Industrial Communication Solution – Schneider Electric TSXCUSB485 | TSX Premium Series
Where This Product Is Used
The Schneider Electric TSXCUSB485 is a USB to RS485 serial converter purpose-built for connecting a PC or laptop to Modicon TSX Premium and TSX Micro PLCs via the terminal port. It is deployed across a wide range of industrial environments where legacy RS485-based Schneider PLCs remain in active service:
- Automotive manufacturing lines – programming and diagnostics of TSX Premium controllers managing robotic cells and conveyor systems
- Water & wastewater treatment plants – remote configuration of pump station PLCs without dedicated RS232 ports on modern laptops
- Building management systems (BMS) – commissioning Modicon PLCs controlling HVAC, lighting, and access control
- Food & beverage processing – on-site PLC firmware updates and fault diagnostics in hygienic production areas
- Power distribution & utilities – interfacing with Modbus RTU networks for energy monitoring and substation automation
- OEM machine builders – standard programming interface included in service kits for TSX Premium-based machines
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | TSXCUSB485 |
| Manufacturer | Schneider Electric (Telemecanique) |
| Series | TSX Premium / Modicon |
| Interface – PC Side | USB Type-A (USB 1.1 / 2.0 compatible) |
| Interface – PLC Side | RS485 (RJ45 or terminal block, per cable end) |
| Protocol Support | Modbus RTU, Uni-Telway, Character Mode |
| Baud Rate | Up to 19,200 bps |
| Cable Length | Approx. 3 m (integrated cable) |
| Power Supply | Bus-powered via USB (no external PSU required) |
| OS Compatibility | Windows XP / 7 / 10 / 11 (driver required) |
| Software Compatibility | Unity Pro, PL7 Pro, SoMachine (legacy) |
| Weight | 160 g |
| Operating Temperature | 0 °C to +60 °C |
| Certifications | CE, RoHS |
Why Engineers Specify This Model
- OEM-matched interface – designed by Schneider Electric specifically for TSX Premium terminal port; eliminates pin-mapping guesswork and signal-level mismatches common with generic USB-RS485 adapters
- Bus-powered convenience – no separate power supply; plug into any USB port and connect directly to the PLC terminal port
- Plug-and-play with Unity Pro & PL7 Pro – recognized automatically by Schneider programming software; no COM port remapping required in most configurations
- Robust industrial cable – shielded cable construction resists EMI interference common in panel environments
- Compact form factor – fits in a technician’s tool bag; ideal for field service and commissioning engineers
- Long-term availability – stocked as a service part to support installed base of TSX Premium PLCs still operating in production
Complete System Bill of Materials
For a complete TSX Premium PLC programming and communication setup, engineers typically source the following alongside the TSXCUSB485:
- TSX Premium CPU module (e.g., TSXP574634, TSXP57454M)
- TSX Premium rack (e.g., TSXRKY8, TSXRKY12)
- Power supply module (e.g., TSXPSY2600M, TSXPSY5500M)
- Unity Pro XL or PL7 Pro programming software license
- Ethernet communication module (e.g., TSXETY5103) for network-based programming
- I/O modules (discrete, analog) per application requirements
Compliance & Industry Standards
- CE Marking – compliant with EU Low Voltage Directive and EMC Directive
- RoHS Compliant – restriction of hazardous substances per EU Directive 2011/65/EU
- USB 2.0 Standard – backward compatible with USB 1.1 ports
- Modbus RTU Protocol – compatible with IEC 61158 fieldbus standard implementations
Quality Assurance & Sourcing
Konmask.com sources the TSXCUSB485 through verified industrial automation distributors and authorized channel partners. Each unit undergoes basic functional verification prior to dispatch. We supply both new-in-box (NIB) and tested surplus units clearly labeled by condition. Traceability documentation is available upon request for MRO and OEM procurement teams.
How to Source This Part
- Add the TSXCUSB485 to your cart and proceed to checkout
- For bulk orders (>5 units) or project-based procurement, contact us directly for volume pricing
- Lead time: typically ships within 1–3 business days from Hong Kong warehouse
- International shipping available; DDP (Delivered Duty Paid) terms available on request
- Proforma invoice and packing list provided for customs clearance
Application-Specific FAQ
Q: Is the TSXCUSB485 compatible with TSX Micro PLCs?
A: Yes. The TSXCUSB485 supports the RS485 terminal port found on TSX Micro series PLCs in addition to TSX Premium.
Q: Do I need to install a driver?
A: Yes. A USB-to-serial driver (typically FTDI or Schneider-specific) must be installed on the PC. Driver files are available from Schneider Electric’s support portal or upon request from Konmask.com.
Q: Can this converter be used with Modbus RTU networks?
A: Yes. The RS485 interface supports Modbus RTU master/slave communication, making it suitable for connecting a PC to any RS485 Modbus network for monitoring or configuration.
Q: What is the difference between TSXCUSB485 and TSXPCX3030?
A: The TSXPCX3030 uses a DB9 RS232 interface (requires a separate USB-to-serial adapter on modern PCs), while the TSXCUSB485 connects directly via USB — the preferred choice for laptops without RS232 ports.
Q: Is this product available with a warranty?
A: All new-in-box units carry the standard Schneider Electric manufacturer warranty. Tested surplus units are covered by Konmask.com’s 90-day functional guarantee.
