Programmable Automation Solution — Schneider Electric TSXP57203M | TSX Premium Series
Where This Product Is Used
The Schneider Electric TSXP57203M is a double-format PL7 processor module from the TSX Premium PLC family, engineered for demanding industrial automation environments. It is widely deployed across the following sectors:
- Automotive Manufacturing — Body-in-white assembly lines, paint shop conveyors, and powertrain test benches requiring deterministic scan times and high I/O density.
- Water & Wastewater Treatment — SCADA-integrated pump station control, dosing systems, and filtration sequencing where continuous operation is non-negotiable.
- Food & Beverage Processing — Hygienic filling lines, pasteurization control, and CIP (Clean-in-Place) automation with strict cycle-time requirements.
- Oil & Gas Upstream/Midstream — Wellhead control panels, compressor station automation, and pipeline SCADA nodes.
- Building Automation & Utilities — HVAC sequencing, chiller plant management, and energy metering in large commercial facilities.
- Discrete Manufacturing — Machine tool control, robotic cell coordination, and multi-axis motion sequencing via Fipio or CANopen fieldbus.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | TSXP57203M |
| Brand | Schneider Electric |
| Series | TSX Premium |
| Processor Type | Double-format PL7 CPU |
| Programming Language | PL7 Pro (IL, LD, FBD, SFC, ST) |
| Memory — Program | 64 KB words |
| Memory — Data | 64 KB words |
| Max. I/O Points | Up to 1,024 discrete I/O |
| Communication Ports | Uni-Telway (terminal port), Fipio bus master |
| Fieldbus Support | Fipio, Modbus, Uni-TE |
| Scan Time | ~0.3 ms / 1,000 instructions (Boolean) |
| Real-Time Clock | Yes (battery-backed) |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | −25 °C to +70 °C |
| Relative Humidity | 5% to 95% non-condensing |
| Power Supply Voltage | Via rack backplane (TSX RKY series) |
| Format | Double-slot module |
| Weight | 1,180 g |
| Certifications | CE, UL, CSA |
Why Engineers Specify This Model
- Double-format processing power — The dual-slot form factor accommodates a more powerful CPU and expanded onboard memory compared to single-format Premium processors, making it the preferred choice for complex, multi-task applications.
- Fipio bus master built-in — Native Fipio fieldbus master capability eliminates the need for a separate communication module, reducing rack space and BOM cost in distributed I/O architectures.
- PL7 Pro ecosystem maturity — Decades of installed base means abundant legacy programs, certified function blocks, and experienced integrators — critical for brownfield retrofits and long-lifecycle plant assets.
- Deterministic real-time performance — Sub-millisecond Boolean scan times ensure tight loop control for high-speed discrete and analog processes.
- Battery-backed RTC & data retention — Integrated real-time clock and SRAM retention support time-stamped event logging and warm-restart after power loss without data corruption.
- Proven rack compatibility — Fully compatible with the TSX RKY rack family and all TSX Premium I/O modules, enabling modular system expansion without platform migration.
Complete System Bill of Materials
A typical TSX Premium system built around the TSXP57203M includes the following components. Contact Konmask for bundle pricing.
| Reference | Description | Role in System |
|---|---|---|
| TSXP57203M | Double-format PL7 CPU | Central processor (this item) |
| TSX RKY 8EX | 8-slot Premium rack | Backplane / rack housing |
| TSX PSY 2600M | 24 VDC power supply module | Rack power |
| TSX DEY 32D2K | 32-channel 24 VDC discrete input | Digital inputs |
| TSX DSY 32T2K | 32-channel transistor discrete output | Digital outputs |
| TSX AEY 414 | 4-channel analog input (±10 V / 4–20 mA) | Analog acquisition |
| TSX ASY 410 | 4-channel analog output | Analog control |
| TSX ETY 110 | Ethernet TCP/IP module | SCADA / HMI connectivity |
| TSX MFP 064M | PCMCIA memory card 64 KB | Program backup / transfer |
| TSX T616 / Magelis | Operator panel / HMI | Local operator interface |
Compliance & Industry Standards
- CE Marking — Compliant with EU Low Voltage Directive (LVD) and EMC Directive for industrial environments.
- UL 508 — Listed for industrial control equipment (North American market).
- CSA C22.2 — Certified for Canadian industrial installations.
- IEC 61131-2 — Programmable controller hardware standard compliance.
- IEC 61131-3 — PL7 Pro supports all five standard programming languages defined by this norm.
- RoHS — Manufactured in compliance with EU Directive 2011/65/EU on restriction of hazardous substances.
Quality Assurance & Sourcing
Konmask.com sources the TSXP57203M exclusively through verified industrial distribution channels and authorized secondary-market partners. Every unit offered undergoes the following quality process:
- Visual & mechanical inspection — Connector pins, module housing, label integrity, and firmware version verification.
- Functional power-on test — CPU boot sequence, memory self-test, and communication port response confirmed before dispatch.
- Authenticity screening — Batch codes, date codes, and PCB markings cross-referenced against Schneider Electric documentation to detect counterfeits.
- ESD-safe packaging — Shipped in anti-static bags with foam cushioning and moisture barrier where applicable.
- Traceability — Each unit is logged with serial number, inspection date, and technician ID for full after-sale traceability.
How to Source This Part
- Add to cart on this page and proceed to checkout — we accept T/T bank transfer, PayPal, and major credit cards.
- Request a quote — For quantities ≥ 2 units or project BOM sourcing, email support@konmask.com with your project timeline and required delivery date.
- Lead time — In-stock units ship within 1–3 business days (Hong Kong warehouse). Express DHL/FedEx available.
- Export documentation — Commercial invoice, packing list, and certificate of origin provided for all international shipments. HS Code: 8537.10.
- After-sales support — 90-day warranty on all tested units. Replacement or credit issued for DOA claims with photographic evidence.
Application-Specific FAQ
Q: Is the TSXP57203M compatible with Unity Pro software?
A: No. The TSXP57203M is a PL7-series processor and requires PL7 Pro (v4.x or later) for programming. It is not compatible with Unity Pro or EcoStruxure Control Expert. If you require Unity Pro compatibility, consider the TSX Premium M340 or Modicon M580 platform.
Q: Can this CPU communicate with a Modbus RTU network?
A: Yes, via the built-in Uni-Telway terminal port configured in Modbus master/slave mode, or via an optional TSX SCM 2116 serial communication module for RS-485 Modbus RTU.
Q: What is the maximum number of Fipio devices this CPU can manage?
A: The TSXP57203M Fipio bus master supports up to 127 device addresses on a single Fipio segment at 1 Mbit/s.
Q: Is a PCMCIA memory card required for operation?
A: No. The CPU has onboard flash memory sufficient for standard programs. A PCMCIA card (e.g., TSX MFP 064M) is recommended for program backup, transfer between CPUs, or extended data storage.
Q: Can I replace a TSXP57203M with a TSXP57253M?
A: The TSXP57253M offers expanded memory (128 KB program / 128 KB data) and is a drop-in hardware replacement in the same rack slot. Program migration is straightforward in PL7 Pro with a CPU change operation, though re-validation is recommended.
Q: Do you offer exchange / repair services?
A: Yes. Konmask partners with certified repair facilities for board-level repair of TSX Premium CPUs. Contact us with your unit’s serial number for a repair quote and turnaround estimate.
