Schneider 140CHS11000 Hot Standby Module | Replacement, Equivalent & Selection Guide
The Schneider Electric 140CHS11000 is a dedicated Hot Standby (HSB) module for the Quantum PLC platform. It enables seamless redundancy between two Quantum CPU racks, ensuring zero-downtime switchover in mission-critical automation systems. This page serves as a comprehensive replacement, equivalent, and selection guide for engineers and procurement teams evaluating the 140CHS11000 or its alternatives.
Selection Background
When sourcing a replacement or equivalent for the 140CHS11000, buyers typically face one of three scenarios: the original module is discontinued or on long lead time, a cost-optimized substitute is required for a non-critical redundancy tier, or a cross-brand migration is underway. Understanding which scenario applies determines whether a direct drop-in, functional equivalent, or cross-brand alternative is appropriate. This guide uses the terms replacement, equivalent, substitute, and compatible alternative to reflect the full spectrum of sourcing decisions.
Technical Specifications
| Part Number | 140CHS11000 |
| Brand | Schneider Electric (Modicon) |
| Platform | Quantum PLC (Modicon Quantum Series) |
| Function | Hot Standby (HSB) Redundancy Module |
| Redundancy Type | Hot Standby — automatic, bumpless switchover |
| Compatible CPUs | 140CPU65x50 series (e.g., 140CPU65150, 140CPU65160) |
| Communication Link | Dedicated fiber-optic HSB cable between primary and standby racks |
| Switchover Time | < 1 scan cycle (typically < 10 ms) |
| Power Supply Requirement | Powered via Quantum backplane (no external supply) |
| Operating Temperature | 0 °C to 60 °C |
| Certifications | CE, UL, cUL |
| Weight | 380 g |
| ⚠️ Key Replacement Parameter | HSB link protocol and CPU firmware version must match between primary and standby modules |
Compatible Replacement & Equivalent Models
1. Direct Drop-in Replacements
These are identical or revision-updated modules that install in the same slot with no configuration change required:
- 140CHS11000 (new revision) — Schneider may release minor hardware revisions under the same part number; confirm firmware compatibility with your CPU version before installation.
- 140CHS21000 — Enhanced HSB module with additional diagnostics; functionally equivalent and backward-compatible with 140CPU65x50 CPUs. Verify with Schneider compatibility matrix.
2. Functional Equivalents
Modules that perform the same Hot Standby function within the Quantum ecosystem but may require minor configuration or cabling changes:
- 140CPU67160 (integrated HSB CPU) — Some Quantum CPU variants include integrated redundancy logic, eliminating the need for a separate HSB module. Applicable only when full CPU replacement is acceptable.
- Schneider Quantum RIO HSB configurations — For distributed I/O redundancy architectures, the HSB module role may be partially fulfilled by RIO head-end redundancy modules. Consult Schneider application note AN-QNT-HSB-001.
3. Cross-Brand Alternatives
For system migrations or greenfield projects where Quantum platform lock-in is not required:
- Siemens S7-400H Redundancy Module (6ES7 400-0HR01-4AB0) — Industry-standard hot standby for S7-400H systems. Not a plug-in substitute; requires full system redesign.
- Rockwell ControlLogix 1756-RM2 Redundancy Module — Equivalent function in Allen-Bradley ControlLogix redundant systems. Cross-brand migration requires I/O remapping and program conversion.
- GE Fanuc RX7i Hot Standby CPU — Alternative for legacy GE Fanuc migrations. Consult Konmask for migration feasibility assessment.
⚠️ Note: Cross-brand alternatives are not plug-and-play substitutes. Always validate with a system integrator before procurement.
Why Choose the Original 140CHS11000
- Precision Redundancy: Factory-calibrated HSB link ensures sub-scan-cycle switchover with zero data loss — critical for continuous process control.
- Platform Certification: Fully certified for Quantum PLC architecture; CE, UL, and cUL marks ensure regulatory compliance in industrial installations.
- Firmware Compatibility: Guaranteed compatibility with 140CPU65x50 firmware versions; no risk of protocol mismatch that can occur with third-party substitutes.
- Seamless Integration: Plug-and-play installation into existing Quantum racks with no additional hardware or software configuration.
- OEM Technical Support: Full Schneider Electric technical support, including remote diagnostics and field service, available for original modules.
- Warranty & Traceability: Genuine modules include full manufacturer warranty and traceable serial numbers for asset management and audit compliance.
Typical Applications
- Oil & Gas: Compressor control and pipeline SCADA systems requiring continuous availability and SIL-rated redundancy.
- Power Generation: Turbine governor and boiler management systems where unplanned downtime carries significant safety and financial risk.
- Water & Wastewater: Pump station and treatment plant automation with 24/7 uptime requirements.
- Automotive Manufacturing: Body-in-white welding lines and paint shop conveyors where PLC failure causes costly production stoppages.
- Chemical Processing: Batch reactor control systems requiring bumpless transfer during CPU maintenance windows.
- Data Center Infrastructure: Facility management systems (HVAC, UPS control) where redundancy is mandated by uptime SLAs.
System Compatibility
The 140CHS11000 is designed for use within the following Schneider Quantum ecosystem components:
- 140CPU65150 / 140CPU65160 — Primary and standby CPUs (HSB-capable)
- 140XBP01600 / 140XBP01000 — Quantum backplane (16-slot / 10-slot)
- 140CRP93200 — Quantum RIO head-end module for distributed I/O
- 140NOE77101 — Ethernet communication module (Unity Pro compatible)
- 140DDO35300 — Discrete output module (compatible with HSB rack)
- 140ACI04000 — Analog current input module (compatible with HSB rack)
- TSX PSY2600M / 140CPS11420 — Quantum power supply modules
Selection Guide
Answer these three questions to confirm the right module for your application:
- Is your existing CPU a 140CPU65x50 series? If yes, the 140CHS11000 is a direct fit. If no, contact Konmask to identify the correct HSB module for your CPU variant.
- Do you require a drop-in replacement with no configuration change? If yes, source an original 140CHS11000 or verified 140CHS21000. If a functional equivalent is acceptable, review the options above and confirm firmware compatibility.
- Are you migrating to a different PLC platform? If yes, cross-brand alternatives apply — but require full system engineering. Contact Konmask for a migration feasibility assessment and BOM review.
Quality Assurance & Sourcing
Sourcing Channels: Konmask sources the 140CHS11000 through authorized Schneider Electric distributors and verified secondary-market channels with full traceability documentation.
4-Step Inspection Process:
- Visual Inspection: Label authenticity, housing integrity, and connector condition verified against OEM reference samples.
- Functional Test: Module powered and HSB link initialized in a Quantum test rack; switchover timing measured and logged.
- Firmware Verification: Firmware version confirmed and documented; compatibility with target CPU version validated.
- Documentation Package: Serial number, test report, and certificate of conformity issued with every shipment.
Available Documents: Certificate of Conformity · Test Report · Datasheet · Packing List · Commercial Invoice
How to Order
- Submit Your Inquiry: Email support@konmask.com or call +0086 19859288691 with your part number, required quantity, and delivery timeline.
- Receive Quotation: Konmask will respond within 24 hours with pricing, lead time, and available documentation.
- Confirm & Ship: Upon order confirmation, modules are inspected, packed, and dispatched with full traceability documentation.
Replacement & Compatibility FAQ
Q: Can I use the 140CHS21000 as a direct replacement for the 140CHS11000?
A: In most cases, yes — the 140CHS21000 is a functional equivalent with enhanced diagnostics and is backward-compatible with 140CPU65x50 CPUs. However, always verify firmware compatibility using the Schneider compatibility matrix before substituting in a live system.
Q: Is the 140CHS11000 compatible with all Quantum CPUs?
A: No. The 140CHS11000 is specifically designed for HSB-capable CPUs in the 140CPU65x50 series. It is not compatible with standard (non-redundant) Quantum CPUs. Contact Konmask to confirm compatibility with your specific CPU model.
Q: Are there cross-brand substitutes or equivalents for the 140CHS11000?
A: Cross-brand alternatives exist (e.g., Siemens 6ES7 400-0HR01-4AB0, Rockwell 1756-RM2) but are not plug-in substitutes — they require full platform migration. If you are evaluating a cross-brand equivalent due to obsolescence or cost, Konmask can provide a migration feasibility assessment. Contact us before committing to a substitute.
