Schneider Electric 170MCI00100 – CANopen Communication Module | Momentum PLC I/O Platform
Engineering Background
The Schneider Electric Momentum series represents one of the most widely deployed distributed I/O and controller platforms in industrial automation. Designed for modular, DIN-rail-mounted architectures, Momentum modules integrate seamlessly into both standalone and networked control environments. The 170MCI00100 is the dedicated CANopen communication adapter for the Momentum I/O base, enabling high-speed, deterministic fieldbus communication across complex machine and process control systems.
Product Positioning
The 170MCI00100 serves as the fieldbus interface between Schneider Electric Momentum I/O bases and CANopen master controllers. It is the preferred solution for OEMs and system integrators requiring reliable, standards-compliant CANopen connectivity in distributed control architectures — including packaging machinery, material handling, press lines, and building automation systems.
Complete Technical Specifications
- Part Number: 170MCI00100
- Manufacturer: Schneider Electric (formerly Modicon)
- Series / Platform: Momentum I/O
- Module Type: CANopen Communication Adapter
- Fieldbus Protocol: CANopen (CiA DS-301, DS-401)
- Node Address: Configurable via rotary switches (1–127)
- Baud Rate: 10 kbps – 1 Mbps (auto-detect or manual)
- Connector: 9-pin Sub-D (male), standard CANopen pinout
- Supply Voltage: Powered via Momentum I/O base (5 VDC internal bus)
- Operating Temperature: 0 °C to +60 °C
- Storage Temperature: –40 °C to +85 °C
- Relative Humidity: 5% to 95% non-condensing
- Protection Rating: IP20 (module only)
- Dimensions (W × H × D): Momentum standard adapter form factor
- Weight: Approx. 220 g
- Certifications: CE, UL, cUL
- Compatible I/O Bases: All Schneider Electric Momentum 170 series I/O bases
- Compatible Controllers: Any CANopen master (Schneider Electric, Beckhoff, B&R, Lenze, etc.)
- Country of Origin: France / EU
Proven Application Environments
- Packaging and bottling lines with distributed I/O nodes
- Conveyor and material handling systems requiring deterministic cycle times
- Press and stamping machine control with multi-axis coordination
- Building automation and HVAC control networks
- Automotive assembly line distributed control
- Water and wastewater treatment plant I/O expansion
- Retrofit and modernization of legacy Modicon Momentum installations
Engineering Advantages
- Standards-Compliant CANopen: Full CiA DS-301 and DS-401 compliance ensures interoperability with any certified CANopen master.
- Plug-and-Play Integration: Snaps directly onto any Momentum I/O base — no additional wiring harness or adapter required.
- Deterministic Communication: CANopen SYNC and PDO mechanisms deliver cycle-accurate I/O updates for motion-critical applications.
- Wide Baud Rate Range: Supports 10 kbps to 1 Mbps, accommodating both long-distance and high-speed network topologies.
- Rotary Node Addressing: Hardware-based node ID setting eliminates software configuration errors during commissioning.
- Proven Field Reliability: Momentum platform has 20+ years of global deployment across heavy industrial environments.
System Architecture & Signal Flow
The 170MCI00100 mounts on the communication adapter slot of a Momentum I/O base. The CANopen master controller communicates with the module via the Sub-D9 CANopen bus connector. The module translates CANopen PDO/SDO messages into the Momentum internal backplane protocol, making I/O data transparently available to the master’s process image. Node address and baud rate are set via onboard rotary switches prior to installation. The module supports both NMT state machine management and LSS (Layer Setting Services) for advanced network configuration.
Typical signal flow: CANopen Master → CAN Bus (Sub-D9) → 170MCI00100 → Momentum I/O Backplane → I/O Base Channels → Field Devices
Sourcing & Quality Verification
- Source: Authorized distributor stock and verified surplus channels
- Inspection: Each unit undergoes visual inspection, label verification, and functional continuity check before shipment
- Authenticity: Part numbers, date codes, and manufacturer markings verified against Schneider Electric reference documentation
- Packaging: Anti-static bag + foam-lined carton; original OEM packaging preserved where available
- Warranty: 12-month Konmask operational warranty against manufacturing defects
- Traceability: Batch records and inspection reports available upon request for MRO and OEM procurement
Procurement Process
- Confirm Compatibility: Verify your Momentum I/O base model and CANopen master specifications. Contact our engineers if unsure.
- Request a Quote: Submit your quantity and delivery requirements via the contact form or email below.
- Order Confirmation: Receive proforma invoice with lead time and shipping options (DHL / FedEx / sea freight).
- Quality Hold: Pre-shipment inspection report issued on request for orders ≥ 5 units.
- Shipment & Tracking: Real-time tracking provided; export documentation (commercial invoice, packing list, CO) included.
- After-Sales Support: Technical commissioning support available via email or video call.
Technical FAQ
Q: Is the 170MCI00100 compatible with all Momentum I/O bases?
A: Yes. It is compatible with all Schneider Electric Momentum 170 series I/O bases that have a communication adapter slot.
Q: Can this module work with a non-Schneider CANopen master?
A: Yes. The 170MCI00100 is fully CiA DS-301 compliant and works with any certified CANopen master, including Beckhoff, B&R, Lenze, and others.
Q: What is the maximum number of nodes on a CANopen network with this module?
A: CANopen supports up to 127 nodes per network segment. The 170MCI00100 occupies one node address (1–127, configurable).
Q: Is an EDS (Electronic Data Sheet) file available?
A: Yes. The EDS file for the 170MCI00100 is available from Schneider Electric’s product documentation portal and can be provided upon request.
Q: What is the lead time for this part?
A: In-stock units typically ship within 1–3 business days. For larger quantities, please contact us for availability confirmation.
Q: Do you provide a certificate of conformance?
A: Yes, a Konmask inspection certificate is available for all orders. OEM CoC can be requested for verified new-in-box stock.
