Genuine Schneider Electric TSXDEY16A4 Discrete Input Module | TSX Premium Series – Verified Source
The Schneider Electric TSXDEY16A4 is a 16-channel 24 VDC discrete (digital) input module designed for the TSX Premium and Modicon Premium PLC platform. Konmask.com supplies this module as a verified, genuine Schneider Electric component — backed by our 4-step quality verification process and supported by global logistics capabilities.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | TSXDEY16A4 |
| Manufacturer | Schneider Electric |
| Series | TSX Premium / Modicon Premium |
| Module Type | Discrete (Digital) Input Module |
| Number of Channels | 16 |
| Input Voltage | 24 VDC |
| Input Type | Sink / Source (IEC Type 1) |
| Input Current per Channel | 7.5 mA (nominal) |
| Response Time | ≤ 1 ms (fast filter) / configurable |
| Isolation | Optical isolation between field and bus |
| Connector Type | HE10 (20-pin) front connector |
| Backplane Bus | TSX Premium rack bus |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -25 °C to +70 °C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Protection Degree | IP20 |
| Standards | IEC 61131-2, CE, UL, CSA |
| Weight | Approx. 200 g |
Our 4-Step Quality Verification Process
Every TSXDEY16A4 unit shipped from Konmask.com passes through a rigorous four-stage inspection before dispatch:
- Source Authentication — Units are procured exclusively from Schneider Electric authorized distributors or verified OEM surplus channels. Counterfeit-risk suppliers are blacklisted.
- Physical Inspection — Label integrity, housing condition, connector pin alignment, and date-code consistency are checked against Schneider Electric factory standards.
- Functional Bench Test — Each module is powered up and channel-by-channel input response is verified using calibrated test equipment prior to packaging.
- Documentation Audit — Traceability records (lot number, origin, test report) are archived and available upon request for regulated industries.
Key Features & Benefits
- 16 independent 24 VDC input channels — high channel density reduces rack space and wiring cost
- Optical isolation — protects the CPU backplane from field-side voltage transients and ground loops
- Configurable input filters — selectable response times (1 ms / 4 ms / 8 ms) via Unity Pro / PL7 Pro software
- HE10 pre-wired connector compatibility — supports TSXCDP053 / TSXCDP203 pre-wired cables for fast panel wiring
- LED channel status indicators — front-panel LEDs for real-time field signal diagnostics without software
- Hot-swap capable — module can be replaced under power in Premium racks with appropriate rack configuration
- IEC 61131-2 Type 1 compliance — ensures interoperability with standard field sensors and switches
Typical Applications
- Machine tool and CNC control panels — reading limit switches, proximity sensors, and E-stop circuits
- Conveyor and material handling systems — monitoring position sensors, photo-eyes, and gate interlocks
- Water and wastewater treatment — level switch inputs, valve position feedback, pump run/fault signals
- Building automation and HVAC — occupancy sensors, door contacts, and alarm inputs
- Pharmaceutical and food & beverage — IEC-compliant discrete sensing in hygienic process lines
- Power distribution and energy management — breaker status, relay feedback, and protection relay inputs
Compatible System Components
| Component | Part Number | Description |
|---|---|---|
| CPU Module | TSXP571634M | TSX Premium CPU, 16K words, Ethernet |
| CPU Module | TSXP572634M | TSX Premium CPU, 32K words, Ethernet |
| Rack (4-slot) | TSXRKY4EX | TSX Premium 4-slot extension rack |
| Rack (8-slot) | TSXRKY8EX | TSX Premium 8-slot extension rack |
| Pre-wired Cable | TSXCDP053 | 0.5 m HE10 to terminal block cable |
| Pre-wired Cable | TSXCDP203 | 2.0 m HE10 to terminal block cable |
| Power Supply | TSXPSY2600M | TSX Premium 26 W rack power supply |
| Discrete Output Module | TSXDSY16T2 | 16-channel 24 VDC transistor output |
Global Sourcing & Shipping Capabilities
- Stock availability: Konmask.com maintains buffer stock of high-velocity TSX Premium I/O modules to support urgent MRO and project requirements.
- Lead time: In-stock units ship within 1–3 business days; sourced units typically 5–15 business days depending on origin.
- Shipping destinations: We ship to 80+ countries including USA, Germany, UK, Australia, Southeast Asia, Middle East, and South America via DHL, FedEx, and UPS Express.
- Export compliance: All shipments are screened against applicable export control regulations (EAR, EU Dual-Use). End-user declarations provided where required.
- Packaging: Anti-static ESD bags, foam-lined cartons, and climate-controlled storage for sensitive electronics.
Certifications & Compliance Statement
- CE Marking — Compliant with EU Low Voltage Directive and EMC Directive
- UL Listed — Recognized under UL 508 (Industrial Control Equipment)
- CSA Certified — Meets Canadian Standards Association requirements
- IEC 61131-2 — Programmable controller equipment standard for discrete I/O
- RoHS Compliant — Restriction of Hazardous Substances (EU Directive 2011/65/EU)
Konmask.com does not alter, re-label, or modify any manufacturer components. All units are supplied in original or OEM-equivalent packaging with unbroken traceability.
How to Order
- Add to Cart — Click the purchase button above to place an order directly online.
- Request a Quote — For bulk quantities (>5 units), OEM pricing, or project BOM sourcing, email support@konmask.com with your quantity and required delivery date.
- Provide PO / Project Details — Our team will confirm availability, lead time, and issue a proforma invoice within 24 business hours.
- Payment & Dispatch — We accept T/T bank transfer, PayPal, and major credit cards. Tracking number provided upon dispatch.
Authenticity & Trust FAQ
Q: Are these modules genuine Schneider Electric products?
A: Yes. All TSXDEY16A4 units are sourced from authorized channels or verified OEM surplus. We provide traceability documentation upon request.
Q: Can you provide a test report or inspection certificate?
A: Yes. A functional test report is available for each unit. Please request it at the time of order.
Q: Do you offer a warranty?
A: Konmask.com provides a 12-month warranty against manufacturing defects on all modules. DOA (Dead on Arrival) units are replaced at no cost within 30 days of receipt.
Q: What if I need multiple modules for a large project?
A: Contact us for project pricing. We regularly supply 10–500+ unit orders for system integrators and OEMs globally.
Q: Can you source discontinued or obsolete TSX Premium modules?
A: Yes. Obsolescence management is a core service at Konmask.com. We maintain access to NOS (New Old Stock) and refurbished inventory for end-of-life Schneider Electric parts.
Q: What is your lead time for out-of-stock items?
A: Typically 5–15 business days for sourced items. Expedited sourcing is available for urgent shutdowns — contact us directly.
