Schneider Electric LC1D38M7C 38A AC Contactor | Replacement, Equivalent & Selection Guide
The Schneider Electric LC1D38M7C is a 3-pole AC contactor from the TeSys D series, rated at 38A / 18.5 kW with a 220V AC coil (M7 suffix). Designed for motor control, switching, and industrial automation applications, it is one of the most widely deployed IEC contactors globally. This page serves as a comprehensive selection, replacement, and compatibility reference for engineers and procurement teams sourcing the LC1D38M7C or its equivalents.
Technical Specifications
- Model: LC1D38M7C
- Brand: Schneider Electric
- Series: TeSys D
- Poles: 3-pole (3P) + 1 NO auxiliary
- Rated Current (AC-3): 38A
- Motor Power (400V): 18.5 kW
- Motor Power (220V): 11 kW
- Coil Voltage: 220V AC / 50–60 Hz (M7 suffix)
- Coil Reference: M7 = 220V AC
- Utilization Category: AC-3 (squirrel-cage motors)
- Thermal Current (Ith): 60A
- Auxiliary Contact: 1 NO integrated
- Mounting: DIN rail or screw mounting
- Standards: IEC/EN 60947-4-1, UL 508
- Operating Temperature: -25°C to +60°C
- Degree of Protection: IP20 (open), IP40 (with cover)
- Weight: ~1,210 g
- Country of Origin: France / China (varies by batch)
Compatible Replacement & Equivalent Models
The following models are functionally equivalent or direct replacements for the LC1D38M7C. Always verify coil voltage and auxiliary contact configuration before substitution.
- Schneider (same series, different coil): LC1D38B7C (24V AC), LC1D38F7C (110V AC), LC1D38Q7C (380V AC), LC1D38U7C (240V AC)
- Siemens equivalent: 3RT2036-1AM20 (38A, 220V AC coil, TeSys D footprint compatible)
- ABB equivalent: AF38-30-10-13 (38A, 100–250V AC/DC coil)
- Eaton / Moeller equivalent: DILM38-10 (38A, 220V AC coil)
- Chint equivalent: NXC-38M (38A, 220V AC coil, IEC standard)
- Delixi equivalent: CDC1-38 (38A, 220V AC coil)
Note: Third-party equivalents may differ in terminal layout, auxiliary contact position, or accessory compatibility. Confirm dimensional drawings before panel installation.
Why Choose the Original LC1D38M7C
- Proven reliability: TeSys D is the world’s best-selling IEC contactor range with decades of field validation
- Rich accessory ecosystem: Compatible with LA1D auxiliary contact blocks, LAD4 suppressor modules, and LADN add-on contacts
- Certified compliance: IEC, UL, CSA, CCC, and GOST certified for global deployment
- Predictable lifecycle: Rated for 10 million no-load operations and 1.5 million AC-3 operations
- Easy integration: Direct mounting with TeSys D overload relays (LRD series) without additional adapters
Typical Applications
- Motor starters for pumps, fans, compressors, and conveyors (11–18.5 kW range)
- HVAC systems: chiller compressor control, AHU fan starters
- Machine tool control panels and CNC auxiliary circuits
- Water treatment and wastewater pump stations
- Building automation and BMS-controlled loads
- Star-delta (Y-Δ) starter configurations (used in sets of 3)
System Compatibility
- Overload relay pairing: LRD14C (7–10A), LRD16C (10–16A), LRD21C (12–18A), LRD22C (16–24A) — select based on motor FLA
- Auxiliary contact blocks: LA1DN11, LA1DN20, LA1DN22 (snap-on, front-mount)
- Surge suppressor: LAD4RCU (RC type), LAD4RCE (varistor type) for coil protection
- Mechanical interlock: LAD9R1 for reversing contactor pairs
- PLC output compatibility: Coil driven by 220V AC relay output or SSR; for 24V DC PLC direct drive, select LC1D38BD (24V DC coil)
- Enclosure: Fits standard IEC panel cutouts; compatible with Schneider PrismaSeT and OEM DIN rail enclosures
Selection Guide
Use the table below to select the correct LC1D38 variant by coil voltage:
- LC1D38B7C — 24V AC coil
- LC1D38D7C — 42V AC coil
- LC1D38F7C — 110V AC coil
- LC1D38M7C — 220V AC coil ✔ (this model)
- LC1D38N7C — 415V AC coil
- LC1D38Q7C — 380V AC coil
- LC1D38U7C — 240V AC coil
- LC1D38BD — 24V DC coil (for PLC direct drive)
- LC1D38ED — 48V DC coil
- LC1D38ND — 60V DC coil
Need a higher current rating? Consider LC1D40 (40A), LC1D50 (50A), or LC1D65 (65A) for larger motors.
Quality Assurance & Sourcing
All LC1D38M7C units supplied by Konmask.com are sourced through verified industrial distribution channels. Each unit is:
- Inspected for original Schneider Electric packaging and holographic labels
- Tested for coil continuity and contact resistance before dispatch
- Shipped with original documentation and CE/IEC certification markings
- Backed by our 12-month warranty against manufacturing defects
We specialize in hard-to-source and long-lead-time industrial automation components for MRO, OEM, and system integrator customers worldwide.
How to Order
- Part Number: LC1D38M7C
- Add to cart directly on this page for standard stock orders
- Bulk / project orders: Contact us for volume pricing and lead time confirmation
- Urgent requirements: Email [email protected] or call +0086 19859288691
- Custom configurations: Specify coil voltage, auxiliary contacts, and accessories when inquiring
Replacement & Compatibility FAQ
Q: Can I replace LC1D38M7C with LC1D40M7C?
A: Yes, the LC1D40 is a direct form-fit replacement with a slightly higher 40A rating. Terminal positions and mounting dimensions are identical within the TeSys D frame.
Q: Is the LC1D38M7C compatible with TeSys D overload relays?
A: Yes. It directly clips onto LRD-series overload relays (e.g., LRD22C for 16–24A motor protection) without adapters.
Q: What does the “M7” suffix mean?
A: “M7” designates a 220V AC, 50/60 Hz coil. Other suffixes indicate different coil voltages (e.g., BD = 24V DC, F7 = 110V AC).
Q: Can a Siemens 3RT2036 replace the LC1D38M7C?
A: Electrically yes (same current rating and coil voltage available), but terminal labeling and accessory mounting differ. Verify panel wiring diagrams before substitution.
Q: Is this contactor suitable for capacitor switching (AC-6b)?
A: No. The LC1D38M7C is rated for AC-3 (motor loads). For capacitor banks, use dedicated capacitor switching contactors (LC1DWK series).
