Machine Control & Discrete Output Solution — SHARP ZW-162S | ZW Series
Where This Product Is Used
The SHARP ZW-162S Output Module is deployed across a wide range of industrial automation environments where reliable discrete output switching is critical. Typical application sites include:
- Assembly Line Automation — Controls actuators, solenoid valves, and indicator lamps on high-speed production lines in automotive and electronics manufacturing.
- Conveyor & Material Handling Systems — Drives motor starters and relay coils for belt conveyors, sorting gates, and diverter mechanisms.
- Packaging Machinery — Interfaces with pneumatic cylinders and servo drives in form-fill-seal and cartoning equipment.
- Building Automation & HVAC Control Panels — Switches fan contactors, damper actuators, and pump relays in BMS-integrated panels.
- Water Treatment & Utilities — Operates valve actuators and pump control circuits in SCADA-linked process stations.
- Semiconductor & Clean-Room Equipment — Provides isolated output switching in environments requiring low-noise, high-reliability signal control.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | ZW-162S |
| Manufacturer | SHARP |
| Module Type | Discrete Output Module |
| Series | ZW Series |
| Output Type | Solid-State / Relay (confirm with datasheet) |
| Number of Output Points | 16 Points |
| Rated Output Voltage | 24 VDC / 100–240 VAC (application-dependent) |
| Output Current per Point | Refer to OEM datasheet |
| Communication Interface | Backplane / Rack-mount Bus |
| Isolation | Optical isolation between field and logic side |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -20°C to +70°C |
| Weight | 500 g (approx.) |
| Mounting | Rack / DIN-rail compatible chassis |
Note: Specifications are indicative. Always verify against the official SHARP ZW-162S datasheet before system design.
Why Engineers Specify This Model
- Proven ZW-Series Architecture — The ZW platform is a mature, field-tested SHARP automation product line with a long installed base in Asian and global industrial markets.
- Optical Isolation — Protects the controller backplane from field-side voltage transients and ground loops, reducing nuisance faults in noisy industrial environments.
- High Point Density — 16 output points per module minimise rack space and wiring complexity compared to lower-density alternatives.
- Direct Drop-In Replacement — Maintains pin and bus compatibility within the ZW chassis family, enabling maintenance replacement without rewiring.
- Long-Term Availability via Authorised Distributors — Konmask maintains sourcing channels for legacy and current SHARP automation modules, reducing procurement lead times.
Complete System Bill of Materials
For a complete SHARP ZW-Series output control system, engineers typically specify the following alongside the ZW-162S:
- SHARP ZW-Series CPU / Controller Module
- SHARP ZW-Series Power Supply Module
- SHARP ZW-Series Input Module (e.g., ZW-161S or equivalent)
- ZW-Series Rack / Backplane Chassis (4-slot, 8-slot, or 16-slot)
- Terminal Block Wiring Connectors (field-side)
- 24 VDC Field Power Supply (for output load circuits)
- Programming Cable / Software (SHARP ZW programming environment)
Contact [email protected] for a complete BOM quotation.
Compliance & Industry Standards
- Designed in accordance with IEC 61131-2 (Programmable Controllers — Equipment Requirements and Tests)
- CE Marking — EMC Directive compliance for European market installations
- RoHS compliant (restriction of hazardous substances)
- UL/cUL listing — verify current certification status with SHARP or authorised distributor
- IP20 enclosure rating (module body; panel enclosure provides additional protection)
Quality Assurance & Sourcing
Konmask.com sources SHARP ZW-162S modules through verified industrial distribution channels. Every unit dispatched from our warehouse undergoes the following process:
- Authenticity Verification — Label, date code, and packaging cross-checked against known-good reference units.
- Visual & Mechanical Inspection — Connector pins, PCB condition, and housing integrity inspected prior to dispatch.
- Traceability Documentation — Batch records and sourcing documentation available on request for regulated industries.
- Warranty — 12-month warranty against manufacturing defects. Contact support for RMA procedures.
How to Source This Part
- Add to Cart — Click the purchase button above to place an order directly through Konmask.com.
- Request a Quote — For volume orders (5+ units), email [email protected] with your required quantity and delivery timeline.
- Urgent / Emergency Orders — Call or WhatsApp +0086 19859288691 for same-day quotation on critical maintenance requirements.
- Cross-Reference Assistance — If you are unsure whether the ZW-162S is the correct replacement for your system, send us your existing module part number and we will confirm compatibility.
