Industrial Ethernet Communication Solution – Schneider Electric BMXNOC0401 | Modicon M340
Where This Product Is Used
The Schneider Electric BMXNOC0401 is a dedicated Ethernet communication module engineered for the Modicon M340 PAC (Programmable Automation Controller) platform. It is widely deployed across demanding industrial environments where reliable, high-speed network connectivity is mission-critical:
- Automotive Manufacturing: Real-time data exchange between M340 PLCs and SCADA/MES systems on assembly lines and robotic welding cells.
- Water & Wastewater Treatment: Remote monitoring and control of pumping stations, filtration units, and chemical dosing systems via Modbus TCP/IP.
- Oil & Gas Upstream/Midstream: Integration of field controllers into DCS networks for pipeline SCADA and compressor station automation.
- Food & Beverage Processing: Connecting M340 controllers to HMI panels and historian servers in hygienic production environments.
- Building Automation & Energy Management: Linking M340-based energy meters and HVAC controllers to BMS platforms over EtherNet/IP.
- Pharmaceutical & Life Sciences: Validated network communication in GMP-compliant manufacturing lines requiring audit-trail data logging.
- Power Distribution & Utilities: Substation automation and feeder protection coordination using IEC 61850-compatible Ethernet infrastructure.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number / SKU | BMXNOC0401 |
| Brand | Schneider Electric |
| Series / Platform | Modicon M340 |
| Module Type | Ethernet Communication Module |
| Supported Protocols | Modbus TCP/IP, EtherNet/IP, FTP, HTTP, SNMP |
| Ethernet Ports | 2 × RJ45 (10/100BASE-TX, auto-negotiation) |
| Max Connections | 64 simultaneous TCP connections |
| I/O Scanner | Yes – up to 64 remote devices |
| Web Server | Embedded diagnostic web server |
| Supply Voltage | Powered via M340 backplane (3.3 V / 5 V internal bus) |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | −25 °C to +70 °C |
| Relative Humidity | 10 % to 95 % (non-condensing) |
| Protection Rating | IP20 |
| Mounting | M340 BMX backplane rack (any slot) |
| Dimensions (H × W × D) | 100 × 30 × 117 mm (approx.) |
| Weight | ~600 g |
| Certifications | CE, UL, cUL, RoHS |
Why Engineers Specify This Model
- Dual-Port Ethernet Switch: The integrated 2-port switch enables daisy-chain or star topology without an external switch, reducing panel footprint and wiring cost.
- Simultaneous Multi-Protocol Support: Runs Modbus TCP/IP and EtherNet/IP concurrently, allowing a single module to serve both legacy SCADA and modern EtherNet/IP devices.
- Embedded I/O Scanner: Polls up to 64 remote Ethernet I/O devices autonomously, offloading the CPU and ensuring deterministic scan cycles.
- Built-in Web Diagnostics: Engineers can access real-time module status, network statistics, and I/O data via any standard browser — no additional software required.
- Hot-Swap Capable: Supports online module replacement on M340 racks with redundant power, minimising planned downtime during maintenance windows.
- Unity Pro / EcoStruxure Machine Expert Compatible: Full configuration and diagnostics within Schneider’s standard engineering toolchain — no third-party drivers needed.
Complete System Bill of Materials
A typical M340 Ethernet communication node using the BMXNOC0401 includes:
- BMXNOC0401 – Ethernet Communication Module (this item)
- BMXP342020 / BMXP342030 – Modicon M340 CPU (select per I/O count and memory)
- BMXXBP0400 / BMXXBP0800 – M340 Backplane Rack (4-slot or 8-slot)
- BMXCPS2000 / BMXCPS3500 – M340 Power Supply Module
- BMXDDI1602 / BMXDDO1602 – Digital I/O Modules (as required)
- BMXAMI0410 / BMXAMO0210 – Analog I/O Modules (as required)
- TWDNAC485T – RS-485 Serial Communication Module (optional, for legacy devices)
- Standard Cat5e/Cat6 Ethernet patch cables (field-supplied)
Compliance & Industry Standards
- CE Marking – EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- UL 508 – Industrial Control Equipment (UL & cUL listed)
- RoHS 2011/65/EU – Restriction of Hazardous Substances compliant
- IEC 61131-2 – Programmable Controllers: Equipment Requirements & Tests
- IEEE 802.3 – Ethernet Standard (10BASE-T / 100BASE-TX)
- ODVA EtherNet/IP – Conformance tested
Quality Assurance & Sourcing
Every BMXNOC0401 unit supplied by Konmask.com undergoes the following quality process:
- ✔ Authenticity Verification – Sourced from authorised Schneider Electric distributors or verified surplus channels with full traceability documentation.
- ✔ Visual & Functional Inspection – Each unit is inspected for physical integrity, label authenticity, and connector condition prior to dispatch.
- ✔ Firmware Version Check – Module firmware is verified against Schneider Electric’s published release notes to ensure compatibility with current Unity Pro / EcoStruxure versions.
- ✔ Anti-Static Packaging – Shipped in ESD-safe bags with foam cushioning to prevent transit damage.
- ✔ Warranty – 12-month replacement warranty against manufacturing defects.
How to Source This Part
- Add to Cart – Click Add to Cart and proceed to checkout. We accept T/T bank transfer, PayPal, and major credit cards.
- Request a Quote – For orders of 3+ units or project BOM pricing, email [email protected] with your quantity and delivery timeline.
- Lead Time – In-stock units ship within 1–3 business days (DHL Express / FedEx International Priority). Ex-stock lead time for bulk orders: 5–10 business days.
- Export Compliance – We handle all export documentation including commercial invoice, packing list, and certificate of origin for international shipments.
Application-Specific FAQ
Q: Can the BMXNOC0401 replace the BMXNOE0100 in an existing M340 rack?
A: Yes. The BMXNOC0401 is the successor to the BMXNOE0100 and is backward-compatible with existing M340 racks. It adds a second Ethernet port and enhanced I/O scanner capacity. Unity Pro configuration migration is straightforward.
Q: Does this module support DHCP or does it require a static IP?
A: Both modes are supported. The module can be configured for DHCP, BOOTP, or static IP assignment via Unity Pro or the embedded web server.
Q: How many Modbus TCP/IP connections can run simultaneously?
A: The BMXNOC0401 supports up to 64 simultaneous TCP connections, which can be allocated across Modbus TCP/IP server/client and EtherNet/IP adapter/scanner roles.
Q: Is the module compatible with EcoStruxure Machine Expert (formerly SoMachine)?
A: The BMXNOC0401 is a Modicon M340 module and is configured via Unity Pro or EcoStruxure Control Expert. EcoStruxure Machine Expert targets Modicon M221/M241/M262 platforms and is not applicable here.
Q: Can I use this module for remote I/O over Ethernet?
A: Yes. The embedded I/O scanner function allows the BMXNOC0401 to poll up to 64 remote Ethernet I/O heads (e.g., Advantys STB, Momentum) directly, without additional gateway hardware.
