Precision Motion Control Solution – SEW-EURODRIVE CMP40M/BK/KY/RH1M/SB1 | CMP Series
Where This Product Is Used
The SEW-EURODRIVE CMP40M/BK/KY/RH1M/SB1 synchronous servomotor is engineered for demanding motion-control applications where compact footprint, high torque density, and precise positioning are non-negotiable. Typical deployment environments include:
- Packaging machinery – high-cycle pick-and-place arms, form-fill-seal axes, and labeling heads
- Conveyor & material handling – indexing stations, accumulation conveyors, and sortation diverters
- CNC & machine tool auxiliaries – tool-changer actuators, rotary tables, and clamping axes
- Robotics & gantry systems – joint drives in Cartesian and SCARA configurations
- Textile & printing equipment – tension-controlled winding/unwinding and registration axes
- Food & beverage processing – hygienic-area dosing pumps and portioning conveyors (IP-rated enclosure)
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer Part Number | CMP40M/BK/KY/RH1M/SB1 |
| SEW Order Number | 0200-36642 |
| Drawing / Config Code | T1102-01-000-14 |
| Motor Series | CMP (Compact Synchronous Servomotor) |
| Frame Size | 40 (IEC 40 mm flange) |
| Winding Variant | M (medium speed / standard winding) |
| Holding Brake | BK – integrated spring-applied holding brake |
| Shaft Type | KY – cylindrical shaft with keyway |
| Feedback System | RH1M – single-turn high-resolution resolver |
| Connector Option | SB1 – angled power & feedback connector set |
| Country of Origin | Germany |
| HS Code | 8501.52 |
| Gross Weight | ~700 g |
| Shipping | Physical goods – requires shipping |
Why Engineers Specify This Model
- Integrated holding brake (BK) – eliminates external brake modules; load is held safely on E-stop or power loss without additional hardware cost
- Keyway shaft (KY) – positive torque transmission to pulleys, couplings, and pinions; no slip under shock loads
- High-resolution resolver (RH1M) – robust, EMI-immune feedback ideal for harsh industrial environments; no battery backup required
- Compact CMP40 frame – fits space-constrained machine designs while delivering high peak torque-to-inertia ratio
- Native MOVIDRIVE® / MOVITRAC® compatibility – plug-and-play commissioning with SEW drive systems; auto-parameterization via DriveRadar®
- Angled connector (SB1) – reduces cable-bend radius in tight enclosures; simplifies cable routing and maintenance access
Complete System Bill of Materials
For a fully operational servo axis using this motor, engineers typically specify:
- SEW-EURODRIVE MOVIDRIVE® MDX60B or MDX61B servo inverter (size matched to motor)
- SEW resolver cable (pre-assembled, shielded) – part prefix RES-
- SEW power cable (pre-assembled, shielded) – part prefix POW-
- SEW MOVIMOT® or external 24 V DC brake rectifier (if brake supply is separate)
- Coupling or timing-belt pulley matched to 40 mm keyway shaft
- DIN rail 24 V DC PSU for brake and control logic
Contact support@konmask.com for a complete BOM quotation.
Compliance & Industry Standards
- CE Marked – compliant with EU Machinery Directive 2006/42/EC and Low Voltage Directive 2014/35/EU
- UL / cUL recognized components (SEW CMP series)
- RoHS 2 compliant (Directive 2011/65/EU)
- IP protection per IEC 60034-5 (verify exact IP rating on motor nameplate)
- Insulation class F (155 °C) per IEC 60085
- HS Tariff Code: 8501.52 – AC motors, multi-phase, output > 750 W
Quality Assurance & Sourcing
Konmask.com sources SEW-EURODRIVE components exclusively from authorized distribution channels and verified surplus inventories. Every unit undergoes:
- Visual inspection for nameplate legibility, connector integrity, and shaft condition
- Continuity and insulation resistance check (Megger test) prior to dispatch
- Secure anti-static packaging with desiccant for long-haul freight
- Traceable documentation: original manufacturer labels retained
All products are sold with a 30-day return window for DOA (Dead on Arrival) units. Extended warranty options available on request.
How to Source This Part
- Add to cart directly on this page for in-stock units
- Request a quote for volume orders (>3 units) – email support@konmask.com
- Expedited sourcing – if stock is depleted, our procurement team can locate and verify units within 3–5 business days
- WhatsApp / WeChat – reach our technical team at +86 198 5928 8691 for urgent requirements
Application-Specific FAQ
Q: Is this motor compatible with SEW MOVIDRIVE® B series inverters?
A: Yes. The CMP40M with RH1M resolver is natively supported by MOVIDRIVE® MDX60B/61B. Use SEW’s DriveRadar® or MOVITOOLS® MotionStudio for auto-parameterization.
Q: What is the brake release voltage?
A: The BK holding brake is spring-applied and electrically released. Standard release voltage is 24 V DC via SEW’s BG brake rectifier module. Confirm exact specs on the motor nameplate or SEW documentation for order number 0200-36642.
Q: Can the shaft keyway be used with a standard DIN 6885 key?
A: Yes. The KY designation indicates a DIN 6885 Form A keyway. Match key dimensions to the shaft diameter specified in SEW’s dimensional drawing for CMP40.
Q: What feedback resolution does the RH1M resolver provide?
A: The RH1M is a single-turn resolver. Effective resolution depends on the R/D converter in the drive; MOVIDRIVE® B achieves up to 4096 increments/revolution from this resolver.
Q: Is export to non-EU countries supported?
A: Yes. Konmask.com ships globally. HS code 8501.52 applies. Buyers are responsible for local import duties and compliance. We provide commercial invoice and packing list for customs clearance.
