Distributed I/O Solution – Schneider Electric 140CRP93200 | Modicon Quantum RIO Head Module
Where This Product Is Used
The Schneider Electric 140CRP93200 is a Remote I/O (RIO) Head Module designed for the Modicon Quantum PLC platform. It serves as the communication interface between the Quantum CPU rack and remote I/O drops distributed across the plant floor. Engineers deploy this module in applications where field devices — sensors, actuators, drives, and instrumentation — must be connected over long distances without running individual signal cables back to the main control panel.
Typical deployment environments include:
- Oil & Gas Processing Plants — Remote wellhead and separator skid I/O over S908 RIO bus
- Water & Wastewater Treatment — Distributed pump station monitoring across large facilities
- Power Generation & Utilities — Turbine control and switchgear monitoring with long cable runs
- Automotive Manufacturing — Body shop and paint line distributed I/O drops
- Chemical & Pharmaceutical Plants — Hazardous area remote I/O with intrinsically safe barriers
- Mining & Minerals Processing — Conveyor system and crusher control with remote drops
- Food & Beverage Production — CIP/SIP process control with distributed field I/O
Technical Specifications
| Part Number | 140CRP93200 |
| Brand | Schneider Electric |
| Series | Modicon Quantum |
| Module Type | RIO Head Module (Remote I/O Drop Adapter) |
| Communication Bus | S908 Remote I/O (RIO) Coaxial Bus |
| Bus Speed | 1 Mbit/s |
| Max. I/O Drops Supported | Up to 31 drops per RIO cable |
| Max. Cable Length | Up to 4,572 m (15,000 ft) with repeaters |
| Power Supply Voltage | 24 VDC (from backplane) |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Mounting | Modicon Quantum backplane slot |
| Weight | Approx. 420 g |
| Certifications | UL, CE, CSA |
Why Engineers Specify This Model
- Proven S908 RIO Architecture — The 140CRP93200 uses Schneider’s battle-tested S908 coaxial RIO bus, a deterministic, high-reliability protocol trusted in critical process industries for decades.
- Long-Distance I/O Extension — Supports cable runs up to 4,572 m, eliminating the need for costly multi-conductor home-run cables from remote field devices.
- High Drop Density — A single RIO cable supports up to 31 remote drops, each housing multiple I/O modules, enabling large-scale distributed architectures from a single head module.
- Seamless Quantum Integration — Plugs directly into the Modicon Quantum backplane alongside CPU, power supply, and other modules — no external gateway or converter required.
- Redundancy-Ready — Compatible with Quantum Hot Standby (HSB) CPU configurations, supporting redundant RIO cable paths for fault-tolerant operation.
- Deterministic Scan Time — Fixed, predictable I/O scan cycle ensures reliable real-time control performance for process-critical applications.
Complete System Bill of Materials
A typical Modicon Quantum RIO drop system using the 140CRP93200 includes:
- 140CRP93200 — RIO Head Module (this item, installed in Quantum CPU rack)
- 140CRA93200 — RIO Drop Adapter Module (installed in each remote drop rack)
- 140XBP00600 / 140XBP01000 — Quantum Backplane (6-slot or 10-slot, for remote drop)
- 140CPS11420 / 140CPS21400 — Quantum Power Supply Module (for remote drop rack)
- 140DDI35300 / 140DDO35300 — Discrete Input / Output Modules (field I/O)
- 140ACI03000 / 140ACO13000 — Analog Input / Output Modules (process signals)
- 490NTW00002 — RIO Coaxial Cable (Belden 9463 equivalent, 75Ω)
- 490NRP254 00 — RIO T-connector / Tap for drop connection
- 140XTS00200 — RIO Cable Terminator (required at each end of RIO cable)
Compliance & Industry Standards
- UL Listed — UL 508 (Industrial Control Equipment)
- CE Marked — EMC Directive 2014/30/EU, Low Voltage Directive 2014/35/EU
- CSA Certified — C22.2 No. 142
- RoHS Compliant
- IEC 61131-2 (Programmable Controllers — Equipment Requirements)
- Compatible with IEC 61511 / IEC 61508 safety-instrumented system architectures (consult SIL assessment documentation)
Quality Assurance & Sourcing
At Konmask.com, every Schneider Electric 140CRP93200 unit is:
- Sourced from authorized distributors and verified supply chains
- Inspected for physical integrity, label authenticity, and firmware revision prior to dispatch
- Shipped in original or equivalent ESD-safe packaging
- Backed by our 90-day quality guarantee against defects in materials and workmanship
- Traceable by serial number and batch for full supply chain transparency
How to Source This Part
Ready to order the Schneider Electric 140CRP93200? Here’s how to get started:
- Add to Cart — In-stock units ship within 1–3 business days
- Request a Quote — For volume orders (5+ units), contact us for preferential pricing
- Lead Time Inquiry — If out of stock, we can source from our global supplier network with typical lead times of 2–4 weeks
- Technical Pre-Sales Support — Our engineers can verify compatibility with your existing Quantum system configuration
📧 support@konmask.com | 📞 +0086 19859288691
Application-Specific FAQ
Q: Can the 140CRP93200 be used with Modicon Premium or M340 PLCs?
A: No. The 140CRP93200 is exclusively designed for the Modicon Quantum platform and uses the proprietary S908 RIO bus. It is not compatible with Premium (TSX) or M340 architectures.
Q: How many 140CRP93200 modules can be installed in a single Quantum rack?
A: Multiple RIO head modules can be installed in a Quantum rack (subject to backplane slot availability and power budget), each managing an independent RIO cable with up to 31 drops.
Q: Is the 140CRP93200 compatible with Hot Standby (HSB) CPU configurations?
A: Yes. The module supports Quantum Hot Standby architectures. Redundant RIO cable paths can be configured for fault-tolerant operation using dual 140CRP93200 modules.
Q: What is the maximum I/O point count per RIO cable managed by this module?
A: With 31 drops and up to 8 I/O modules per drop, a single RIO cable can support thousands of I/O points depending on the module types installed.
Q: Can I mix discrete and analog I/O modules in the same remote drop?
A: Yes. Modicon Quantum remote drop racks support mixed I/O configurations — discrete, analog, and specialty modules can coexist in the same drop rack.
Q: What cable type is required for the S908 RIO bus?
A: The S908 RIO bus requires 75Ω coaxial cable (Belden 9463 or equivalent). Schneider Electric part number 490NTW00002 is the recommended pre-terminated cable assembly.
