KITZ SCT P11104128 TD4CB-GC-1003-FA-SEP-316LE Pneumatic Ball Valve | Replacement, Equivalent & Selection Guide
The KITZ SCT P11104128 / TD4CB-GC-1003-FA-SEP-316LE is a stainless steel pneumatic actuated ball valve designed for demanding industrial process control applications. Also referenced under part numbers 469205, FBSDV-6.35-2B3-BGC#A, 5252156-A, 302156, and 2302037, this valve is engineered for reliable on/off or modulating service in corrosive and high-purity environments.
Technical Specifications
- Manufacturer: KITZ SCT (Stainless Corporation of Taiwan)
- Model / Part No.: P11104128 / TD4CB-GC-1003-FA-SEP-316LE
- Cross-Reference Nos.: 469205 | FBSDV-6.35-2B3-BGC#A | 5252156-A | 302156 | 2302037
- Valve Type: Pneumatic Actuated Ball Valve (IGS — Integrated Gas System)
- Body Material: 316L Stainless Steel (SEP designation)
- Actuator Type: Double-Acting / Spring-Return Pneumatic (GC series)
- Bore Size: 6.35 mm (¼ inch)
- End Connection: Compression / Tube Fitting (BGC#A)
- Seat Material: PTFE / Reinforced PTFE
- Pressure Rating: Refer to KITZ SCT datasheet for rated WOG/CWP
- Temperature Range: -20°C to +180°C (media dependent)
- Actuation: Pneumatic (FA — Fail-Action specified)
- Weight: Approx. 2,600 g
- Compliance: CE, RoHS (confirm with datasheet)
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents for the KITZ SCT P11104128 / TD4CB-GC-1003-FA-SEP-316LE. Always verify dimensional, pressure, and actuation compatibility before substitution:
- KITZ SCT FBSDV-6.35-2B3-BGC#A — Direct OEM cross-reference (same valve, alternate catalog number)
- KITZ SCT TD4CB-GC-1003-FA-SEP-316LE — Full model string; confirm actuator spring setting matches application
- Swagelok SS-43GXS4 — ¼” SS pneumatic ball valve; verify actuator interface and Cv
- Parker Hannifin 4A-B2LJ-SSP — Comparable SS pneumatic ball valve; check end connection type
- Nupro / Swagelok SS-4P4T — Manual equivalent for reference sizing
- SMC VBA / VBN Series — Pneumatic actuated SS ball valves; confirm port size and actuator torque
Note: Cross-references are provided for selection guidance only. Konmask.com recommends engineering verification before replacement in critical systems.
Why Choose the Original Model
- OEM Precision: Manufactured to KITZ SCT’s exacting tolerances for semiconductor, pharmaceutical, and chemical process systems
- 316L Body: Superior corrosion resistance vs. standard 304 SS — ideal for aggressive media and cleanroom environments
- Integrated Actuator: Factory-assembled and tested pneumatic actuator eliminates field assembly errors
- Proven Reliability: KITZ SCT valves are widely specified in IGS (Integrated Gas Systems) for semiconductor fabs globally
- Traceability: Full material certification and test documentation available
Typical Applications
- Semiconductor process gas distribution (IGS / gas cabinet systems)
- Pharmaceutical and biotech process lines (CIP/SIP compatible)
- Chemical dosing and corrosive fluid control
- High-purity gas and liquid handling systems
- Laboratory and analytical instrument gas supply
- Automated process control panels and skids
System Compatibility
- Pneumatic Supply: Typically 4–7 bar (60–100 psi) instrument air or nitrogen
- Control Signal: Compatible with solenoid valve pilot (3/2 or 5/2 way) — specify fail-open or fail-closed
- Tube Fitting: BGC#A compression fitting — compatible with 6.35 mm (¼”) OD tubing
- PLC / DCS Integration: Actuator accepts standard 24 VDC or 110/220 VAC solenoid signals via pilot valve
- Position Feedback: Optional limit switch / NAMUR sensor bracket available
Selection Guide
Use the following criteria to confirm this valve or select the correct replacement:
- 1. Bore & Flow: Confirm 6.35 mm bore and required Cv/Kv for your flow rate
- 2. Body Material: 316L SS specified — verify media compatibility (acids, solvents, gases)
- 3. Actuation: Double-acting vs. spring-return — confirm fail-safe position (FA = Fail-Action; specify FO or FC)
- 4. End Connection: BGC#A compression fitting for 6.35 mm OD tube — confirm tubing OD and material
- 5. Pressure & Temperature: Verify rated WOG and temperature range against process conditions
- 6. Certifications: Confirm CE, SEMI, or other required certifications for your industry
Not sure which model fits your system? Contact our selection team with your P&ID or existing valve tag data.
Quality Assurance & Sourcing
- All KITZ SCT valves supplied by Konmask.com are sourced from authorized distributors or verified surplus channels
- Each unit undergoes visual inspection and cross-reference verification prior to shipment
- Material Test Reports (MTR) and original packaging available upon request
- Konmask.com specializes in industrial automation components — PLC modules, DCS parts, and process valves
How to Order
- Online: Add to cart directly on this page — stock availability shown in real time
- Email RFQ: [email protected] — include quantity, delivery location, and any certification requirements
- Phone / WhatsApp: +0086 19859288691
- Lead Time: In-stock items ship within 1–3 business days; ex-stock lead times quoted on request
- Minimum Order: 1 piece
Replacement & Compatibility FAQ
Q: Is P11104128 the same as TD4CB-GC-1003-FA-SEP-316LE?
A: Yes — P11104128 is the KITZ SCT internal part number; TD4CB-GC-1003-FA-SEP-316LE is the full model/configuration string. Both refer to the same valve assembly.
Q: What does “SEP” mean in the model number?
A: SEP indicates the body material is 316L Stainless Steel (Stainless Electropolished/Passivated grade per KITZ SCT nomenclature).
Q: Can I replace this valve with a Swagelok equivalent?
A: Swagelok offers comparable ¼” SS pneumatic ball valves, but actuator interface, Cv, and fitting dimensions must be verified. Contact us for a compatibility review.
Q: What is the “FA” designation in the model?
A: FA = Fail-Action — specifies the actuator’s fail-safe behavior. Confirm whether your application requires Fail-Open (FO) or Fail-Closed (FC) and verify the spring configuration.
Q: Do you supply the solenoid pilot valve separately?
A: Yes — compatible solenoid pilot valves (NAMUR or inline) are available. Contact us with your voltage and port size requirements.
