Machine Control & Robot Communication Solution — YASKAWA JANCD-NCP01 | NCP Series
Where This Product Is Used
The YASKAWA JANCD-NCP01 is a dedicated communication board designed for integration within YASKAWA Motoman robot controllers, primarily the DX100 and NX100 series. It is deployed across a wide range of industrial automation environments where real-time, high-reliability machine-to-machine communication is critical:
- Automotive body welding lines — coordinating multi-axis robot motion with PLC-controlled fixture systems
- Arc welding & plasma cutting cells — synchronizing torch control signals with robot path execution
- Palletizing & material handling systems — enabling upstream conveyor PLCs to trigger robot pick-and-place sequences
- Assembly automation — interfacing YASKAWA controllers with Siemens S7, Mitsubishi Q/iQ-R, or Allen-Bradley ControlLogix PLCs via fieldbus
- Semiconductor & electronics manufacturing — high-speed, low-latency communication in cleanroom robot cells
- Food & beverage packaging lines — hygienic-environment robot coordination with line PLCs
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | JANCD-NCP01 |
| Manufacturer | YASKAWA Electric Corporation |
| Series | NCP (Network Communication Processor) |
| Compatible Controllers | YASKAWA DX100, NX100 Robot Controllers |
| Board Type | Communication / Network Interface PCB |
| Communication Protocol | DeviceNet / CC-Link / PROFIBUS-DP (model-dependent) |
| Form Factor | Plug-in PCB module (controller slot-mount) |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -20°C to +70°C |
| Weight | Approx. 600 g (with packaging) |
| Country of Origin | Japan |
| Condition | New / Refurbished (specify at order) |
Note: Confirm exact protocol variant with your controller’s documentation before ordering. Contact us if you need assistance cross-referencing your controller serial number.
Why Engineers Specify This Model
- OEM-grade reliability — manufactured to YASKAWA’s stringent quality standards for 24/7 industrial duty cycles
- Drop-in replacement — direct slot-compatible with existing DX100/NX100 controller chassis; no hardware modification required
- Deterministic communication — supports real-time fieldbus protocols ensuring microsecond-level cycle time consistency critical for synchronized multi-robot cells
- Reduced integration risk — using the OEM board eliminates firmware compatibility issues common with third-party alternatives
- Long service life — designed for the full operational lifespan of YASKAWA robot controllers (10–15+ years)
- Broad ecosystem support — compatible with YASKAWA’s MotoSim EG-VRC simulation environment for pre-deployment validation
Complete System Bill of Materials
For a fully operational YASKAWA robot communication system, engineers typically specify the following alongside the JANCD-NCP01:
- YASKAWA DX100 or NX100 Robot Controller (main unit)
- JANCD-YCP01 or JANCD-YCP02 — CPU board (if replacing concurrently)
- JANCD-YIF01 — I/O interface board
- JZRCR-NPP01 — teach pendant cable assembly
- Fieldbus master module (PLC-side): e.g., Siemens CP 342-5 for PROFIBUS, or Allen-Bradley 1756-DNB for DeviceNet
- Shielded fieldbus cable (DeviceNet thick/thin, PROFIBUS cable type A)
- Network termination resistors (120 Ω, quantity 2 per segment)
Konmask.com can source complete BOM packages — contact us for a bundled quotation.
Compliance & Industry Standards
- CE Marking — compliant with EU Machinery Directive 2006/42/EC and EMC Directive 2014/30/EU
- UL/cUL Listed — recognized for use in North American industrial control panels
- RoHS Compliant — meets EU Directive 2011/65/EU on restriction of hazardous substances
- ISO 9001:2015 — manufactured under YASKAWA’s certified quality management system
- IEC 61131-2 — programmable controller hardware compliance (applicable to controller system)
- SEMI S2 / S8 — applicable for semiconductor fab deployments
Quality Assurance & Sourcing
Konmask.com sources the JANCD-NCP01 exclusively through verified industrial automation distributors and authorized YASKAWA channel partners. Every unit undergoes the following before dispatch:
- Visual inspection — PCB surface, connector pins, and component integrity check
- Functional verification — bench-tested against known-good DX100/NX100 controller reference units where applicable
- ESD-safe packaging — shipped in anti-static bags with foam cushioning inside double-wall cartons
- Traceability documentation — serial number recorded; certificate of conformance available on request
- Warranty — 12-month warranty against manufacturing defects; advance replacement available for qualified accounts
How to Source This Part
- Confirm compatibility — provide your robot controller model and serial number; our engineers will verify fit
- Request a quote — email support@konmask.com or call +0086 19859288691 for volume pricing
- Place order — add to cart and checkout, or request a proforma invoice for bank transfer / L/C payment
- Lead time — in-stock units ship within 1–3 business days; sourced units typically 7–15 business days
- Export documentation — commercial invoice, packing list, and HS code declaration provided for all international shipments
Application-Specific FAQ
Q: Is the JANCD-NCP01 compatible with the YASKAWA DX200 controller?
A: No. The DX200 uses a different board architecture (JANCD-YCP21 series). The JANCD-NCP01 is designed specifically for DX100 and NX100 platforms. Contact us to identify the correct part for your DX200 system.
Q: Can this board be used to add EtherNet/IP connectivity to an existing DX100 controller?
A: The JANCD-NCP01 supports specific fieldbus protocols (DeviceNet, CC-Link, or PROFIBUS depending on variant). For EtherNet/IP, the JANCD-YEW01 board is the appropriate solution. We can supply both.
Q: What happens if the NCP01 board fails in production?
A: Communication between the robot controller and the PLC/fieldbus network will be interrupted, typically causing an E-stop or alarm condition. We recommend keeping one spare unit on-site. Ask about our consignment stock program.
Q: Do you provide installation support?
A: Yes. We offer remote technical guidance for board replacement procedures. On-site commissioning support can be arranged for qualified projects in mainland China.
Q: Can I return the board if it doesn’t resolve my fault?
A: We offer a 30-day return window for unused, uninstalled boards in original packaging. For boards that have been installed, please contact us — we handle each case individually to ensure a fair resolution.
