Pump & Fan Drive Solution — Schneider Electric ATV310HU55N4 | Altivar 310
Where This Product Is Used
The Schneider Electric ATV310HU55N4 is a 5.5 kW (7.5 HP) three-phase variable speed drive from the Altivar 310 series, purpose-engineered for simple machine applications that demand reliable speed control and energy savings. Typical deployment environments include:
- HVAC Systems — Air handling units, chiller pumps, cooling tower fans, and ventilation systems in commercial buildings and industrial facilities.
- Water & Wastewater — Centrifugal pumps, booster pump stations, irrigation systems, and sewage lift stations requiring precise flow control.
- Conveyor & Material Handling — Belt conveyors, roller conveyors, and packaging lines where smooth start/stop and speed ramping reduce mechanical wear.
- Compressors & Blowers — Screw compressors and centrifugal blowers in manufacturing plants and process industries.
- Food & Beverage Processing — Mixer drives, filling lines, and agitator motors requiring hygienic, controllable speed profiles.
- OEM Machine Builders — Integrated into panel-built control systems for textile, printing, and light industrial machinery.
Technical Specifications
| Part Number / SKU | ATV310HU55N4 |
| Brand / Manufacturer | Schneider Electric |
| Series | Altivar 310 (ATV310) |
| Motor Power | 5.5 kW / 7.5 HP |
| Supply Voltage | 3-Phase, 380–460 V AC (±10%) |
| Supply Frequency | 50/60 Hz |
| Output Frequency Range | 0.5–500 Hz |
| Rated Input Current | ~14.6 A (400 V) |
| Rated Output Current | 13.7 A |
| Protection Rating | IP20 (panel-mount) |
| Control Type | V/f (Voltage/Frequency), Sensorless Flux Vector |
| Communication | Modbus RTU (RJ45), optional CANopen / DeviceNet |
| Braking | DC injection braking; external braking resistor compatible |
| Digital Inputs | 4 configurable digital inputs |
| Analog Inputs | 1 × 0–10 V / 0–20 mA |
| Relay Outputs | 2 relay outputs (fault + run) |
| Ambient Temperature | -10°C to +50°C (operating) |
| Weight | 2.68 kg |
| Mounting | DIN rail / panel mount |
Why Engineers Specify This Model
- Dedicated HVAC/Pump Profile — Pre-configured macros for pump and fan applications reduce commissioning time to under 30 minutes.
- Energy Savings — Quadratic V/f law reduces motor energy consumption by up to 50% at partial loads versus direct-on-line starters.
- Integrated EMC Filter — Built-in Class C2 EMC filter eliminates the need for an external filter in most panel designs.
- Compact Footprint — Slim profile (72 mm wide) allows high-density panel layouts without sacrificing thermal performance.
- Modbus RTU Native — Standard RJ45 Modbus port enables direct integration with BMS, SCADA, and PLC networks without additional gateways.
- Auto-tuning — One-button motor auto-tuning optimizes drive parameters for the connected motor automatically.
- Robust Protection — Thermal overload, overcurrent, overvoltage, undervoltage, and phase-loss protection are all built in.
Complete System Bill of Materials
For a fully functional ATV310HU55N4 installation, engineers typically specify the following complementary components:
- Input Line Reactor — Reduces harmonic distortion and protects against supply transients (e.g., VW3A4551).
- Output dV/dt Filter — Protects motor windings on long cable runs (e.g., VW3A4601).
- Braking Resistor — Required for high-inertia loads with frequent stopping (e.g., VW3A7701).
- Remote Keypad / Display — Panel-mount remote display for operator interface (e.g., VW3A1101).
- CANopen Communication Card — For CANopen network integration (e.g., VW3A3608).
- Schneider GV2 / GV3 Motor Starter — Upstream motor protection circuit breaker.
- 24 VDC Power Supply — For control circuit and I/O power (e.g., ABL8REM24030).
Compliance & Industry Standards
- CE Marked — Compliant with EU Low Voltage Directive (2014/35/EU) and EMC Directive (2014/30/EU)
- UL Listed / cUL — North American safety certification
- RoHS Compliant — Restriction of Hazardous Substances Directive
- IEC 61800-5-1 — Adjustable speed electrical power drive systems safety
- IEC 61800-3 — EMC requirements for power drive systems
- EN 55011 Class C2 EMC — Conducted and radiated emissions
Quality Assurance & Sourcing
Konmask.com specializes in industrial automation components for B2B buyers, system integrators, and OEM machine builders. Every unit offered through our platform is:
- Sourced from authorized distributors or verified surplus channels with full traceability.
- Inspected for physical integrity, label authenticity, and firmware version prior to dispatch.
- Shipped with original manufacturer packaging where available.
- Supported by our technical team for pre-sales specification and post-sales commissioning queries.
How to Source This Part
To place an order or request a quotation for the ATV310HU55N4:
- Online: Add to cart directly on this page for standard stock orders.
- Bulk / Project Quotation: Email [email protected] with your project BOM and required delivery date.
- Phone / WhatsApp: +0086 19859288691 — available for urgent procurement and technical pre-sales support.
- Lead Time: In-stock units ship within 1–3 business days. Special-order units: 7–21 business days depending on origin.
Application-Specific FAQ
Q: Can the ATV310HU55N4 control a pump in a closed-loop PID configuration?
A: Yes. The Altivar 310 has an integrated PID controller that accepts a 4–20 mA or 0–10 V feedback signal from a pressure or flow transducer, enabling closed-loop pump control without an external PLC.
Q: Is an external EMC filter required for CE compliance?
A: No. The ATV310HU55N4 includes a built-in Class C2 EMC filter, meeting EN 55011 requirements for most industrial environments. For residential or light commercial environments (Class C1), an additional external filter may be required.
Q: What is the maximum motor cable length supported?
A: Up to 50 m shielded cable without an output filter. With a dV/dt output filter, cable runs up to 100 m are supported.
Q: Can this drive be used with a single-phase input supply?
A: No. The ATV310HU55N4 (N4 suffix) is rated for 3-phase 380–460 V input only. For single-phase 200–240 V applications, refer to the ATV310HU55M2 variant.
Q: Does the drive support bypass operation?
A: The drive itself does not include an integrated bypass. A separate bypass contactor circuit must be designed into the panel if bypass-to-DOL operation is required.
Q: What communication protocols are natively supported?
A: Modbus RTU via RJ45 is native. Optional plug-in communication cards add CANopen, DeviceNet, PROFIBUS DP, or EtherNet/IP capability.
