Schneider Electric MPCYT90NAN00N – Advanced Operator Interface | Magelis GTU Series
Engineering Background
The Schneider Electric MPCYT90NAN00N is a high-performance operator interface panel from the Magelis GTU (Graphic Terminal Universal) series — Schneider’s flagship HMI platform engineered for demanding industrial automation environments. Designed to bridge the gap between machine-level control and operator visibility, this unit delivers robust touchscreen interaction, real-time process visualization, and seamless integration with Schneider’s EcoStruxure automation architecture.
Product Positioning
Targeted at OEM machine builders, system integrators, and plant automation engineers, the MPCYT90NAN00N is the preferred choice where reliability, display clarity, and multi-protocol connectivity are non-negotiable. It is widely deployed in manufacturing lines, process control panels, energy management systems, and infrastructure automation projects across Asia-Pacific, Europe, and North America.
Complete Technical Specifications
| Part Number | MPCYT90NAN00N |
| Brand | Schneider Electric |
| Series | Magelis GTU (Graphic Terminal Universal) |
| Display Size | 9.0″ WVGA TFT LCD |
| Resolution | 800 × 480 pixels |
| Touch Technology | Resistive touchscreen |
| Processor | ARM Cortex-A8, 600 MHz |
| Memory (RAM) | 256 MB DDR2 |
| Flash Storage | 256 MB internal |
| Operating System | Embedded Linux |
| Communication Ports | 2× USB Host, 1× USB Device, 1× Ethernet RJ45 (10/100 Mbps), 1× Serial (RS-232/RS-485) |
| Supported Protocols | Modbus TCP/IP, Modbus RTU, EtherNet/IP, CANopen, Profibus DP (via gateway) |
| Power Supply | 24 VDC (±20%) |
| Power Consumption | ≤ 18 W |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -20°C to +70°C |
| Humidity | 10% to 90% RH (non-condensing) |
| Protection Rating | IP65 (front panel) |
| Mounting | Panel cut-out, rear mounting |
| Dimensions (W×H×D) | Approx. 248 × 185 × 55 mm |
| Weight | 9.28 kg (with packaging) |
| Certifications | CE, UL, cUL, RoHS |
| Software | Vijeo Designer (Schneider Electric HMI programming software) |
Proven Application Environments
- Discrete Manufacturing: Assembly line control panels, robotic cell HMI stations, CNC machine operator terminals
- Process Industries: Chemical dosing systems, water treatment SCADA interfaces, oil & gas skid monitoring
- Energy & Utilities: Substation automation, power distribution monitoring, building energy management systems (BEMS)
- Food & Beverage: Hygienic production line control, batch process visualization, recipe management interfaces
- Infrastructure: Tunnel ventilation control, pump station automation, HVAC system management
- OEM Machine Building: Packaging machinery, textile equipment, printing press control panels
Engineering Advantages
- EcoStruxure Native Integration: Plug-and-play compatibility with Schneider Modicon M340, M580, Premium, and Quantum PLCs — zero protocol bridging required
- IP65 Front Panel Sealing: Withstands wash-down environments, dust ingress, and industrial coolant splatter without degradation
- Vijeo Designer Ecosystem: Drag-and-drop screen development, built-in alarm management, trend logging, and multi-language support (Unicode)
- Dual USB Host Ports: Enables simultaneous data logging to USB drive and firmware update without panel disassembly
- Wide Power Input Range: 24 VDC ±20% tolerance absorbs voltage fluctuations common in industrial power rails
- Embedded Linux OS: Deterministic real-time performance with no Windows licensing overhead or OS update dependencies
- Compact Depth Profile: 55 mm rear depth minimizes panel enclosure depth requirements — critical for retrofit projects
System Architecture & Signal Flow
The MPCYT90NAN00N operates as the human-machine interface layer within a three-tier automation architecture:
- Field Level (I/O): Sensors, actuators, and field devices communicate via Modbus RTU (RS-485) or CANopen to the PLC/controller
- Control Level (PLC): Schneider Modicon or third-party controllers process logic and expose data registers via Modbus TCP/IP or EtherNet/IP over the plant LAN
- HMI Level (MPCYT90NAN00N): The operator interface polls controller registers at configurable scan rates, renders real-time process graphics, manages alarms, logs trends to internal flash or USB, and accepts operator setpoint inputs — all without requiring a PC or SCADA server
For multi-panel architectures, the Ethernet port supports simultaneous connection to a SCADA server (OPC-UA or Modbus TCP) while maintaining local PLC communication — enabling supervisory oversight without interrupting machine-level HMI operation.
Sourcing & Quality Verification
- Origin: Genuine Schneider Electric product, sourced through verified industrial distribution channels
- Condition: New-in-box (NIB) or factory-refurbished units available — condition specified at order confirmation
- Authenticity: Each unit ships with original Schneider Electric part label, serial number traceable via Schneider’s product verification portal
- Inspection: Pre-shipment functional power-on test and visual inspection performed by Konmask technical team
- Documentation: Certificate of conformity, packing list, and original datasheet included upon request
- Warranty: 12-month Konmask operational warranty covering manufacturing defects; Schneider OEM warranty terms apply for new units
Procurement Process
- Step 1 — Inquiry: Submit your RFQ via the product page or email support@konmask.com with quantity, required delivery date, and destination port
- Step 2 — Quotation: Konmask responds within 1 business day with pricing, lead time, and available stock confirmation
- Step 3 — Order Confirmation: Purchase order or proforma invoice issued; payment terms: T/T, L/C, or trade assurance
- Step 4 — Inspection & Packing: Unit tested, photographed, and packed in anti-static ESD packaging with foam cushioning
- Step 5 — Shipment: DHL / FedEx / sea freight options; tracking number provided within 24 hours of dispatch
- Step 6 — After-Sales: Technical support available via email and WhatsApp; replacement or refund per Konmask warranty policy
Technical FAQ
Q: Is the MPCYT90NAN00N compatible with third-party PLCs (Siemens, Mitsubishi, Omron)?
A: Yes. Via Vijeo Designer’s built-in driver library, the unit supports Modbus TCP/RTU (universal), and additional drivers for Siemens S7, Mitsubishi FX/Q, and Omron FINS are available. Verify driver version compatibility in Vijeo Designer before commissioning.
Q: What is the recommended Vijeo Designer version for this model?
A: Vijeo Designer 6.2 SP8 or later is recommended. Download from Schneider Electric’s software portal using your mySchneider account.
Q: Can the unit operate in portrait (vertical) orientation?
A: The display supports landscape orientation natively. Portrait mode requires screen rotation configuration in Vijeo Designer and appropriate panel cut-out modification.
Q: What is the backlight lifespan?
A: Rated at approximately 50,000 hours MTBF under normal operating conditions (25°C, 50% brightness). Backlight replacement is a field-serviceable procedure.
Q: Is remote access or VNC supported?
A: Yes. The embedded Linux OS supports VNC server functionality, enabling remote screen monitoring and limited interaction via standard VNC clients over Ethernet.
Q: What export documentation is available for customs clearance?
A: Konmask provides commercial invoice, packing list, certificate of origin (CO), and HS code declaration (HS: 8537.10) for all international shipments.
