules total, subject to the backplane current budget of your power supply.
Q: Does the 1769-IQ32T support diagnostics?
A: Basic diagnostics (module fault, communication fault) are available via the controller tag structure in Studio 5000. It does not support point-level diagnostics.
