SCHUBERT 09026240 BF3-UNI3 SEC-4400MC-UC CPASC1-M1H-K-P-2.5 CPASC1-VI-SA VMS BF Control Module – Gerhard Schubert GmbH Packaging Automation Series
When a VMS BF control module fails on a Schubert TLM transmodul packaging line, the entire production cell halts — robotic pick-and-place arms freeze, servo axes lose synchronization, and high-speed carton assembly grinds to a stop. Every minute of unplanned downtime in a pharmaceutical or food packaging facility can cost thousands in lost output and compliance risk. The SCHUBERT 09026240 BF3-UNI3 SEC-4400MC-UC CPASC1-M1H-K-P-2.5 CPASC1-VI-SA VMS BF Control Module is the irreplaceable intelligence hub that keeps these precision systems running at full speed.
Within the Schubert BF3-UNI3 (Basis-Funktionsmodul 3, Universal 3) platform, the 09026240 occupies the role of the primary vision-motion-servo (VMS) bus field controller. Paired with the SEC-4400MC-UC motion controller and the CPASC1 servo amplifier cascade (M1H-K-P-2.5 power stage, VI-SA interface), this module orchestrates real-time communication between the machine’s central TLM controller and distributed servo drives across the packaging cell. It is a cornerstone component in Schubert’s globally deployed TLM and F4 series lines, found in production facilities across Europe, North America, and Asia-Pacific.
Technical Specifications
- Part Number / SKU: 09026240
- Module Type: VMS BF Control Module (Vision-Motion-Servo Bus Field)
- Platform Series: BF3-UNI3 (Basis-Funktionsmodul 3, Universal 3)
- Motion Controller Pairing: SEC-4400MC-UC
- Servo Amplifier Interface: CPASC1-M1H-K-P-2.5 (Power Stage) + CPASC1-VI-SA (Interface Adapter)
- Manufacturer: Gerhard Schubert GmbH
- Compatible Machine Series: TLM Transmodul, F4 Packaging Lines
- Weight: 2.6 kg
- Condition: New / Refurbished / Exchange (specify on inquiry)
Key Features & Benefits
- Real-Time VMS Bus Control: Manages high-speed synchronization between vision systems, motion controllers, and servo drives with deterministic cycle times.
- Universal Platform Compatibility (BF3-UNI3): Designed for multi-axis, multi-robot Schubert packaging cells without hardware reconfiguration.
- SEC-4400MC-UC Integration: Seamless pairing with the SEC-4400MC-UC ensures coordinated multi-axis motion profiles for pick-and-place and carton-erecting operations.
- CPASC1 Cascade Architecture: The M1H-K-P-2.5 power stage and VI-SA interface adapter enable modular servo amplifier expansion, reducing wiring complexity.
- Rapid Replacement: Drop-in replacement for failed modules minimizes line restart time — critical for 24/7 production environments.
- Genuine OEM Quality: Sourced from authorized channels; each unit undergoes functional verification before shipment.
Industry & Equipment Applications
- Pharmaceutical Packaging: Blister pack insertion, carton erecting, and leaflet folding lines requiring FDA/GMP-compliant uptime.
- Food & Beverage: High-speed confectionery, bakery, and dairy product secondary packaging.
- Cosmetics & Personal Care: Precision cartoning and tray-loading automation.
- Medical Device Assembly: Sterile packaging lines with strict traceability requirements.
- Consumer Goods: Multi-format flexible packaging cells running Schubert TLM platforms.
System Integration & Compatible Parts
This module is designed to operate within the Schubert TLM ecosystem. Commonly integrated or replaced alongside:
- SEC-4400MC-UC — Motion Controller Unit
- CPASC1-M1H-K-P-2.5 — Servo Amplifier Power Stage
- CPASC1-VI-SA — Servo Amplifier Interface Adapter
- Schubert TLM Central Controller (TLM-F4 series)
- BF3-UNI3 platform backplane and communication bus components
If you are unsure of compatibility with your specific machine serial number or software version, our technical team can assist with cross-referencing before purchase.
Our Quality Assurance Process
- Source Verification: All units are sourced from authorized distributors or directly from decommissioned OEM-maintained lines.
- Functional Testing: Each module is bench-tested for communication integrity, power rail stability, and bus response prior to shipment.
- Secure Packaging: Anti-static ESD packaging with foam cushioning to prevent transit damage.
- Documentation: Shipment includes test report and traceability documentation upon request.
- Warranty: 90-day replacement warranty on verified functional units (terms apply).
How to Order
- Submit an inquiry via the Contact / Request a Quote form on this page.
- Provide your machine model, serial number, and required quantity.
- Our technical team will confirm compatibility and availability within 1 business day.
- Receive a formal quotation with lead time and shipping options.
- Confirm order — we handle export documentation and international logistics.
Why Choose Konmask.com?
- Industrial Automation Specialists: Focused exclusively on PLC, DCS, servo, and motion control components from leading global brands.
- Global B2B Supply: Serving maintenance engineers, procurement teams, and OEM integrators in 40+ countries.
- Fast Response: Dedicated account managers respond to all technical inquiries within 24 hours.
- Competitive Pricing: Direct sourcing relationships enable cost-effective pricing without compromising authenticity.
- Secure Transactions: T/T, L/C, and major payment methods accepted with full export compliance.
Frequently Asked Questions
- Q: Is the SCHUBERT 09026240 a new or refurbished unit?
- A: We stock both new and professionally refurbished units. Please specify your preference when submitting an inquiry, and we will confirm availability and pricing accordingly.
- Q: Can this module be used as a direct replacement without reprogramming?
- A: In most cases, yes — the BF3-UNI3 platform supports module swap with parameter restore from the TLM controller backup. However, firmware version compatibility should be verified with your Schubert service documentation.
- Q: Do you provide export documentation for international shipments?
- A: Yes. We provide commercial invoice, packing list, and certificate of origin. Additional documentation (e.g., EUR.1, Form A) can be arranged upon request.
- Q: What is the lead time for this part?
- A: Lead time varies by stock status. In-stock units typically ship within 3–5 business days. Please contact us for current availability.
- Q: Can Konmask.com source other Schubert spare parts?
- A: Yes. We specialize in hard-to-find Schubert TLM and F4 series components. Submit your full parts list for a consolidated quotation.
