SHARP JW-214NA Power Supply Module | Replacement, Equivalent & Selection Guide
The SHARP JW-214NA is a dedicated power supply module designed for the SHARP JW series PLC platform. This page provides full technical specifications, verified compatible replacements, equivalent alternatives, and a structured selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
| Part Number | JW-214NA |
| Manufacturer | SHARP |
| Module Type | Power Supply Module |
| Compatible Platform | SHARP JW Series PLC |
| Input Voltage | AC 100–240 V (wide range) |
| Output Voltage | DC 5 V / DC 24 V (refer to datasheet for rated current) |
| Mounting | DIN rail / backplane slot |
| Operating Temperature | 0 °C to 55 °C |
| Weight | Approx. 200 g |
| Certifications | CE, UL (verify with datasheet) |
Note: Always verify specifications against the official SHARP JW-214NA datasheet before final design-in.
Compatible Replacement & Equivalent Models
When the JW-214NA is discontinued, hard to source, or requires a cost-effective alternative, the following models are commonly evaluated as replacements. Compatibility must be verified against your specific system configuration.
- SHARP JW-214N — Earlier revision; functionally similar, verify firmware compatibility
- SHARP JW-21PS — Alternative power supply within the JW-20 series; check slot and connector pinout
- SHARP JW-32CUH (integrated PSU variant) — For system-level replacement where CPU+PSU consolidation is acceptable
- Third-party DIN rail PSU (24 VDC, ≥5 A) — Suitable for retrofit projects where the JW backplane is replaced; brands such as MEAN WELL, Phoenix Contact, or OMRON S8VK series are widely used
Konmask.com stocks both OEM and verified-equivalent modules. Contact us to confirm cross-reference availability.
Why Choose the Original Model
- Guaranteed compatibility — Drop-in fit for existing SHARP JW series backplanes with no firmware or wiring changes
- Stable output quality — Factory-tuned ripple and regulation specifications protect sensitive I/O and CPU modules
- Reduced commissioning risk — No re-validation required when replacing like-for-like in certified installations
- Long service life — Industrial-grade components rated for continuous 24/7 operation in harsh environments
- OEM traceability — Full manufacturer documentation and warranty chain maintained
Typical Applications
- Factory automation and discrete manufacturing lines
- Process control panels in chemical, food & beverage, and pharmaceutical plants
- Building management and HVAC control systems
- Machine tool and CNC controller power distribution
- Legacy SHARP JW PLC system maintenance and life extension projects
System Compatibility
The JW-214NA is designed for use within the SHARP JW Series PLC ecosystem. Confirmed compatible platforms include:
- SHARP JW-20 series base units
- SHARP JW-21 series expansion racks
- SHARP JW-50H / JW-100H systems (verify slot specification)
Before ordering a replacement or equivalent, confirm: (1) backplane slot type, (2) output current requirements of all installed modules, and (3) input voltage at your installation site.
Selection Guide
Use the decision flow below to select the right power supply for your application:
- Existing SHARP JW system, like-for-like replacement → Order JW-214NA (OEM)
- JW-214NA unavailable, same platform → Evaluate JW-214N or JW-21PS with pinout verification
- System retrofit or modernization → Consider third-party 24 VDC DIN rail PSU with appropriate current rating
- New system design → Consult Konmask.com for current-generation SHARP or equivalent PLC platform recommendations
- Uncertain about compatibility → Submit your system BOM to support@konmask.com for a free cross-reference check
Quality Assurance & Sourcing
- All units sourced through authorized distributors or verified secondary-market channels
- Pre-shipment inspection: visual, label authenticity, and functional power-on check
- Anti-static packaging with humidity indicator cards for sensitive electronics
- Batch traceability records available on request
- 30-day DOA (Dead on Arrival) replacement guarantee
How to Order
- Online: Add to cart directly on this page — stock status shown in real time
- Email RFQ: Send part number, quantity, and required delivery date to support@konmask.com
- Phone / WhatsApp: +0086 19859288691 (Mon–Fri, 09:00–18:00 CST)
- Bulk / project orders: Request a formal quotation with lead time and warranty terms
Replacement & Compatibility FAQ
Q: Is the JW-214NA still in production?
A: SHARP’s JW series is a legacy platform. Availability depends on remaining OEM stock and secondary-market supply. Contact us for current stock status.
Q: Can I use a generic 24 V power supply instead of the JW-214NA?
A: In retrofit scenarios, yes — provided the output voltage, current capacity, and connector interface are matched. For in-warranty or certified installations, OEM replacement is strongly recommended.
Q: Do you provide a certificate of conformance (CoC)?
A: Yes, CoC and inspection reports are available upon request for orders of 5 units or more.
Q: What is the lead time?
A: In-stock items ship within 1–3 business days. Out-of-stock items are subject to sourcing lead time — typically 2–6 weeks. Contact us for confirmation.
Q: Can Konmask.com help me find an equivalent if the JW-214NA is unavailable?
A: Absolutely. Submit your system details and we will provide a verified cross-reference recommendation at no charge.
