Machine Control & SCADA Solution – Schneider Electric HMIGTO4310 | Magelis GTO Series
Where This Product Is Used
The Schneider Electric HMIGTO4310 is a 5.7″ QVGA advanced touchscreen HMI panel from the Magelis GTO Series, engineered for demanding industrial environments. Typical deployment scenarios include:
- Machine tool control panels – real-time spindle speed, axis position, and alarm visualization
- Packaging line HMI stations – recipe management, batch tracking, and operator guidance
- Water & wastewater treatment – pump status monitoring, flow rate display, and remote alarm acknowledgment
- Building automation (BMS) – HVAC zone control, energy metering dashboards
- Food & beverage processing – CIP cycle visualization, temperature trending, and compliance logging
- Oil & gas field panels – pressure/flow monitoring in compact control enclosures
Technical Specifications
| Part Number | HMIGTO4310 |
| Brand | Schneider Electric |
| Series | Magelis GTO |
| Display Size | 5.7″ TFT LCD |
| Resolution | 320 × 240 (QVGA) |
| Colors | 65,536 (16-bit) |
| Touch Type | Analog resistive touchscreen |
| Processor | ARM Cortex-A8, 600 MHz |
| RAM | 128 MB |
| Flash Storage | 256 MB internal + SD card slot |
| Communication Ports | 1× Ethernet (RJ45), 2× USB Host, 1× USB Device, 1× Serial (RS-232/485) |
| Supported Protocols | Modbus TCP/RTU, EtherNet/IP, CANopen, Uni-Telway |
| Power Supply | 24 V DC (±20%) |
| Power Consumption | ≤ 15 W |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | −20 °C to +70 °C |
| Protection Rating | IP65 (front panel) |
| Mounting | Panel cut-out, portrait or landscape |
| Dimensions (W×H×D) | 196 × 152 × 52 mm |
| Weight | ~0.8 kg |
| Software | Vijeo Designer 6.x |
| Country of Origin | France / China (varies by batch) |
Why Engineers Specify This Model
- Vijeo Designer integration – drag-and-drop screen builder with built-in PLC driver library covering 200+ device brands
- Dual USB host ports – simultaneous barcode scanner + USB memory stick without a hub
- IP65 front seal – washdown-safe for food, pharma, and chemical environments
- Wide protocol support – connects natively to Modicon M340/M580, Altivar drives, and third-party PLCs via Modbus or EtherNet/IP
- Compact 5.7″ footprint – fits standard 192 × 148 mm panel cut-outs, replacing legacy Magelis XBT-GT panels without re-drilling
- SD card data logging – on-board trend recording and alarm history export without a PC
Complete System Bill of Materials
For a fully operational HMI station, engineers typically pair the HMIGTO4310 with:
- HMIGTO4310 – this HMI panel (SKU: HMIGTO4310)
- XBTZG935 – USB programming cable (Type A to mini-B)
- XBTZG9001 – SD memory card 512 MB for data logging
- ABL8REM24030 – 24 V DC / 3 A regulated power supply
- Vijeo Designer 6.x – engineering software license (sold separately)
- VW3A8306 – RJ45 Ethernet patch cable (shielded, 3 m)
Compliance & Industry Standards
- CE Marking – EU Low Voltage Directive & EMC Directive
- UL 508 – Industrial Control Equipment (North America)
- cULus Listed
- RoHS 2 Compliant (Directive 2011/65/EU)
- IEC 61131-2 – Programmable Controllers: Equipment Requirements
- EN 61000-4 series – EMC immunity (ESD, EFT, surge, conducted RF)
Quality Assurance & Sourcing
Every HMIGTO4310 unit shipped by Konmask.com undergoes the following verification process:
- Visual inspection against Schneider Electric OEM packaging standards
- Firmware version check and boot-up functional test
- Serial number traceability recorded prior to dispatch
- Sourced from authorized distributors and verified surplus channels
- 30-day return window for DOA (Dead on Arrival) units
How to Source This Part
To place an order or request a formal quotation for the Schneider HMIGTO4310:
- Online: Add to cart directly on this page and proceed to checkout
- Email RFQ: [email protected] – include quantity, required delivery date, and destination country
- Phone / WhatsApp: +0086 19859288691 (Mon–Sat, 09:00–18:00 CST)
- Lead Time: In-stock units ship within 1–3 business days; ex-stock orders within 7–14 days
- Export: We ship worldwide via DHL Express, FedEx, and UPS with full customs documentation
Application-Specific FAQ
Q: Can the HMIGTO4310 communicate with a Siemens S7-300 PLC?
A: Yes. Vijeo Designer includes a native S7 MPI/Profibus driver. An MPI-to-USB adapter (e.g., PC Adapter USB A2) is required on the PLC side.
Q: Is the HMIGTO4310 suitable for outdoor cabinet installations?
A: The front panel is IP65-rated, but the rear electronics require an IP54 or better enclosure. Direct sunlight may reduce display readability; a sun shield accessory is recommended.
Q: What is the maximum number of screens supported?
A: Vijeo Designer supports up to 1,000 pages per project on this panel, with up to 500 variables per page.
Q: Can I replace an older HMIGTO2300 with this unit?
A: Yes. The HMIGTO4310 uses the same panel cut-out dimensions and 24 V DC supply. Projects created in Vijeo Designer for the GTO2300 can be migrated with the built-in project conversion wizard.
Q: Does Konmask provide a warranty?
A: We offer a 12-month warranty against manufacturing defects on all new units, and a 90-day warranty on tested refurbished stock. Contact [email protected] for warranty claims.
